  • Page 1 Nureva™ Wall System WM408i User manual...
  • Page 2: Table Of Contents

    Contents Touch panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Touch panel features Cleaning your touch panel Wall mount adjustments .
  • Page 3 Installing and cleaning the dust filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Regulation and safety notices .
  • Page 4: Touch Panel

    Page 3 of 4 Page 2 of 4 Page 2 of 4 1 0 1 4 0 2 - 0 2 ogo are trademarks of Nureva Inc. in the United States, Canada and other countries. RS232 3.5mm RS232 - 3.5 mm Provides projector-control from the Nureva control module panel presence-detect and power button.
  • Page 5 Upper Lower power power +5VDC Provides power to the Nureva control module. There is an alternate power connection port along the bottom connection panel.  74lb. 33.6 kg USB A USB B 1 0 1 4 0 2 Page 2 of 4...
  • Page 6: Cleaning Your Touch Panel

    See the LED state map in the appendix for details. Page 2 of 4 Cleaning your touch panel Use dry-erase cleaner, or a damp cloth to clean the WM408i touch panel. Avoid abrasive cleaning agents such as a scrubbing sponge. September 2019...
  • Page 7: Wall Mount Adjustments

    Use this adjustment when the left or the right of the image is larger or smaller and in a perspective shape. : Once the above mechanical adjustments are complete, use the Wall display system tools in the Nureva Room Manager software to fine-tune the landed image. September 2019...
  • Page 8: Projector Connections

    Projector connections Audio Composite RS232 in/out audio/video Power Wi-Fi/Media Network VGA out HDMI VGA 2 1&2 Mini USB Connection Feature functions Microphone In Pass through to projector 10W internal speaker Audio In/Out Loop through Composite video L/R audio VGA 1 Video input VGA Out/VGA 2 Third-party pass-through display...
  • Page 9: Control Panel

    5.  Cancel: Exit a menu or cancel a selection 6.  Volume: Adjust the volume level for the projector’s speaker 7.  Mute: Mute the sound from the projector’s speaker 8.  Calibrate: (not yet supported by Nureva Room Manager) 9.  Enter: Confirm your item selection September 2019...
  • Page 10: Projector On-Screen Display Menu

    Projector on-screen display menu The projector has multilingual OSD menus that allow you to make image adjustments and change a variety of settings. Navigating the menu To access the OSD, press the menu button on the projector remote control or control panel. Use the arrow buttons on the projector remote or control panel to navigate the main menu on the left-hand side.
  • Page 11: Picture

    Use the left and right arrows to adjust the sharpness own custom color mode: of the image. • Nureva Wall – Color matching for dual displays (default) Saturation – video mode only Adjust the image from fully saturated color to black •...
  • Page 12 Color settings The color settings are sensitive and easy to unbalance. Adjust the picture settings before considering these adjustments. Color Saturation Choose which color to adjust on the screen (Red, Adjust the intensity of the selected color using the Green, Blue, Cyan, Magenta or Yellow). left and right arrows.
  • Page 13: Screen

    The range of movement will vertical pixels depend on the image source. 17:9 – The default aspect ratio for the Nureva Wall V. Position image mode Adjust the vertical position of the image using the left 4:3 –...
  • Page 14: Settings

    Settings Language VGA 2 (Function) Switch the OSD to a different language: Input – Choose Input to allow the VGA port to work • Press the right arrow to enter the submenu as a VGA input function. • Use the up and down arrows to select the Output –...
  • Page 15: Volume

    Volume Volume Control the following: • Speaker • Line out • Microphone • Mute • Volume • Microphone Volume September 2019...
  • Page 16: Options

    Options Auto Source High Altitude • On – The projector will search for other On – The built-in fans run at high speed. Select this signals if the current input signal is lost option when using the projector at altitudes above •...
  • Page 17: Lan

    Main Menu - LAN Status Display the network connection status Display the DNS number DHCP MAC Address Configure the DHCP settings. Choose On to let the Display the MAC address projector obtain an IP address automatically from Group Name your network. Choose Off to assign IP, subnet mask, Display the group name gateway and DNS configuration manually.
  • Page 18: Source

    Signal Processing Source Source Menu By Default, se Change 'MUL Source Access the input Source menu by pressing the Input Source button on the remote or projector control 頁 0 panel. • VGA-1 • VGA-2 • HDMI-1 • HDMI-2 • Video •...
  • Page 19: Multimedia

    Multimedia Project media files (photos, videos, music, documents) stored on the following devices: • Nureva-approved wireless dongle – Wirelessly access the media files stored (available through your reseller) on your mobile phone, tablet, PC, notebook or desktop • USB flashdrive – Directly access the media files stored in the device How to access multimedia mode: 1.  Plug the wireless dongle for your system (available from through your reseller), or USB flash drive into...
  • Page 20: Laptop Display

    Laptop display 1.  On multimedia menu, select Laptop 2.  Enable your laptop or notebook Wi-Fi function, and search the AP name listed in the Wi-Fi network list 3.  Enter the password when prompted 4.  Open your web browser and enter the IP address 5.  Select Wi-Fi on the left side of the screen and install the application required by the operating system 6.  Launch the EZview application and enter the control code shown on the bottom right side of the screen 7.  Wait until the connection is established.
  • Page 21: Usb Storage Display

    USB storage display 1.  On the multimedia menu, select USB Disk 2.  Use the arrow keys to select the file category and press Enter 3.  Use the arrow keys to select the file to view or play and press Enter to confirm Configuring multimedia display settings 1.  On the multimedia menu, select Settings 2.  Use the arrow keys to choose the desired menu option and press Enter to access the submenu for your...
  • Page 22: Rs232 Commands

