Modell der Diesellok BR 245
22450

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BR 245 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trix BR 245

  • Page 1 Modell der Diesellok BR 245 22450...
  • Page 3: Table Of Contents

    Inhaltsverzeichnis: Seite Sommaire : Page Informationen zum Vorbild Informations concernant la locomotive réelle Sicherheitshinweise Remarques importantes sur la sécurité Wichtige Hinweise Information importante Multiprotokollbetrieb Mode multiprotocole Hinweise zum Digitalbetrieb Remarques relatives au fonctionnement en mode digital Schaltbare Funktionen Fonctions commutables Parameter/Register Paramètre/Registre Wartung und Instandhaltung...
  • Page 4: Informationen Zum Vorbild

    Informationen zum Vorbild Information about the prototype Zur Ablösung der seit fast vier Jahrzehnten stark beanspruchten The German Railroad began several years ago to search for a sui- Diesellokomotiven der Baureihe 218 begann die Deutsche Bahn table replacement for the class 218 diesel locomotives that had schon vor einigen Jahren, nach geeignetem Ersatz zu suchen.
  • Page 5: Informations Concernant La Locomotive Réelle

    Informations concernant la locomotive réelle Informatie over het voorbeeld Pour remplacer les locomotives diesel de la série 218 qui, depuis Voor de aflossing van de reeds gedurende bijna vier decennia près de quarante ans, sont extrêmement sollicitées, la Deutsche zwaarbelaste diesellocomotieven van de serie 218 begon de Bahn s’est déjà...
  • Page 6: Sicherheitshinweise

    Priorität 2: DCC werden. Priorität 3: DC • Für Reparaturen oder Ersatzteile wenden Sie sich bitte an Hinweis: Wenn zwei oder mehr digital-Protokolle am Ihren Trix-Fachhändler. Gleis erkannt werden, wählt der Decoder automatisch das • Gewährleistung und Garantie gemäß der beiliegenden höchstwertige Protokoll. Wird z.B. mfx und DCC erkannt, Garantieurkunde. wählt der Decoder mfx.
  • Page 7: Hinweise Zum Digitalbetrieb

    Hinweis: Beachten Sie, dass nicht alle Funktionen in allen mfx-Protokoll Digital-Protokollen möglich sind. Unter mfx und DCC können Adressierung einige Einstellungen von Funktionen, welche im Analog- • Keine Adresse erforderlich, jeder Decoder erhält eine Betrieb wirksam sein sollen, vorgenommen werden. einmalige und eindeutige Kennung (UID). Hinweise zum Digitalbetrieb • Der Decoder meldet sich an einer Central Station oder • Die genaue Vorgehensweise zum Einstellen der diversen Mobile Station mit seiner UID automatisch an.
  • Page 8 DCC-Protokoll • Alle Funktionen können entsprechend dem Funktions- mapping geschaltet werden. Adressierung • Weitere Information, siehe CV-Tabelle DCC-Protokoll. • Mögliche Adressen: Kurze, lange und Traktionsadresse Es wird empfohlen, die Programmierungen grundsätzlich auf • Adressbereich: dem Programmiergleis vorzunehmen. 1 – 127 (kurze Adresse, Traktionsadresse) Logische Funktionen 1 – 10239 (lange Adresse) • Jede Adresse ist manuell programmierbar. Anfahr-/Bremsverzögerung • Kurze oder lange Adresse wird über die CVs ausgewählt. • Die Beschleunigungs- und Bremszeit können getrennt • Eine angewandte Traktionsadresse deaktiviert die von einander eingestellt werden.
  • Page 9: Schaltbare Funktionen

    f0 f8 f0 - f3 f4 - f7 Schaltbare Funktionen STOP mobile station Spitzensignal Funktion f0 Funktion f0 Geräusch: Puffer an Puffer — Funktion 1 Funktion f1 Funktion f1 Geräusch: Betriebsgeräusch — Funktion 2 Funktion f2 Funktion f2 Geräusch: Horn —...
  • Page 10: Parameter/Register

