You should have:
All Assembly parts of VOYAGER Cage Shown for your reference
A*1
B*1
G*8
P1*1
P2*2
24x495
24x715
A. back wire mesh
B. front wire mesh
C. left side mesh
D. right side mesh
E. left &right top wire mesh
F. left&right open top mesh
VOYAGER
O
E*2
C*1
D*1
J*1
R *3
5
X *1
H.grill
I.metal tray
J. handle of tray
K.screw (dia=4mm L=5mm)
V. length seed guard piece
W.short seed guard piece
Assembly Instructions
F*2
H*1
M1*4
M6x40
S *3
Q*3
O*4
M1. screw (dia=6mm L=40mm)
M2.screw (dia=6mm L=35mm)
M3.screw (dia=6mm L=10mm)
P1. perch(short one)
P2. perch(length one)
K. screw (dia=4mm L=5mm)
It is recommended that two or three people assemble this cage
V*2
I*1
M2 *16
M3 *14
k*2
M4*5
M6x35
M6x10
O. wheels
Q .steel cup
R. handle of door
S. cup holder
N. Nut
U. hexagon wrench
X. wrench (screw all bolts)
W*2
N*12
U *1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Liberta VOYAGER
Summary of Contents for Liberta VOYAGER
- Page 1 VOYAGER Assembly Instructions You should have: All Assembly parts of VOYAGER Cage Shown for your reference M1*4 M2 *16 M3 *14 P1*1 P2*2 N*12 M6x40 M4*5 S *3 M6x35 M6x10 U *1 R *3 X *1 24x495 24x715 A. back wire mesh H.grill...
- Page 2 Step 1 M1*4 M2 *12 M3 *6 M6x40 M6x35 M6x10 R *3 S *3 Connect C to A&B with M1 on top and bottom, M2 in the middle position; Connect D to A&B as same step above; Insert wheels into the legs of cage.
- Page 3 Step 2 Step 3 M2 *16 M6x35 M4*5 close-up Fix J onto K with 2 of K as drawing Insert H and I into the position (as drawing) Connect 1 of F to A&B with M2 and loose M2(no screw up), meanwhile cycle 2 of G on each alxe of E,then insert alxe into the hole of A&B;...
- Page 4 Step 4 Step 5 M3 *6 M6x10 Put two protruding parts of W & V into cage body's holes,then keep holes on border of W & V aline, meanwhile insert M3 into the holes, screw up with N on other side(as close-up );...
