NOVA HD LED LIGHTING KIT INSTRUCTIONS
Congratulations on Your Purchase
Congratulations on the purchase of your Nova HD Umbrella with integrated LED lighting kit!
There are a couple things to think about prior to installing your new umbrella:
-
With the cabling supplied, the umbrella needs to be installed within 10m of a power-
source
-
How will the cabling run to the umbrella? This will depend on the type of surface that the
umbrella is installed on and the environment it is installed in (eg. residential vs public or
commercial space).
-
Do you need the services of an electrician?
Components Supplied with the LED Lighting Kit
-
1x Central Lighting Hub (installed on umbrella)
-
8x Integrated LED strip lights (installed on umbrella)
-
1x 24v low voltage power cable (installed inside the umbrella)
-
1x 10m 24v extension cable
-
1x Cable Connector
-
1x Remote control
-
1x 60-Watt transformer with AU/NZ power plug
NOTE: The 10m extension cable is a 24-Volt cable (low voltage). If you use this cable as supplied and connect
the LED driver to an existing power plug that is within reach you may not require the services of an electrician.
However, if you intend to make any modifications to the supplied cabling (eg. attaching extensions, running 240v
cable, installing a new power-point) you will require a licensed electrician.
If in doubt, seek the advice of a licensed electrician.
