RT360W-D56 Wireless Broadband USB AP
ASKEY
's RT360W-D56 is 802.11g Wireless Access Point & USB Print Server
features and 1-port LAN . The 802.11g Access Point features allow PCs/Notebooks
with wireless card that adapts 802.11g technology to connect to the Ethernet. Through
the LAN connection to connect Local Area Network.
[Hardware Specifications]
Main Chip Sets
•
Processor: Broadcom BCM4702 125MHz R3000 MIPS32 CPU
•
54g (draft IEEE802.11g) Broadcom Radio
−
BCM4306 MAC and Baseband Processor
−
BCM2050 Radio
•
Memory
−
4MB Flash
−
16MB SDRAM
Interface
•
One 2.4GHz 54g RF interface for Wireless LAN connection
•
One 10/100 Mbps RJ-45 Ethernet LAN connection
•
Two USB 1.1 Ports for printer connection
Radio Characteristics
•
Standard: IEEE 802.11b (Wi-Fi) and 54g (draft IEEE802.11g)
•
Frequency Band (ISM Band):
−
2.412 ~ 2.4835 GHz
•
Spreading:
−
Direct Sequence Spread Spectrum (11-chip Barker sequence)
•
Modulation
−
OFDM: 54, 48, 36, 24, 18, 12, 9, and 6 Mbps
−
CCK: 11 , and 5.5 Mbps
−
DQPSK: 2 Mbps
−
DBPSK: 1 Mbps
•
Number of Channels:
−
802.11b : 1 - 11 (FCC),
June. 30, 2003
- 1 -
www.askey.com.tw
Rev: 0.0
Advertisement
Table of Contents
Related Manuals for Askey RT360W-D56
Summary of Contents for Askey RT360W-D56
- Page 1 RT360W-D56 Wireless Broadband USB AP ASKEY ’s RT360W-D56 is 802.11g Wireless Access Point & USB Print Server features and 1-port LAN . The 802.11g Access Point features allow PCs/Notebooks with wireless card that adapts 802.11g technology to connect to the Ethernet. Through the LAN connection to connect Local Area Network.
- Page 2 − 54g : 1 - 11 (FCC) • Data Rate: − 54 Mbps 48 Mbps 36 Mbps 24 Mbps 18 Mbps 12 Mbps 9 Mbps 6 Mbps − 802.11b 11 Mbps 5.5 Mbps 2 Mbps 1 Mbps • Antenna: −...
- Page 3 − 128 Bits Power and Operation Environment • Power Input: − 5 Volts DC, 2 A • Temperature − Operating: 0°C to 40°C − Storage: -10°C to 65°C • Humidity: − 5% to 80% (non-condensing) LED Indicators • POWER •...
- Page 4 - IP Finder utility • Find the IP address of print server and then link to print server's web management page. - Test button • A SW printing test button in print server's web management page. - 4 - June.
- Page 5 WARNING TEXT General purpose This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 6 Safety Information In order to maintain compliance with the FCC RF exposure guidelines, this equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Use only with supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations. Regulatory information / Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product.
