NOTE: A PHILLIPS SCREWDRIVER OR A CORDLESS HAND DRILL IS REQUIRED TO TIGHTEN/SECURE ALL SCREWS.
STEP 1 CASTERS.
STEP 2 – REMOVING DRAIN PAN & HOSE.
INSERT CASTER LEG STEMS INTO BASE SECTION.
DRILL THROUGH LEG PIPES USING 1/8 DRILL BIT AND
PILOT HOLES AS REFERENCE.
SECURE CASTERS USING ½'' RETAINING SCREWS.
STEP 3 ARMS.
INSERT ARMREST INTO SEAT SECTION.
SECURE USING ½'' RETAINING SCREWS. USING PILOT
HOLES AS REFERENCE.
323 East Owassa • Suite 4 • Edinburg, TX 78539 • 1-800-270-6199 • 956-781-5000 • Fax 956-781-5552
196-26-BAR – 196-30-BAR
Assembly Instructions
www.mjminternational.com • hmoroles@yahoo.com
IDENTIFY COMPONENTS TO START ASSEMBLY
SEAT SECTION.
ELEVATED LEGREST WITH CUSHION
RECLINING BACKREST WITH CUSHION
ARMS.
PUSH PULL HANDLE
COMMODE
SLIDING FOOTREST
MESH SLING WITH PAD
16 (SIXTEEN) ½'' SCREWS.
BOX WITH CASTERS AND SCREWS
2 CASTERS WITH BRAKES.
o
3 CASTERS NON BRAKE.
o
STEP 2 BACKREST.
INSERT RECLINING BACKREST.
SECURE USING ½'' RETAINING SCREWS. USING PILOT
HOLES AS REFERENCE.
STEP 4 PUSH-PULL HANDLE.
INSERT PUSH PULL HANDLE INTO BACK SECTION
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MJM 196-26-BAR
Summary of Contents for MJM 196-26-BAR
- Page 1 MJM International Corporation 196-26-BAR – 196-30-BAR Assembly Instructions "We Do Care - We Do More" IDENTIFY COMPONENTS TO START ASSEMBLY SEAT SECTION. ELEVATED LEGREST WITH CUSHION RECLINING BACKREST WITH CUSHION ARMS. PUSH PULL HANDLE COMMODE SLIDING FOOTREST MESH SLING WITH PAD 16 (SIXTEEN) ½’’...
- Page 2 MJM International Corporation "We Do Care - We Do More" STEP 5 PUSH-PULL HANDLE STEP 6 SLIDING FOOTREST. CENTER SLIDING FOOTREST UNDER FRAME AND SECURE USING ½’’ RETAINING SCREWS. USING PILOT INSERT PVC PIPE INTO 4-WAY FITTINGS. HOLES AS REFERENCE.
- Page 3 MJM International Corporation CARE INSTRUCTIONS "We Do Care - We Do More" PVC PIPING AND CASTERS Wipe down piping with non-abrasive cleanser. DO NOT use solvents. Restore luster with Johnson’s Pledge or similar spray wax. If casters are used in wet environment, keep lubricated with white lithium paste or similar lubricant; remove hair and mop- thread build up.
