- Page 1 User Manual Version 10.2 2018/05 TDS-32F Touch Monitor TDS-32F-Lite standard version...
- Page 2 TES reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of TES to notify any person of such revisions or changes.
- Page 3 Compliance Information For FCC (USA) This equipment has been tested and fund to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. There limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Usage Notice Warning - To prevent the risk of fire or shock hazards, and do not expose the product to moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions follow all warnings, precautions and maintenance as recommended in this user’s Please manual to maximize the life of your unit.
-
Page 5: Table Of Contents
Table of Contents Chapter 1 ........................5 1.1 Overview ........................6 1.2 Feature ........................6 1.3 Specifications ......................6 1.4 Block Diagram......................7 1.5 Interface Connectors ....................8 1.5.1 Power Connector ....................8 1.5.2 Video Signal Connector ..................8 1.6 Package Overview ....................10 Chapter 2 ........................ -
Page 6: Chapter 1
Chapter 1 Product Introduction... -
Page 7: Overview
1.1 Overview TDS-32F series supports landscape or portrait and low power consumption at the maximum consumption of 70W. TDS-32F provides application for Interactive whiteboard and digital signage. 1.2 Feature VESA mounting holes for various mounting options. Multilingual OSD user control ... -
Page 8: Block Diagram
1.4 Block Diagram This section describes the electrical requirements of the monitor. The block diagram in figure 1 illustrates the various electrical sub-systems. -
Page 9: Interface Connectors
1.5 Interface Connectors 1.5.1 Power Connector The monitor shall have a power control switch visible and accessible on the bottom of the monitor. The power switch shall be marked with icons per IEC 417, #5009. The operation of the power switch should be programmable thru monitor firmware control. - Page 10 The video signal input via HDMI female connector. Connector Pin Assignment: Signal Signal TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock– TMDS Data2– TMDS Data1+ Reserved (N.C. on device) TMDS Data1 Shield TMDS Data1– TMDS Data0+ DDC/CEC Ground TMDS Data0 Shield +5V Power TMDS Data0–...
-
Page 11: Package Overview
This product is intended to be supplied by a AC-in Power source, rated 100V~240V, 1.2A 50/60Hz minimum, Tma = 40 degree C minimum, and the altitude of operation = 3048m minimum. If it needs further assistance with purchasing the power source, please contact to TES for further information. -
Page 12: Chapter 2
Chapter 2 Product Installation... -
Page 13: About Vesa Mount
2.1 About VESA Mount “VESA Flat Display Mounting Interface The TDS-32F series conform to the Standard” which defines a physical mounting interface for touch monitor and corresponding with the standards of touch monitor mounting devices. The VESA mount is located on the back of this unit. -
Page 14: Install The Vesa Screw
2.1.1 Install the VESA screw Note: Please install/ dismantle the product when the device is in the shutdown state. Step 1: Fasten two M5 screws nut into the VESA hole The length of screw nut is 30mm Step 2: Fasten four M5 screws into the VESA hole The specification of screw is M5 x 8mm... -
Page 15: About General Mounting Information
2.2 About General Mounting Information The following two mounting orientations are supported: Landscape and portrait mode. For optimal touch performance, ensure that the monitor is supported fully and is as flat as possible. 2.2.1 Landscape 2.2.2 Portrait... -
Page 16: On-Screen Display
2.3 On-Screen Display The TDS-32 Lite series provide side panel controls. And the following is OSD function table: Menu off status Menu on status Menu disappear/ return to main MENU Menu appear item ▲ Brightness Main item select up/ Adjust up Main item select down/ Adjust ▼... - Page 17 Please note: 1. When the OSD Lock function is selected, this indicates that all the buttons except “power” button are now disabled. 2. When the Power Lock function is selected, this indicates that the power key is disabled; user can not to turn off the monitor by "Power" key. 3.
-
Page 18: Osd Function Description
2.3.1 OSD Function Description ITEM CONTENT Default Contrast The monitor luminance level control. Brightness The monitor backlight level control. Automatically adjusts the screen image of VGA signal, Auto Adjust affecting the H-position, V-position, Frequency, and Phase menu. Left/Right Moving screen image horizontal position to left or right. Up/Down Moving screen image vertical position to up or down. -
Page 19: Timing Table Chart
2.3.2 Timing Table Chart Polarity MODE Resolution H-Freq. (KHz) Bandwidth (MHz) 31.47 25.175 VGA 640x480@ 60Hz 35.16 VESA 800x600@ 56Hz 37.88 VESA 800x600@ 60Hz 48.36 VESA 1024x768@ 60Hz 44.772 74.5 VESA 1280x720@ 60Hz 47.776 79.5 VESA 1280x768@ 60Hz VESA 1280x1024@ 60Hz VESA 1280x960@ 60Hz 106.5 VESA 1440x900@ 60Hz... -
Page 20: Dimension
2.4 Dimension 2.4.1 Front View 2.4.2 Side View... -
Page 21: Rear View
2.4.3 Rear View... -
Page 22: Appendix
