Deviser EM20 User Manual

EM20 Technical Specifications and
User Manual
Calibrator hole
● Frequency range: 1GHz; Field strength calibration range: 5V/m ±0.5dB (20℃ ~30℃ );
● This field strength calibrator is suitable for calibrating the field strength of all kinds of
electromagnetic filed strength meters with probe meridional size below 65mm, as well as 360
degrees isotropy detection and verification of electromagnetic field probe;
● Insert the antenna probe into the circular hole of calibrator in axial parallel as shown in figure,
keep the geometric center of the electromagnetic field probe overlap with the geometric
center of calibrator circular hole;
● Avoid using the calibrator in high power RF radiation environment;
● Please keep the calibrator over 1m away of human body;
● Be aware of device battery voltage warning when calibrating, low battery voltage can cause
inaccurate calibration;
● The frequency range and field strength calibration range can be customized;
● Powered by 4 AA battery, 6V or AC line adaptor, 12V, flexible and convenient.
● Calibration tuning potentiometer hole (adj) is specially used by professionals to calibrate field
strength.
Calibration tuning
potentiometer hole Power On/Off Power switch(DC/AC)
Charging port
Power indicator
