Summary of Contents for Texecom Premier Elite Com300
- Page 1 Installation Manual Premier Elite Com300/Com2400 INS175-5...
-
Page 2: Regulatory Requirements
PSTN network termination point. In the event of problems, you should contact Technical Support at Texecom Ltd. The Premier Com300 and Com2400 digimodems have both been approved for the following usage: •... -
Page 3: Connection Status
Premier Elite Com300 & Com2400 Installation Manual Digimodem Features • 8 channel multi format digital communicator supporting Fast Format, Contact ID, SIA Level 2/3 and EasyCom Pager protocols • 6 Alarm Receiving Centre telephone numbers (up to 24 digits each) •... -
Page 4: Communicator Operation
Premier Elite Com300 & Com2400 Installation Manual Digimodem Layout Telephone Connections (TNV) Direct connection for telephone line (see page 6 for wiring details). RJ11 Socket (TNV) Alternative connection for telephone line. Connection Plug (SELV) Plugs into digimodem socket on top right hand corner of control panel. Operation... -
Page 5: Modem Operation
Premier Elite Com300 & Com2400 Installation Manual • Once the event has been successfully reported to the receiver, the receiver will send back an acknowledgement signal and the digimodem will shut down. The digimodem will then return to its normal mode Modem Operation The digimodem will monitor the telephone line for an incoming ringing signal;... -
Page 6: Telephone Line Connections
Premier Elite Com300 & Com2400 Installation Manual Telephone Line Connections To connect the telephone line, proceed as follows: Connection to the telephone network must be made via an NTE5 master socket (Line Box). Fit the rubber grommet supplied with the digimodem into the 20mm cable entry in the top right hand corner of the control panel. -
Page 7: Setting Up The Com Ports
Premier Elite Com300 & Com2400 Installation Manual All apparatus that requires access to emergency services (999 and 112) must be connected directly to the master socket. Devices that do not require access to these services such as faxes, modems and answer machines etc. can be connected to the extension sockets (see Note below). - Page 8 Premier Elite Com300 & Com2400 Installation Manual Programming the Com300 and Com2400 To program the Com300 or Com2400, proceed as follows: Enter into the Engineers Menu Select the Program Digi menu and press • Select the required ARC set •...
- Page 9 Premier Elite Com300 & Com2400 Installation Manual What will be sent as a Text Message The following information will be received in the text message: My Home N a m e p r o g r a m m e d i n t o p h o n e...
-
Page 10: Specifications
Premier Elite Com300 & Com2400 Installation Manual Specifications Operating Voltage 9 - 13.7V Current Consumption Quiescent 25mA When Active 80mA Communicator Protocols Fast Format Contact ID SIA Level 2/3 EasyCom Pager SMS Messaging (Com2400 only) Modem Protocol Com300 V.21 (300-baud) Com2400 V.21, V.22 or V.22bis (300, 1200 or 2400-baud) -
Page 11: Warranty
Texecom cannot accept responsibility or liability for any damages whatsoever based on a claim that the Premier Com300 or Com2400 failed to function correctly. Due to our policy of continuous improvement Texecom reserve the right to change specification without prior notice. - Page 12 Texecom Limited, Bradwood Court, St. Crispin Way, Haslingden, Lancashire BB4 4PW, England. Technical Support: UK Customers Tel: 08456 300 600 (Calls charged at 3.36 pence per minute from a BT landline. Calls from other networks may vary.) International Customers Tel: +44 1706 233875 Email: techsupport@texe.com...
