NUREVA™ WALL
INSTALLATION GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the WALL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nureva WALL

Summary of Contents for Nureva WALL

  • Page 1 NUREVA™ WALL INSTALLATION GUIDE...
  • Page 2 WARNING: Failure to provide adequate structural strength for the wall mount can result in serious personal injury or damage to property. The anchors and wall to which this equipment is attached can support four times the combined weight of all equipment. Ensure the wall structure is reinforced as required before installing the equipment.
  • Page 3 Important SAFETY WARNINGS NOTICE: This projector is a Class 2 laser device that conforms to IEC 60825-1: 2007 and CFR 1040.10 and 1040.11. Except for deviations to Laser Notice No.50 dated June 24 2007. FCC NOTICE This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules.

  • Page 4: Table Of Contents

    Table of contents BEFORE YOU BEGIN What’s in the box You must supply INSTALLATION — RECOMMENDED STEPS TO A SUCCESSFUL SETUP 1. Determine the installation location 2. Install the system 3. Initial adjustment of the projected image(s) 4. Connection your system (connection diagrams) 5.

  • Page 5: What's In The Box

    D - Wall spacers I - Washers © 2018 Nureva Inc. All rights reserved. Nureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countr L - Bottom end caps B - Covers G - RS232 to 3.5mm cable...

  • Page 6: You Must Supply

    To install the system successfully, you need to provide the following items. Go through these checklists and ensure everything is on hand before you begin to install the system. U - Wall mount cover (L/R) V - Wall mount plate...

  • Page 7: Determine The Installation Location

    ″ (227 cm) 24 lb. *Projector and (10.9 kg) wall mount weight : The surface the system is mounted on is capable of supporting 4 times the weight of the system. 75 lb. (34 kg) *Touch panel weight...

  • Page 8: Install The System

    Install the system Install the projector wall mount plate(s) 45.85in 89.21in 43.52in 2.1.1 1165mm 2266mm 1106mm 1.12in 29mm Refer to the installation PROJECTOR MOUNTING PLATE NPT-1 WALL BRACKETS drawing included in the projector box. MIN 254mm [10in] MIN 254mm [10in]...
  • Page 9 2266mm [89 1/4"] TO NEXT PROJECTOR TO NEXT PROJECTOR REFERENCE HOLE REFERENCE HOLE UREVA WALL Drill out the projector wall plate ON TEMPLATE PROJECTOR MOUNTING PLATE REFERENCE HOLE holes marked on the template 38mm [1.5"] HOLE FOR WIRE DROP using a ¼″ drill bit.
  • Page 10 Install the wall anchors according to the manufacturer instructions. Where possible, secure the wall mount plate to a wall stud. Install the wall mount and projector 2.2.1 Attach the projector plate(s) with four of the screws provided.
  • Page 11 Repeat with any remaining wall mounts and projectors. 2.2.5 Projector power RS232 to 3.5mm cable Attach the cables from the RS-232 RS-232 wall mount to the back of the Audio In Audio In Audio Out Audio Out Audio L Audio L Audio R...
  • Page 12 Use a level to make sure the marks are in-line. Refer to installation measurement  on your installation drawing. 2.3.2 Attach the brackets to the wall Wall bracket using the recommended wall anchors. Wall spacer Use the optional spacers if you're running cords behind the touch panel.
  • Page 13 Do not center the touch panels to the projector. 2.3.5 Mark where the adjustment feet land on the wall – there are two adjustment feet locations for each touch panel. 2.3.6  Slide the touch panel on the 74lb.
  • Page 14 Tighten the nuts. 2.3.9 Mount the top joiner plate and lightly screw in the screws. December 2018 © 2018 Nureva Inc. All rights reserved. Nureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries.
  • Page 15 © 2018 Nureva Inc. All rights reserved. Nureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries. Page 3 of 4 Connect the hardware 2.4.1...
  • Page 16 2.4.2 Daisy chain the boards together by connecting the USB A USB A-B cord to the ports on the control module of one USB B touch panel to the next. Repeat for each touch panel. 2.4.3 Connect the last touch panel to the computer using another USB B USB A-B cord.
  • Page 17 33.6 kg www.nureva.com/support 13.1 © 2018 Nureva Inc. All rights reserved. Nureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries. Page 4 of 4 Snap on the front panel covers. Span...

  • Page 18: Initial Adjustment Of The Projected Image(S)

    3. Initial adjustment of the projected image(s) 3.1.1 Power on your projector. Powering on your projector without video input will bring up the Nureva splash page. Use the splash page for the initial adjustment of your projected image. 3.1.2 ...
  • Page 19 1 0 1 4 0 2 - 0 2 1 0 1 4 0 2 - 0 2 d. Nureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries. Page 2 of 4...

  • Page 20: Connection Your System (Connection Diagrams)

     74lb. 74lb. 33.6 kg 33.6 kg December 2018 1 0 1 4 0 2 - 0 2 ureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries. Page 3 of 4...
  • Page 21 Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries. © 2018 Nureva Inc. All rights reserved. Nureva and the Nureva logo are trademarks of Nureva Inc. in the United States, Canada and other countries.

  • Page 22: Adjust The Projected Image And Touch

    Windows display manager is set to 1920 x 1016. 5.2 Download software 5.1.1 Navigate to the Internet. Download the Nureva Room Manager and Span Workspace from the downloads page at www.nureva.com/support 5.3 Nureva Room Manager 5.3.1 13.1...
  • Page 23 5.3.2 For dual or triple configurations, go to System matching in the Nureva Room 13.1 Manager. Follow the on-screen instructions to complete system matching. For single systems, proceed to the next step. 5.3.3 13.4 Go to Image alignment in the Nureva Room Manager.
  • Page 24 5.4 Launch Span Workspace 5.4.1 Launch Span Workspace. 1:41 PM 5/11/2018  74lb. 33.6 kg 1 0 1 4 0 2 - 0 2 Page 2 of 4 December 2018...

  • Page 25: Install The Hdl300 Audio Conferencing System

    6. Install the HDL300 audio conferencing system 6.1 Single system 9 ½" (242 mm) To projector reference hole 6.2 Double system 15 ¾ (400 mm) From centerline to drill hole 9 ½" (242 mm) To projector reference hole 7 ⅝" (195 mm) From top of board Between touch panels December 2018...
  • Page 26 Troubleshooting For troubleshooting, please see our Customer support portal. support.nureva.com December 2018...
