- Page 1 PAGE TITLE OWNER MANUAL NOVA HD UMBRELLA www.instantshadeumbrellas.com.au...
- Page 2 The following information is to inform you on how to operate your Nova HD umbrella correctly. Please follow these instructions as they are designed to assist operation and prolong the life of the...
-
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Your Nova HD umbrella comes fully assembled in the box. Before you can erect and set up your Nova HD umbrella you will need to install the required base fitting which is either a base plate or inground fitting. Prior to fixing the base plate or inground fitting please read the following important information. - Page 4 1 Fixing the base plate to a timber deck: If you wish to install your Nova HD umbrella onto a timber deck then the following installation method should be adhered to. Your base plate must be bolted to the frame of the deck and not only to the deck planking.
- Page 5 www.instantshadeumbrellas.com.au 2 Fixing the base plate to a concrete slab: When installing your umbrellas on a concrete surface fix the base plate to the concrete using 6 galvanised or stainless concrete screw fixings. The concrete slab should be at least 150mm thick. The fixings used should be at least 75mm long (100mm recommended) and 10mm in diameter.
-
Page 6: Inground Installation
www.instantshadeumbrellas.com.au INGROUND INSTALLATION Fixing into lawn, soil or patio: When installation is required in soil or lawn etc. then an inground fitting must be used. This is a galvanised steel fitting which must be concreted into position. Terrain differs from thick clay to sand or fine soil so a different sized hole must be prepared and a different volume of concrete used to suit. - Page 7 SETTING UP YOUR NOVA HD UMBRELLA Once you have fixed the base fitting correctly you can erect the umbrella by following the below instructions. To erect the Nova HD Umbrella: Attach the hinged spigot to the base plate or inground fitting with the one smaller stainless steel spigot bolt supplied with your umbrella.
-
Page 8: Care And Maintenance
OPERATING YOUR NOVA HD UMBRELLA To open the Nova HD umbrella: • If opening the umbrella for the first time please refer to the section called “opening the umbrella for the first time”. • Remove the strap from the canopy. - Page 9 Damage to the fabric caused by “pinching” is not covered by warranty. Maintenance instructions for your Nova HD: • In coastal or metropolitan environments it is beneficial to wash of any dirt, pollen and salt residue from the umbrella frame and fabric using a hose or soft bristle brush.
- Page 10 www.instantshadeumbrellas.com.au TWO METHODS FOR STRAPPING Closing the umbrella overnight: Your umbrella is supplied with a “Halo” ring for quick and easy strapping of the umbrella Step One: Locate the Halo components (ring tube and telescopic rod). Step Two: Carefully bend the ring tube to form a circle, you may need a second person to help.
- Page 11 www.instantshadeumbrellas.com.au...
- Page 12 www.instantshadeumbrellas.com.au Closing the umbrella for long term storgae: Step One: Stand in front of the umbrella and locate the front four fabric panels. Step Two: Group the four panels and roll together towards the frame. Step Three: Fold the remaining panels over the rolled panels one by one, alternating from left to right until all panels are neatly folded.
- Page 13 UV-resistant 100% Nova HD Giant Telescopic Heavy Duty Umbrella Solution Dyed Premium Acrylic Canvas (5 year warranty agains fading). NOVA HD UMBRELLA RANGE Upgrade to 100% waterproof Frames Canvas LED Lights (optional) 650GSM welded PVC also Frames are made of Marine Grade Anodised Aluminium with a 3 year warranty against...
- Page 14 Nova HD Drawing NOVA HD PARTS DIAGRAM Top Hub “U”Joint Nut & Bolt Canopy screw bolt and Washer Square Telescopic Tube Strop Nut & Bolt Strop Strut Sliding Spacer & Barrel Bolt Canopy Arm Mast Cap “U”Joint Bottom Hub...
- Page 15 www.instantshadeumbrellas.com.au...
-
Page 16: Warranty
www.instantshadeumbrellas.com.au WARRANTY Thank you for your purchase from Instant Shade Pty Ltd. The benefits given by this warranty are in addition to all other rights and remedies in respect of the product which the purchaser has under the Trade Practices Act and similar State and Territory Laws. Nothing in this warranty will exclude, restrict or modify any conditions, warranty rights or liability implied in this purchase or protected by law where to do so would render this warranty void. - Page 17 www.instantshadeumbrellas.com.au CANVAS Warranty Conditions - PLEASE READ CAREFULLY The canvas warranty is a Limited Manufacturer’s Warranty, which is passed on by Instant Shade Umbrellas. The canvas warranty covers the canopy canvas only. It specifically excludes items such as thread, zips, velcro, webbing and binding used in canopy fabrication.
- Page 18 www.instantshadeumbrellas.com.au Instant Shade Pty Ltd info@instantshade.com.au www.instantshadeumbrellas.com.au...