    Bedeutung Wert DCC ab Werk Adresse 1 - 127 PoM Minimalgeschwindigkeit 0 - 255 PoM Anfahrverzögerung 0 - 255 PoM Bremsverzögerung 0 - 255 PoM Maximalgeschwindigkeit 0 - 255 Werkreset/Herstellerkennung PoM Funktionen F1 - F8 im Analogbetrieb 0 - 255 PoM Funktionen F9 - F15 und Licht im Analogbetrieb 0 - 255 Erweiterte Adresse (oberer Teil)
  • Page 11: Safety Notes

    Note: If two or more digital protocols are recognized in the well as transferred along with the product to others. track, the decoder automatically takes on the highest value • Please see your authorized Trix dealer for repairs or digital protocol.For example, if mfx & DCC are recognized, spare parts.
  • Page 12: Notes On Digital Operation

    Notes on digital operation mfx Protocol • The operating instructions for your central unit will give Addresses you exact procedures for setting the different parame- • No address is required; each decoder is given a one- ters. time, unique identifier (UID). • The values set at the factory have been selected for mfx • The decoder automatically registers itself on a Central in order to guarantee the best possible running characte- Station or a Mobile Station with its UID. ristics.
  • Page 13 DCC Protocol • See the CV description for the DCC protocol for additional information. Addresses We recommend that in general programming should be • Possible addresses: short, long, and m.u. address done on the programming track. • Address range: Logic Functions 1 – 127 (short address, m.u. address) 1 – 10239 (long address) Acceleration / Braking Delay • Every address can be programmed manually.
  • Page 14: Controllable Functions

    f0 f8 f0 - f3 f4 - f7 Controllable Functions STOP mobile station Headlights Function f0 Function f0 Sound effect: Buffer to buffer — Function 1 Function f1 Function f1 Sound effect: Operating sounds — Function 2 Function f2 Function f2 Sound effect: Horn —...
  • Page 15: Parameter/Register

    Discription DCC Value Factory-Set Address 1 - 127 PoM Minimum Speed 0 - 255 PoM Acceleration delay 0 - 255 PoM Braking delay 0 - 255 PoM Maximum speed 0 - 255 Factory Reset / Manufacturer Recognition PoM Functions F1 - F8 in analog operation 0 - 255 PoM Functions F9 - F15 and lights in analog operation 0 - 255...
  • Page 16: Remarques Importantes Sur La Sécurité

    Remarques importantes sur la sécurité • L’intégralité des fonctions est disponible uniquement en exploitation Trix Systems, DCC et mfx. • La locomotive ne peut être utilisée qu‘avec le système • Feux de signalisation s‘inversant selon le sens de mar- d‘exploitation indiqué. che; feux commutables en exploitation digital. • Analogique max. 15 Volt =, digital max. 22 Volt ~. • Rayon minimal d’inscription en courbe 360 mm. • La locomotive ne peut pas être alimentée électriquement par plus d‘une source de courant à la fois.
  • Page 17: Remarques Relatives Au Fonctionnement En Mode Digital

    Protocole mfx Indication : remarquez que toutes les fonctions ne peuvent pas être actionnées dans tous les protocoles numériques. Adressage Sous mfx et sous DCC, il est possible de procéder à • Aucune adresse n’est nécessaire, le décodeur reçoit tou- quelques paramétrages de fonctions devant être actives tefois une identification unique et non équivoque (UID).
  • Page 18 Protocole DCC avec ceux de l’appareil de commande. • Toutes les fonctions peuvent être commutées en fonction Adressage du mappage des fonctions (voir le descriptif des CVs). • Adresse possibles: Courtes, longues et adresses de traction • Pour toute information complémentaire, voir le tableau • Catégorie d’adresse : des CVs, protocole DCC. 1 à 127 (adresses courtes, adresses de traction) Il est recommandé, de réaliser la programmation, fonda- 1 à...
  • Page 19: Fonctions Commutables

    f0 f8 f0 - f3 f4 - f7 Fonctions commutables STOP mobile station Fanal éclairage Activé Fonction f0 Fonction f0 Bruitage : Tampons joints — Fonction 1 Fonction f1 Fonction f1 Bruitage : Bruit d’exploitation — Fonction 2 Fonction f2 Fonction f2 Bruitage : Trompe —...
  • Page 20: Paramètre/Registre

