Icarus
BP-0Li2-000-KTL013-x & BP-0Li2-000-KTH013-X
H IG H OU T PU T
I NSTA LL IN S EC O ND S
EN E RGY EF F IC I E N T
Joining Your Li2 Fixture
1. Simply slide joiner plate into each side of the fixture.
2. Use thumb screws to screw joiner plate into place.
On-Board Power Supply
1. Utilize brackets to mount power supply and cables.
2. Snap brackets into place on the middle two bars.
3. Screw power supply into brackets.
Easy Rack Mount Solution with RapidRack
RapidRack™ Mounting Plate
RapidRack™ Thumb Screw
1. Loosen RapidRack
thumb screw enough to slide RapidRack
™
2. Slide RapidRack
plate into desired rack mount position.
™
3. Tighten RapidRack
thumb screw to secure RapidRack
™
IMPORTANT:
To avoid risk of damage to the fixture and their LEDs, make all wiring
ELECTRICAL SHOCK HAZARD
Read all instructions prior to performing installation. All facility wiring to be performed only by licensed electricians in accordance with National Electric Code
and local code specifications. Failure to do so voids warranty and may result in serious injury or death. Supplied Connectors on all power cables have breaking
capacity and can be installed by non-licensed individuals. Disconnect main power prior to installation, maintenance or service.
For more info, documents and videos reqarding your BIOS Icarus LLi fixtures: Please log onto www.bioslighting.com/product/icarus-lli/
bioslighting.com
(321) 260-2467
info@bioslighting.com
Li2
™
Rev1 [2021 01/05]
Specifications and dimensions subject to change without notice.
Contact BIOS for questions and the most current information.
Installation Guide
For PSU wiring info, please visit product page by scanning QR code.
Li 2 Joiner Plate
™
Tip:
1. Extend RapidRack™ plates on one end and rest on rack
plate.
™
ledge.
plate into place.
2. Extend RapidRack™ on opposite side to complete
™
secure mounting solution.
Screw joiner plate into place
Brackets for cables and PSU box
Extend & rest on ledge
Extend & secure
CAUTION!
ICES-005 (A)
Page 1 of 2
