TurtleRC Turtle Brain Model B
Instruction Manual
V2.0
WARNINGS
Keep your hands off the control sticks when powering on the Brain or Transmitter.
Always use a functioning killswitch if someone will be riding on your prop.
PRACTICE driving your prop in a safe area away from people until you understand how it
moves and reacts.
CHANGELOG FOR MODEL B
Model B does away with the fuse and power switch present on Model A, and instead employs a 50A
thermal circuit breaker. This provides the same protection as Model A but does not require a supply of
50A fuses. If a stall or other fault occurs once and the breaker trips, simply reset the breaker to activate
power. If the breaker keeps tripping, something is causing an over current issue that needs to be
corrected.
