- Page 1 627 Amersale Drive Naperville, IL 60563 Phone: (800) 323-5664 Fax: (630) 897-0573 sales@belson.com Model # RPP22 Instructions Sheet SQUARE RECYCLED PLASTIC PLANTER www.belson.com...
- Page 2 BEFORE ASSEMBLY, PLEASE MAKE SURE ALL COMPONENTS ARE INCLUDED. FP - FASTENER PACK ( 1 ) - ONE FASTENER PACK ( 1 ) - ONE BOTTOM PLATE B - FRAME RING ( 2 ) - TWO FRAME RINGS ( 4 ) FOUR SIDE PANELS www.belson.com...
- Page 3 BEFORE ASSEMBLY, PLEASE MAKE SURE ALL FASTENERS ARE INCLUDED. 16 - #12 X 2 1/2” PAN HEAD PHILLIPS SCREW ALSO NEED FOR THIS ASSEMBLY WILL BE THE FOLLOWING MATERIALS: 1 - #3 PHILLIPS DRIVE BIT www.belson.com...
- Page 4 #12 X 2 1/2” PAN HEAD PHILLIPS SCREW STEP #1: AS SHOWN IN THE DIAGRAM ABOVE, PLACE ON SIDE PANEL FACE DOWN ON A FLAT SURFACE. PLACE THE FRAME RINGS AT THE TOP AND BOTTOM SECTIONS OF THE PANEL BEING SURE TO LINE UP THE PRE-DRILLED PILOT HOLES IN THE SIDE PANEL.
- Page 5 #12 X 2 1/2” PAN HEAD PHILLIPS SCREW STEP #2: PLACE ANOTHER SIDE PANEL BESIDE THE PREVIOUS PANEL SO THAT IT TOUCHES AS DISPLAYED IN THE DIAGRAM ABOVE. GENTLY TURN THE SIDE PANEL WITH THE RINGS INSTALLED ON TO THE NEW SIDE PANEL. MAKING SURE THE HOLES LINE UP WITH THE PRE-DRILLED PILOT HOLES IN THE NEW PANEL.
- Page 6 #12 X 2 1/2” PAN HEAD PHILLIPS SCREW STEP #3: REPEAT STEP #2. www.belson.com...
- Page 7 STEP #4: PLACE THE BOTTOM PANEL INTO THE OPENING BETWEEN THE FRAME RINGS. www.belson.com...
- Page 8 #12 X 2 1/2” PAN HEAD PHILLIPS SCREW STEP #5: REPEAT STEP #2. www.belson.com...
- Page 9 STEP #6: TURN THE PLANTER UPRIGHT ONTO ITS BASE. PLEASE USE CAUTION WHILE MOVING AS THIS PLANTER WILL WEIGH APPROXIMATELY 96 POUNDS. www.belson.com...
