Page 1: User Manual
User Manual HDMI ARC To Toslink + Coaxial + L/R Converter Model NO:HDCN0017M1... - Page 2 Introduction Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient.
- Page 3 INTRODUCITON Feature： One HDMI ARC Audio signal input, One Toslink , One Coaxial, One analog L/R Audio output Digital Audio port (Toslink & Coaxial) can support 192Khz Sampling Rate(LPCM2.0 Audio Format) The analog audio (L/R Channel) supports max 1V RMS analog audio output. ...
- Page 4 Picture 1.1 Rear Panel Showing A: Digital Audio Toslink Output Port B：Digital Coax Output Port C：Analog L/R Audio Output Port. D：HDMI ARC Audio Input port E：5V DC Port...
- Page 5 Connection and Operation: 1. To use one HDMI Cable to connect the Display (TV or Project) that supported ARC with the HDMI output port , and the other end is connected to device ARC input port. 2. To use optical cable or coax cable to connect the Toslink output port or coax port with the AV Receiver 3.
- Page 6 PCM output for the display device. Spec: HDCN0017M1 ARC Audio Supported Auido Format…………………………….PCM2.0/Dolby AC3/DTS Digital Audio Output Supported Audio Format.……………..…..PCM2.0/Dolby AC3/DTS Digital Audio Output Sampling Rate..…32KHz, 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz, 192KHz...
- Page 7 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
- Page 8 Serial Trouble Description Cause and Ways to deal with 1. Check the USB cable connected properly Non-Power-Connected 2. Check the display device if it is in on status. 3. Change the USB port confirm again. 1. Confirm the audio receive if it is in on status 2.
