Summary of Contents for Kongsberg Simrad SR70
- Page 1 INSTALLATION MANUAL Simrad SR70 Receiver kongsberg.com/simrad...
- Page 3 Cable plan, page 16 • List of cables, page 17 • Setting up summary, page 19 • Technical specifications, page 22 • SR70 outline dimensions, page 24 • Overview of frequency selection, page 25 423852/B April 2021 © Kongsberg Maritime AS...
- Page 4 Kongsberg Maritime disclaims any responsibility for damage or injury caused by improper installation, use or maintenance of the equipment. Disclaimer Kongsberg Maritime AS endeavours to ensure that all information in this document is correct and fairly stated, but does not accept liability for any errors or omissions. Support information If you require maintenance or repair, contact your local dealer.
-
Page 5: Table Of Contents
Installation Manual Table of contents ABOUT THIS MANUAL ..............5 SIMRAD SR70................7 SR70 Receiver Unit ........................ 7 Scope of supply........................8 System diagram........................10 Support information .......................11 INSTALLING THE SR70 USING ITS MOUNTING BRACKETS..14 CABLE PLAN ................16 LIST OF CABLES ................ - Page 6 Simrad SR70 423852/B...
-
Page 7: About This Manual
The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval. Kongsberg Maritime AS will accept no responsibility for any damage or injury to the product, vessel or personnel caused by equipment that has been incorrectly installed or maintained, or by drawings, instructions or procedures that have not been prepared by us. - Page 8 Microsoft Corporation in the United States and other countries. ® ® ® Simrad , SIMRAD and the Simrad logo are either registered trademarks, or trademarks of Kongsberg Maritime AS in Norway and other countries. 423852/B...
-
Page 9: Simrad Sr70
Simrad SR70 Simrad SR70 SR70 Receiver Unit The SR70 Receiver Unit comprises a rugged box providing all necessary receiver electronics. You can connect maximum four hydrophones. The SR70 Catch Monitoring Receiver is used in catch monitoring systems to receive the information from the wireless sensors and send it to the computer. -
Page 10: Scope Of Supply
Simrad SR70 Installation Manual Hydrophone connectors Ethernet communication port DC power socket AC power connector Related topics System diagram, page 10 Scope of supply Observe the items provided with the SR70 delivery. SR70 Item Part number In the box SR70 Catch Monitoring Receiver... - Page 11 Simrad SR70 Related topics System diagram, page 10 423852/B...
-
Page 12: System Diagram
Hydrophone (The SR70 Catch Monitoring Receiver allows you to connect four hydrophones.) Unless otherwise specified in a contract, the display, the computer, and the hydrophone are not included in the standard delivery from Kongsberg Maritime. Related topics SR70 Receiver Unit, page 7... -
Page 13: Support Information
Telefax • www.kongsberg.com/simrad Website • simrad.france@simrad.com Email address • : Kongsberg Underwater Technology LLC (KUTL) / Simrad Fisheries Company name • : 19210 33rd Ave W, Suite A, Lynnwood, WA 98036, USA Address • : +1 425 712 1136 Telephone... - Page 14 Website • simrad.canada@simrad.com Email address Malaysia • : Kongsberg Maritime Malaysia Sdn. Bhd Company name • : Unit 27-5 Signature Offices, The Boulevard, Mid Valley City, Lingkaran Syed Pu- Address tra, 59200 Kuala Lumpur, Malaysia • : +65 6411 7488 Telephone •...
- Page 15 Simrad SR70 • www.kongsberg.com/simrad Website • simrad.china@simrad.com Email address 423852/B...
-
Page 16: Installing The Sr70 Using Its Mounting Brackets
Simrad SR70 Installation Manual Installing the SR70 using its mounting brackets The receiver unit can be installed vertically or horizontally using the integrated mounting brackets. Prerequisites A suitable location for the SR70 must be defined prior to installation. The unit can in principle be mounted anywhere on board the ship, provided that the location is dry and ventilated. - Page 17 Installing the SR70 using its mounting brackets Secure the unit using four bolts or screws. Connect the cables. Note When you connect the cables, make sure that they are all properly secured, and able to withstand the vibration and movements of the vessel. Related topics Cable plan, page 16 423852/B...
-
Page 18: Cable Plan
Simrad SR70 Installation Manual Cable plan The cables are used to connect the SR70 to the computer and to the hydrophone or hydrophones. Display Computer + TV80 SR70 Catch Monitoring Receiver Hydrophones Cables identified with an asterisk (*) are system or commercial cables. These cables are provided in the delivery or with the relevant item. -
Page 19: List Of Cables
List of cables List of cables A set of cables is required to connect the system units to each other, and to the relevant power source(s). Additional cables are required to connect the SR70 system to peripheral devices. Computer cables Cable Type From/To... - Page 20 Simrad SR70 Installation Manual Related topics Cable plan, page 16 Installing the SR70 using its mounting brackets, page 14 423852/B...
-
Page 21: Setting Up Summary
Setting up summary Setting up summary Before a new SR70 Catch Monitoring Receiver can be put to use, it must be set up for operation. Prerequisites The Receiver Unit must be connected to the computer using an Ethernet line. Context This information describes several sequential tasks. - Page 22 Simrad SR70 Installation Manual On the menu, select Setup Installation Select to open the Add LAN Port Select dialog box. Input (LAN) Select the SR70 Catch Monitoring Receiver. Inspect the quality of reception identifying the cleanest frequencies. Select the hydrophone icon on the corresponding “block diagram”...
- Page 23 Setting up summary Select the gear you wish to use. page is located at the left of the dialog Select Gear Installation box. Select one or more catch monitoring sensors, and place them on the chosen gear. To open the dialog box, select Add New Sensor Add New Sensor...
-
Page 24: Technical Specifications
These technical specifications summarize the main functional and operational characteristics of the SR70 Catch Monitoring Receiver. Note At Kongsberg Maritime, we are continuously working to improve the quality and performance of our products. The technical specifications may be changed without prior notice. - Page 25 Technical specifications Compass safe distance • : Not applicable. The unit is not located on the bridge. Compass safe distance Related topics SR70 outline dimensions, page 24 423852/B...
-
Page 26: Sr70 Outline Dimensions
Simrad SR70 Installation Manual SR70 outline dimensions Download the source drawing from the product pages: www.kongsberg.com/simrad. 423852/B... -
Page 27: Overview Of Frequency Selection
Overview of frequency selection Overview of frequency selection If many acoustic systems are used simultaneously, due care must be taken to prevent acoustic interference between the different instruments. Simrad catch monitoring sensors communicate on a frequency range from 40 to 50 kHz. Frequencies 39.4 - 40.8 -... - Page 28 Simrad SR70 Installation Manual PI50 and PI60 Receiver Units • The PI50/PI60 Receiver Units frequency range is from 43.6 to 49.4 kHz. It works in the same operational frequency band as PX TrawlEye sensor channels 4 to 8 and the rest of PX sensors channels 4L to 8H.
- Page 30 ©2021 Kongsberg Maritime...
