Heating Input: 40,000-80,000 BTU/h
Standard Features
• Heavy-duty stainless-steel tubular heat exchanger
• Super-ferritic Stainless-steel secondary heat exchanger
• Single-stage gas valve
• Durable Silicon Nitride igniter
• Quiet multi-speed induced draft blower
• Self-diagnostic control board with constant
memory fault code history output to a LED
• Eligible for installation in California's South Coast
Air Quality Management District (SCAQMD) and San
Joaquin Valley Air Pollution Control District (SJVUAPCD).
This furnace complies with the 14 ng/J NOx emission
limit in SCAQMD Rule 1111 and SJVUAPCD Rule 4905.
• AHRI Certified; ETL Listed
SS-GM9S96-U
Downloaded from
ManualsNet.com
* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the Lifetime Heat Exchanger Limited Warranty (good
for as long as you own your home), 10-Year Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must be
completed within 60 days of installation. Online registration is not required in California or Québec.
search engine
Ultra Low NOx, Single-Stage,
Multi-Speed ECM Gas Furnace
Cabinet Features
• Designed for multi-position installation -
GM9S96: upflow, horizontal left or right
• Certified for direct vent (2-pipe)
or non-direct vent (1-pipe)
• Easy-to-install top venting with optional side venting -
GM9S96: upflow models only
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return with
easy-cut tabs for effortless removal in
bottom air-inlet applications
www.goodmanmfg.com
GM9S96-U
Up to 96% AFUE
Contents
Nomenclature ............................................2
Product Specifications ............................... 3
Dimensions ................................................4
Airflow Specifications ................................5
Wiring Diagram ..........................................6
Accessories ................................................8
) ≤ 1.4%
Leak
11/21
Supersedes 10/21
Advertisement
Related Manuals for Goodman GM9S96-U Series
Summary of Contents for Goodman GM9S96-U Series
-
Page 1: Table Of Contents
GM9S96-U Ultra Low NOx, Single-Stage, Heating Input: 40,000–80,000 BTU/h Multi-Speed ECM Gas Furnace Up to 96% AFUE Contents Nomenclature ..........2 Product Specifications ....... 3 Dimensions ..........4 Airflow Specifications ........5 Wiring Diagram ..........6 Accessories ..........8 Standard Features Cabinet Features • Heavy-duty stainless-steel tubular heat exchanger •... -
Page 2: Nomenclature
Nomenclature 7,8,9 13,14 Brand Engineering G - Goodman® Brand Major/Minor Revisions A - Initial Release B - 1st Revision Configuration M - Upflow/Horizontal N = > 40 NG/J NOx C - Downflow/Horizontal X = < 40 NG/J NOx U = < 14NG/J NOx... -
Page 3: Product Specifications
GM9S96-U Product Specifications GM9S96 GM9S96 GM9S96 0403BU 0603BU 0805CU Heating Data High Fire Input¹ 40,000 60,000 80,000 High Fire Output¹ 38,400 57,600 76,800 AFUE² Temperature Rise Range (°F) 15 - 45 30 - 60 30 - 60 Vent Diameter³ 2" - 3" 2"... -
Page 4: Dimensions
GM9S96-U Dimensions Discharge Discharge 28¾ 6½ ¾ 2¾ 6½ ¾ Air Intake 2⅝ 1⅞ 2" Pipe 19½ Center Dimple Vent/ Flue Pipe Left-Side Alternate For Alternate 2" PVC Drain Trap Vent/ Flue Air Intake Pipe ¾ Exterior Holes 3" Location OD Hole High-Voltage Right-Side... -
Page 5: Airflow Specifications
GM9S96-U Airflow Data COOLING & CIRCULATION AIRFLOW EXTERNAL STATIC PRESSURE, (INCHES WATER COLUMN) THERMO- MODEL TAP # STAT CALL 1043 1011 GM9S96 Y1 / Y2 / G F05^ 1080 1051 1021 0403BU* 1182 1155 1129 1102 1075 1048 1020 1193 1164 1136 1108... -
Page 6: Wiring Diagram
Wiring Diagram PRESSURE TRANSDUCER 115 VAC/ 1 Ø /60 HZ POWER SUPPLY WITH UNUSED OVERCURRENT PROTECTION DEVICE ID BLOWER PRESSURE SWITCH DISCONNECT TR (2) GAS VALVE INTEGRATED CONTROL MODULE AUTO RESET PRIMARY LIMIT CONTROL SURFACE IGNITER 2 CIRCUIT MVC (5) VALVE CONNECTOR PRESSURE... - Page 7 Temperature Rise Range Chart SS-GM9S96-U www.goodmanmfg.com Downloaded from ManualsNet.com search engine...
-
Page 8: Accessories
Note: Other size filters of equal or greater dimensions may be used. Filters may also be centrally located. Goodman Manufacturing Company, L.P., reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations. © 2021 Goodman Manufacturing Company, L.P. • Houston, Texas www.