    RS232 commands RS232 port setting Items Method Communication method Asynchronus communication Bits per seconds 19,200 Data bits 8 bits Parity None Stop bits Flow control None RS232 signals connection RING RING September 2019...
  • Page 23: Commands Set List

    1 : Bright 2 : PC 3 : Movie Color Mode #0110 n 1 ~ 6 P / F 4 : Game 5 : Nureva Wall 6 : User” Brightness #0111 n 0 ~ 100 P / F Contrast #0112 n...
  • Page 24 Write commands Command description ASCII command Value (n) Projector response Resulting control “0: Zoom - Zoom In/Out #0121 n 0 / 1 P / F 1: Zoom +” Keystone settings #0122 n -40 ~ 40 P / F 1 : Front 2 : Rear Display orientation #0123 n...
  • Page 25 = Firmware Version System information #01162 n Okabbbbbccdddee e = Color mode (1- Bright; 2 - PC; 3 - Movie; 4 - Game; 5- Nureva Wall; 6 - User)” Projector serial number #01163 n Okaaaaaaaaaaaaaaaa Serial number n = 0; Off...
  • Page 26: Wake-On-Lan (Wol) Requirements

    LAN function (Regulatory ErP Lot 26 Tier 3), the Standby power consumption drops from 3W to 2W. The Nureva projector supports a AM8250 Multimedia/LAN control chip which has a STDBY mode >2W, and to abide by this requirement, the chipset functionality requires a WOL (Wake On LAN) command prior to the Crestron/Extron commands for LAN standby mode.
  • Page 27: Crestron ® Room Control

    : RoomView’s function is set according to the products’ models and specifications. Crestron : In the Nureva Wall WM408i configuration, the RS232 port is used for projector-level control assigned to the Nureva Touch Panel for presence-detect WAKE/SLEEP. Therefore the RJ45 port must be used for Crestron Main Page extended Crestron-ready room control commands.
  • Page 28 Tool page Settings • IP Address • Projector Name • DNS Server • IP ID • DHCP • User Password • Port • IP Address • Admin Password Crestron Information Page • Group Name • Subnet Mask Item Value/Range Default •...
  • Page 29: Web Browser Projector Control

    Web browser projector control Enable web browser control on the projector Manage your projector settings over a web graphic user interface (GUI) using the steps in this section. : This feature requires connection to a network through the RJ45 port. 1.  On the Network settings page in the projector’s OSD, turn on DHCP 2.  Open your browser and type in the IP address assigned to the projector as shown in the Network Settings in the OSD...
  • Page 30: Lan Setting

    LAN Setting LAN setting Setting Default DHCP IP Address 10.0.21.200 Subnet Mask 255.255.0.0 Item Value/Range Default Remark Gateway 10.0.0.254 DHCP On/Off 0.0.0.0 Group name GROUP IP Address TDB with connection 10.0.21.200 Projector name PROJECTOR Subnetmask TDB with connection 255.255.0.0 Location LOCATION Gateway TDB with connection...
  • Page 31: Projector Status And Control

    Projector Status and Control Projector status and control Setting Value/range Default Projector Status On/Off/Powering/Cooling Input HDMI1/HDMI2/VGA1/VGA2/Composite/Multimedia Logo Default/User Default Ceiling Mount Front/Front ceiling/Rear/Rear ceiling Front ceiling High Altitude On/Off Auto Source On/Off LASER Power Mode Normal/ECO Normal Auto Power Off (min) 0~120 (step: 5) Color Mode PC/Bright/Movie/Game/User...
  • Page 32: Email Alert

    E-mail Setting Email alert Setting Default E-mail alert Disabled Item Value/Range Default Remark E-mail Alert Enable/Disable Disable From Subject User input Null Outgoing SMPT server User input Null Username From User input Null Alert Condition Empty Subject User input Null Out going SMPT Server User input Null...
  • Page 33: Video Compatibility Modes

    Video compatibility modes VGA analog continued VGA analog a. PC signal b. Extended wide timing Modes Resolution V. Frequency H. Frequency Modes Resolution V. Frequency H. Frequency (Hz) [Hz] (Hz) [Hz] 640 x 480 31.5 1280 x 720 44.8 640 x 480 35.0 1280 x 800 49.6...
  • Page 34: Hdmi Digital Continued

    HDMI digital HDMI digital continued d. PC signal e. Extended wide trimming Modes Resolution V. Frequency H. Frequency Modes Resolution V. Frequency H. Frequency (Hz) [Hz] (Hz) [Hz] 1280 x 720 44.8 640 x 480 31.5 1280 x 800 49.6 640 x 480 35.0 WXGA...
  • Page 35 We recommend cleaning the filter annually. If you are operating the projector in a dusty environment, we recommend cleaning the filter after every 2,500 hours of use. New filters can be ordered via orders@nureva.com using the service part number SRV-FILTER. Before you begin, turn the projector off and unplug the power cord.
  • Page 36 Regulation and safety notices FCC Notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 37 Regulation and safety notices Declaration of Conformity for EU countries • EMC Directive 2004/108/EC (including amendments) • Low Voltage Directive 2006/95/EC • R & TTE Directive 1999/5/EC (if product has RF function WEEE Statement To return any product for proper treatment and recycling, contact your local authority or your local reseller. SAFETY WARNINGS AND IMPORTANT INFORMATION September 2019...
  • Page 38 PRÉCAUTIONS DE SÉCURITÉ INFORMATION IMPORTANT September 2019...
  • Page 39 Appendix LED state map Projector SSI WM408i (all models) Operating mode Power Temperature Control Module indicator indicator indicator NTP-1 Stand-by Red - Solid White - Solid Start-up Red - Blink Blue - Blink Operational Blue - Solid Blue - Solid...
