UNC-209SR-B QUICK INSTALLATION GUIDE
Major Components
Single PS/2 PSU
Internal 2.5" SSD x 2
Front Controls and Indicators
Front Panel Controls and Indicators
A. Power Switch
B. LAN1, LAN2 Activity LED
C. Power on LED
D. HDD Activity LED
E. System Reset LED
F. USB 2.0 port x 2
IN THIS YOU CAN TRUST
Internal 3.5" HDD x 2
Without front door
With front door
Rear Fan: 1x 80mm t 32mm(Option)
7x Low Profile PCI slots
(or 3x Full Height PCI slots
with optional bracket)
ATX M/B
(12"x 9.6")
Intrusion Switch (Option)
1x5.25" ODD+1x3.5" HDD
(or 3.5" FDD) Drive Bay
F
E
D
C
- 01 -
Rear Fan:
2x 40mm t 28mm
(Option)
B
A
Advertisement
Related Manuals for Chieftec UNC-209SR-B
Summary of Contents for Chieftec UNC-209SR-B
- Page 1 IN THIS YOU CAN TRUST UNC-209SR-B QUICK INSTALLATION GUIDE Major Components Rear Fan: 1x 80mm t 32mm(Option) 7x Low Profile PCI slots Internal 3.5” HDD x 2 (or 3x Full Height PCI slots with optional bracket) Rear Fan: 2x 40mm t 28mm...
- Page 2 Maintaining Front Door Filter 1. Unlock the front door and take out the filters to clean 2. Insert two filters on both left and right sides of the front door with four anchoring points Rear Window Configuration 3x Full Height PCI slots Standard I/O Opening with optional braceket Rear Fan...
- Page 3 Installing PS/2 power supply 1. Use two screws to fix bracket on the PSU 2. Slide the PSU assembly into the chassis, and use two screws to fix it on the left side of the chassis Installing Internal 2.5” SSD 1.
- Page 4 Installing Rear Fan (2 x 40mm t 28mm)(Option) Use two screws to fix the fan assembly (fan+ finger guard) on rear window Installing Intrusion Switch Use two screws to fix the intrusion switch with a bracket on the chassis IN THIS YOU CAN TRUST Arena Electronic GmbH Germany - 04 -...
