Installation instruction
Network Isolator MED MI 1005 MB
▶
Bill of Material (BOM)
1 x Frame
1 x Bracket
Baaske Medical GmbH & Co. KG
www.baaske-medical.de
2 x Screws 2,5 x 8
2 x Nuts M 2,5
Bacmeisterstraße 3 32312 Lübbecke
1 x Cover
1 x Mounting plate
Harting PushPull
Tel: +49 5741 236027- 0
Please check
the BOM prior to
assembling the
parts.
1 x MI 1005 E Medical
Mountable Isolator
Rev. 1
Fax: +49 5741 236027- 99
