MJM E118-3TW-FF-SQ-PAIL Assembly Instructions

E118-3-FF-SQ-PAIL MJM INTERNATIONAL CORPORATION
Assembly Instructions
NOTE: A PHILLIPS SCREWDRIVER OR A CORDLESS HAND DRILL IS REQUIRED TO TIGHTEN / SECURE ALL SCREWS.

IDENTIFY COMPONENTS TO START ASSEMBLY

SEAT SECTION WITH ARMS, COMMODE, FOLDING FOOTREST
PVC BACKREST WITH MESH SLING.
BOX WITH CASTERS AND SCREWS
4 CASTERS WITH BRAKES.
o

STEP 2 CASTERS.

E118-3TW-FF-SQ-PAIL
ASSEMBLY INSTRUCTIONS
DRILL THROUGH LEG
PIPES USING 1/8 DRILL
BIT AND PILOT HOLES
AS REFERENCE.
SECURE USING 1/2''
RETAINING SCREWS
AND PILOT HOLES AS
REFERENCE.
STEP 1 – CASTERS
INSERT CASTER LEG STEMS INTO BASE SECTION
STEP 3 BACKREST & MESH SLING
INSERT PVC BACKREST INTO T-FITTING LOCATED ON
ARM SECTIONS.
