- Page 1 CORDLESS FRAMING NAILER MODEL：SJ-GFKL1 IMPORTANT! OPERATING MANUAL DO NOT DESTROY •Read the manual from cover to cover before using the tool. •Follow all instructions in the manual. For More Information Including Your Nearest Service Agent Visit: www.spearandjackson.com.au...
-
Page 2: Table Of Contents
Subject Page Packing List Specifications Safety Instructions An Overview of Cordless Framing Nailer Battery and Charging system Fuel Cells Inserting Battery Fasteners Operation Clearing Jams End of Use Procedure Maintenance Troubleshooting Exploded View Drawing 13-14 Parts List REGISTER YOUR NAILER To ensure that your nailer is registered for the full Spear and Jackson warranty period, please provide your details as requested below. -
Page 3: Packing List
Packing List Specifications Model SJ-GFKL1 Description Quantity Weight 3.38Kg Dry Framing Nailer Dimensions 410mm L - 430mm W - 115mm H Allen Keys Goggles Cycle Rate 2-3 nails per second. No more than 1200 nails per hour or 5000 nails per day... -
Page 4: An Overview Of Cordless Framing Nailer
12. Keep the tool, fuel cell, battery and battery charger out of the reach of children. 13. Do not load or unload fuel cells while smoking, in or around naked flames or any ignition source 14. Don’t remove or disable the work contacting element. Don’t operate the tool if the work contacting element is disabled. - Page 5 Charger 1. Do not charge the battery outdoors! Only charge the battery in a dry environment. 2. The charger can only charge the 7.2V lithium rechargeable batteries with maximum capacity 2000mAH. Any use outside of these specifications may render the charger inoperable and cause serious damage to the battery.
-
Page 6: Fuel Cells
Fuel Cells Spear and Jackson recommends the use of Paslode Impulse Power+ Fuel Cell (B20543F) in this nailer. Average nails per fuel cell 1200 Fuel cell showing the correct right Fitting the Fuel Cell angle adaptor and valve stem 1. Lift the fuel cell door. 2. -
Page 7: Inserting Battery
Inserting the battery 1. Insert the battery in the battery receptacle until it’s locked. 2. Ensure the battery indicator light is illuminated. If the battery light does not illuminate, refer to the troubleshooting section . 3. When removing the battery, depress the locking tabs and withdraw the battery. -
Page 8: Fasteners
Fasteners/Nails Your Spear and Jackson nailer uses clipped head 34 degree paper collated framing nails from 2.87mm to 3.33mm in diameter and 50mm to 90mm in length. Using the incorrect nails will damage the tool and cause the nails to jam. (Not covered under warranty) An anti-dry fire feature is incorporated in this tool. -
Page 9: Operation
Removing Nails from the Magazine 1. Slide the magazine actuator to the end of the magazine 2. Depress the actuator release lever 3. Hold the nailer upright 4. The nails in the magazine will slide downward and out of the magazine Actuator release lever Operation cycle 1. -
Page 10: Clearing Jams
Clearing Nail Jams Note: Occasionally you may find that a nail will jam in the nailer. It is a simple task to clear a jammed nail. 1. Remove the battery and fuel cell 2. Remove any un-used nails from the magazine 3. -
Page 11: Maintenance
Maintenance Air filter cleaning Your Spear and Jackson is fitted with a highly efficient air filter. This will need to be cleaned after approximately 10,000 cycles/nails. For this you will need a small screwdriver. 1. Remove the battery and fuel cell Gently prise the air filter cover open. -
Page 12: Troubleshooting
Troubleshooting Before Using Symptom Possible Problem Solution 1 、 Press the metering valve on Improper installation of the metering Reinstall the metering valve, otherwise the fuel cell, no gas sprays out. valve. change to another metering valve or fuel cell. 2 、... -
Page 13: Exploded View Drawing
EXPLODED PARTS DIAGRAM... - Page 14 EXPLODED PARTS DIAGRAM...
-
Page 15: Parts List
Parts List Part# Description Part# Description Part# Description Air Filter Cover Safety Bracket Adjusting Stem Air Filter Spring pin Socket head Screw Belt Hook Bracket Cylinder Cap Bushing O-Ring spring Washer Work Contact Element (safety bracket) Washer Cylinder Cap Non Mar Tip Roll Pin 3*14 Circlip Circlip... - Page 17 PRODUCT REGISTRATION FORM Product code: SJ-GFKL1 Your name & address ------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- Contact Email: ---------------------------------------------------------- Contact phone number ---------------------------------------------------------- Nailer serial number ---------------------------------------------------------- Date of purchase ---------------------------------------------------------- Store where the nailer was purchased ----------------------------- ---------------------------------------------------------------------------------------------------------------------- Please mail this form including a copy of your store receipt to: Spear &...
