- Page 1 E0501-07002 Portable Air Conditioners User Manual...
- Page 3 Warranty Limited Warranty BougeRV provides a one-year warranty for customers who purchase on BougeRV Amazon store and the BougeRV official website. Warranty Period The warranty starts from the date of purchase by the original purchaser. Please provide the screenshot of the order from Amazon or the website in order to affirm the warranty start...
- Page 4 · Product damage caused by the consumer not following the recommendations. · Damage caused by disassembling the machine without authorization or maintained by a non-designated mainte- nance site. · Products purchased neither on BougeRV Amazon store nor BougeRV's official website.
-
Page 5: Table Of Contents
Table of Contents Product Introduction ---------------------------------- 1 Package List ---------------------------------- 2 Product Safety Guidelines ---------------------------------- 3 Preparation Before Use ---------------------------------- 4 Operating Instructions ---------------------------------- 6 Error Code & Troubleshooting ---------------------------------- 7 Cleaning Tips ---------------------------------- 9 Specifications ---------------------------------- 9 FAQs ---------------------------------- 10... -
Page 6: Product Introduction
Product Introduction Exhaust Air Outlet Control Panel Cooling Air Outlet Exhaust Air Inlet Cooling Air Inlet Pipe Drain Power Input Cooling Air Cycling Exhaust Air Cycling... -
Page 7: Package List
Package List Check the package and make sure you receive all accesso- ries. If any of these is missing, please feel free to contact us via service@bougerv.com E0501-07002*1 360W AC Adapter*1 24V DC Power Cord*1 E0501-07001 Portable Air Conditioners User Manual... -
Page 8: Product Safety Guidelines
Product Safety Guidelines 1. The rated voltage of this product is DC 24V, and it cannot be directly connected to AC power at any time. 2. Do not let children operate alone. 3. Do not allow any items to be inserted into the air holes, it will cause product failure. -
Page 9: Preparation Before Use
Preparation Before Use 1. Plug The Power Plug 110V/220V power with 24V AC adapter. Plug directly to a 24V DC power with the included DC power cord. 12V/24V inverter: Connect to the 24V port with DC power cord, the other 12V port is connected to 12V DC power. - Page 10 The water outlet of the drain pipe must be lower than the bottom of the air conditioner, it will cause poor drainage. If you want to move the air conditioner after use, we suggest you tilt it slightly to the rear to drain the condensed water, so as to prevent the water from wetting other objects.
-
Page 11: Operating Instructions
Operating Instructions 1. Fan Mode 5. Cooling Icon 2. "+" Button 6. Temperature 3. "-" Button 7. Fan Icon 4. Power Button 8. Fan/Cooling Mode Switch -- Long press 3s to turn on/off -- Switch between fan mode (compressor does not turn on) and cooling mode -- Adjust the fan speed in three gears -- Increase or decrease the temperature. -
Page 12: Error Code & Troubleshooting
1. Every turn on the air conditioner, it defaults to the state of the last turn-off. 2. The temperature flashing indicates that it is being set. Hold the "+/-" button can increase or decrease the tem- perature continuously. After the flashing is stopped, it will exit the setting state. - Page 13 Phenomenon Measure Check whether it is set to the cooling mode and whether the temperature setting is too high. The temperature range of the air conditioner is 16-30 degrees. When the ambient temperature reaches the No cool enough setting, the compressor and fan will stop running. When the ambient environment is lower than 16 degrees, the air conditioner does not turn on, which is normal.
-
Page 14: Cleaning Tips
2. When not in use for a long time, the power should be unplugged and the water should be drained. 3. Keep away from fire. Specifications Model: E0501-07002 Cooling capacity 2899BTU Rated Voltage 24V DC Rated Current Refrigerant... -
Page 15: Faqs
Q3: In addition to tent cooling, can I use the air condi- tioner for indoor or more scenes? A: Different from the most room or portable air conditioners, the E0501-07002 is not designed to cool an entire room to a set temperature. It is made for more personal comfort for you.
