DVD PLAYER REPLACEMENT (2ND ROW)

Tools Required
J 38778 Door Trim Pad Clip Remover. See Special Tools and Equipment.

Removal Procedure

IMPORTANT: Components of the DVD player cannot be serviced separately. Replace as an
assembly.
1. Move the screen to the open position.
2. Remove the rear screw cover using a flat bladed tool.
3. Remove the four retaining bolts (2).
4. Insert the J 38778 between the headliner and the DVD player assembly. See Special Tools and
Equipment.
5. With 1 hand holding the DVD player assembly, pry the retainer from the bracket.
many waters gallery
many waters gallery
Saturday, February 07, 2009 11:12:33 AM
Saturday, February 07, 2009 11:12:27 AM
2004 Chevrolet Suburban C1500
2004 Chevrolet Suburban C1500
2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV
2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV
Page 1
Page 1
© 2005 Mitchell Repair Information Company, LLC.
© 2005 Mitchell Repair Information Company, LLC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Suburban C1500 2004 and is the answer not in the manual?

Questions and answers

Related Manuals for Chevrolet Suburban C1500 2004

Summary of Contents for Chevrolet Suburban C1500 2004

  • Page 1 2004 Chevrolet Suburban C1500 2004 Chevrolet Suburban C1500 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV DVD PLAYER REPLACEMENT (2ND ROW) Tools Required J 38778 Door Trim Pad Clip Remover. See Special Tools and Equipment.
  • Page 2 2004 Chevrolet Suburban C1500 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV Fig. 83: Removing DVD Player Assembly Retaining Bolts (2nd Row) Courtesy of GENERAL MOTORS CORP. 6. Allow the DVD player assembly to come to rest on the hook.
  • Page 3 2004 Chevrolet Suburban C1500 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV Fig. 84: Allowing DVD Player Assembly To Rest On Hook (2nd Row) Courtesy of GENERAL MOTORS CORP. IMPORTANT: Observe the routing of the wiring harness (2). 7. Disconnect the wire connector (1).
  • Page 4 2004 Chevrolet Suburban C1500 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV Fig. 85: Disconnecting DVD Player Wire Connector (2nd Row) Courtesy of GENERAL MOTORS CORP. Installation Procedure 1. Install the DVD player hook (1) into the hook opening. many waters gallery...
  • Page 5 2004 Chevrolet Suburban C1500 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV Fig. 86: Installing DVD Player Hook (2nd Row) Courtesy of GENERAL MOTORS CORP. 2. Connect the wire connector (1) to the DVD player assembly. IMPORTANT: Ensure the harness is routed to the right side of the large plastic pin as shown (2).
  • Page 6 2004 Chevrolet Suburban C1500 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV Fig. 87: Connecting DVD Player Wire Connector (2nd Row) Courtesy of GENERAL MOTORS CORP. 4. Swing the rear part of the assembly to the headliner so that the retainer is seated.
  • Page 7 2004 Chevrolet Suburban C1500 2004 ACCESSORIES & EQUIPMENT Entertainment - C/K SUV 6. Move the screen to the open position. 7. Install the 2 front retaining bolts (2). Tighten: Tighten the 2 front retaining bolts to 9 N.m (80 lb in).
