Table of Contents About This Document ................. 4 Compliance Information ................5 Important Safety Instructions ..............7 Usage Notice ......................7 Precautions....................... 7 Warnings ........................9 Installation Tips ..................10 Product Overview ..................11 Key Features ......................11 Unpacking .......................11 Package Contents ....................12 Product Setup and Use ................
Page 3
Optional Accessory Installation ..............28 Installing the Stand ....................28 Routing the cables ....................29 Installing the optional LCM ..................30 Installing the optional MSR ..................30 Cleaning ......................... 31 Solutions to Common Problems ................32 Warranty Information ....................33 RoHS Declaration ....................
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of MicroTouch a TES Company.
Compliance Information For FCC (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 6
Renseighements relatifs à la conformité Pour la FCC (États-Unis) Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe B selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
Important Safety Instructions Before using this monitor, please read the user manual thoroughly to help protect against property damage and to ensure your personal safety and the safety of others. Be sure to observe the following instructions. For installation or adjustment, please follow the instructions in this manual and refer all servicing to qualified service personnel.
Page 8
Avis d’utilization Mise en garde Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à la terre. Précautions Veuillez suivre toutes les mises en garde, précautions et entretiens recommandés dans ce manuel d’utilisation pour maximiser la durée de vie de votre unité.
Warnings To turn off monitor power, press “Power” on the OSD (front, bottom right). When turning off the monitor by pressing the POWER button, the main power of the monitor is not turned off completely. To disconnect power completely, remove the power plug from the outlet. If any of the following occur, remove the power plug from the outlet immediately: the monitor is dropped;...
Installation Tips No Touch Screen Drivers Required MicroTouch Touch Monitors are plug and play when connected to Windows 7 or later Windows devices; Kernel 3.2 for most builds of Linux; Android 1.0 and most other modern Operating Systems. If you have a non-Plug and Play operating system, please refer to the Technical Support Section of www.microtouch.com or contact MicroTouch Technical Support to inquire about driver support for your particular operating system.
Package Contents Part Picture LCD Monitor AC Power Cord IEC C15/C16 (1.8 m) AC-DC adapter VGA cable (1.8 m) USB A to B cable (1.8 m) Audio Cable (1.8 m) Stand...
Product Setup and Use Input and Output Connectors Power and Audio Connectors DC Jack: Power connector (Center pin: + 12 vdc; Barrel: ground). LINE IN: Audio input connector Video Signal Input Connectors DP (Display Port): Digital video input. HDMI: Digital video input. VGA: Analog video input.
Turning the Monitor On and Off Turning the monitor On: Connect the monitor to DC power. If the monitor does not come on within a few seconds, press the power button on the OSD keypad, the far-right button of the OSD keypad outlined in red below. When the monitor is on, pressing the Power button will open a pop-up that asks if the monitor is to be turned off.
On-Screen Display (OSD) Button Normal Video Display When OSD Menu is Displayed Activate the main menu Exit selection / Exit OSD Brightness Adjust Menu Up / Adjust Up Mute Audio Menu Down / Adjust Down Select Video Source Select the highlighted item Power on / Power off...
Locking the OSD and Power button functions Lock OSD prevents all the monitor settings from being changed. When this function is activated, all OSD controls and hotkey operations will be disabled except for the Power button. Lock Power button Prevents monitor from being turned off by the Power button. The monitor will power on automatically when power is applied.
Page 17
Picture Menu This menu is used for making common image adjustments. Note that some of the adjustments may be grayed out, indicating that they are not selectable. This indicates the use of a digital video input signal (DP, HDMI or USB Type-C). These selections are fixed/not adjustable for digital video signals. The VGA video signal (because it is analog) may require all adjustments, so they are all selectable when VGA is being used.
Page 18
V-Position Adjust the vertical position of the picture. Press or to select the desired level, and then press SELECT. Selectable only when VGA input is in use. Range: 0-100 Phase Adjust the pixel phase of the picture. Press or to select the desired level, and then press SELECT.
Page 19
Advanced Menu This menu is used to adjust color temperature and image sharpness. Color Temp Select the color temperature Options: 5500K, 6500K, 7500K, 9300K, User Adjust the amount of red in color content Range: 0-100 Green Adjust the amount of green in color content Range: 0-100 Blue Adjust the amount of blue in color content...
Page 20
OSD Menu This menu is used to make set-up adjustments to the OSD itself, as well as other on-screen messages. OSD Timeout Adjusts the time in seconds before the OSD menu disappears after no usage. Range: 0-60 sec OSD Position Selects the OSD Position (center or corners).
Page 21
Option Menu This menu is used select or display various functions. Reset Restore the factory default settings. Options: Yes, No Language Select the OSD language Options: English, French, Deutsch, Italian, Spanish, Japanese, Traditional Chinese and Simplified Chinese Source Select Select the Video Input Source Options: Auto, VGA, HDMI, DP Display Mode Display the current video source and resolution information.
OSD Default Settings Note: N/A applies when a digital video input (DP or HDMI) is in use Menu Parameter Default Settings Contrast Brightness H-Positon Picture V-Positon Phase Clock Auto Adjust Color Temp User Advanced Sharpness OSD Timeout OSD Positon User OSD H-Positon OSD V-Positon Reset...
Mounting options The monitor may be mounted to a stand or other device that has a 100mm x 100mm standard VESA mount hole pattern. VESA Mount The monitor has an integral VESA standard mount pattern that conforms to the “VESA Flat Display Mounting Interface Standard”...
Optional Accessory Installation Note: Power the monitor down before installing/ removing accessories. Installing the Stand Step 1: Engage the hooks at the top of stand first. Step 2: Push lower part of the stand to the touch monitor and install the two screws. Removing the stand Loosen the screws at the bottom of the stand, rotate the stand upward and pull the stand away from the monitor.
Routing the cables Pull the lower rear cover of the stand downward, then lift it away from the stand. Attach the cables, then place the cover on the stand and push it upwards to secure it.
Installing the optional LCM Gently pry the top accessory cable upward and remove the cover. Push the LCM into place. Secure with the two included screws. Installing the optional MSR MSR installation is similar except it installs on the left side port. No screws are required; it simply snaps into place.
Appendix Cleaning Turn off the product and disconnect from AC power before cleaning. Turning the product off protects against accidental touch selections that could cause problems or hazardous results. Disconnecting power protects against hazardous interaction between accidental liquid entry and electricity. To clean the case, dampen a clean cloth lightly with water and a mild detergent and wipe gently.
Solutions to Common Problems No image on monitor Check that the video signal source device is turned on. Check that the selected video input signal matches the video connection. The monitor or computer may be in SLEEP mode. Press any key/move the mouse/touch the touchscreen and wait a few seconds to see if the image appears.
Warranty Information Except as otherwise stated herein, or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchscreen display and their components is three years. Seller makes no warranty regarding the model life of components.