    Affectation DCC Valeur Parm. Usine Adresse 1 - 127 PoM Vitesse minimale 0 - 255 PoM Temporisation d‘accélération 0 - 255 PoM Temporisation de freinage 0 - 255 PoM Vitesse maximale 0 - 255 Réinitialisation d’usine/identification du fabricant PoM Fonctions F1 - F8 en mode analogique 0 - 255 PoM Fonctions F9 - F15 et éclairage en mode analogique 0 - 255...
  • Page 21: Veiligheidsvoorschriften

    Opmerking: let er op dat niet alle functies in alle digitaal- • De volledige toegang tot alle functies is alleen mogelijk protocollen mogelijk zijn. Onder mfx of DCC kunnen enkele met Trix Systems, DCC of met mfx bedrijf. instellingen, welke in analoogbedrijf werkzaam moeten zijn, • Ingebouwde, rijrichtingsafhankelijke frontverlichting is in ingesteld worden.
  • Page 22: Aanwijzingen Voor Digitale Besturing

    Aanwijzingen voor digitale besturing mfx-protocol • Het op de juiste wijze instellen van de diverse parame- Adressering ters staat beschreven in de handleiding van uw digitale • Een adres is niet nodig, elke decoder heeft een éénmalig Centrale. en éénduidig kenmerk (UID). • Fabrieksmatig zijn de waarden voor mfx zo ingestelt dat • De decoder meldt zich vanzelf aan bij het Central Station optimale rijeigenschappen gegarandeerd zijn. of Mobile Station met zijn UID. Voor andere bedrijfssystemen moeten eventueel aanpas- • Naam af de fabriek: DB AG 245 006 singen uitgevoerd worden.
  • Page 23 DCC-protocol • Alle functies kunnen overeenkomstig de functiemapping geschakeld worden (zie CV-beschrijving). Adressering • Voor verdere informatie, zie de CV-tabel DCC-protocol. • Mogelijke adressen: kort, lang en tractieadres Het is aan te bevelen om het programmeren alleen op het • Adresbereik: programmeerspoor uit te voeren. 1 – 127 (kort adres, tractieadres) 1 – 10239 (lange adres) Fysieke functies • Elk adres is handmatig programmeerbaar.
  • Page 24: Schakelbare Functies

    f0 f8 f0 - f3 f4 - f7 Schakelbare functies STOP mobile station Frontsein Functie f0 Functie f0 Geluid: buffer aan buffer — Functie 1 Functie f1 Functie f1 Geluid: bedrijfsgeluiden — Functie 2 Functie f2 Functie f2 Geluid: signaalhoorn —...
  • Page 25: Parameter/Register

    Betekenis Waarde DCC Af fabriek Adres 1 - 127 PoM Minimale snelheid 0 - 255 PoM Optrekvertraging 0 - 255 PoM Afremvertraging 0 - 255 PoM Maximumsnelheid 0 - 255 Fabrieksinstelling/fabriekherkenning PoM functies F1 - F8 in analoogbedrijf 0 - 255 PoM functies F9 - F15 en licht in analoogbedrijf 0 - 255 Uitgebreld adres (bovenste gedeelte)
  • Page 31 Hinweis: Einige Teile werden nur ohne oder mit anderer 1 Antenne, Signalhörner E249 014 Farbgebung angeboten. 2 Decoder 248 426 Teile, die hier nicht aufgeführt sind, können nur im Rahmen 3 Schraube E786 750 einer Reparatur im Märklin-Reparatur-Service repariert 4 Beleuchtungseinheit E190 372 werden.
  • Page 32 If you should want such certification to be done, please contact us – also due to the additional costs incurred for this. Gebr. Märklin & Cie. GmbH Stuttgarter Str. 55 - 57 73033 Göppingen 248437/0615/Ha1Ef Germany Änderungen vorbehalten www.maerklin.com/en/imprint.html www.trix.de © Gebr. Märklin & Cie. GmbH...
