Casio IT-G400 Disassembly/Assembly

Hide thumbs Also See for IT-G400:

Advertisement

Quick Links

Download this manual
Precautions Before Disassembling Parts
• When reassembling the parts, reverse the disassembly procedures.
If [ Note on reassembling ] is stated, be sure to follow it.
• Use the right screwdriver according to the screw diameter.
• When disassembling or reassembling parts, do not pinch or damage wires.
• When reassembling FPC (cable), be sure that its orientation is correct. The contacts of the FPC are on one side
only.
Tool list
The following tools are necessary when replacing maintenance parts.
No.
1
#0 precision screwdriver (Phillips head)
2
#1 precision screwdriver (Phillips head)
3
Tweezers
4
Special screwdriver (Torx head)
Flow
1. Removing the LOWER CASE BLOCK
2. Removing the BRACKET BLOCK
3. Removing the MAIN PCB
4. Removing the IO ASSY
5. Removing the LCD BLOCK
Disassembling the UPPER CASE BLOCK
DISASSEMBLY/ASSEMBLY
Item
Disassembling the LOWER CASE BLOCK
Disassembling the BRACKET BLOCK
Disassembling the BRACKET/LCD
– 1 –
IT-G400 / VER.1
