FoamPRO Turbo Stream S108-4008 Installation And Operation Manual

Hide thumbs Also See for Turbo Stream S108-4008:

Advertisement

Quick Links

Models S108-4008 and S108-4008H
All quality FoamPro products are ruggedly designed, accurately machined, carefully assembled, thoroughly inspected
and tested. In order to maintain the high quality of your unit, and to keep it in a ready condition, it is important to follow
the instructions on care and operation. Proper use and good preventive maintenance will lengthen the life of your unit.
ALWAYS INCLUDE THE UNIT SERIAL NUMBER IN CORRESPONDENCE.
FoamPro • 26 Southern Blvd. • Nesconset, NY 11767 USA • 800-533-9511 • FAX 816-892-3178
Turbo Stream
INSTALLATION AND
OPERATION MANUAL
®
Unit
Serial
Number
Form 925
Rev. 6/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Turbo Stream S108-4008 and is the answer not in the manual?

Questions and answers

Summary of Contents for FoamPRO Turbo Stream S108-4008

  • Page 1 Proper use and good preventive maintenance will lengthen the life of your unit. ALWAYS INCLUDE THE UNIT SERIAL NUMBER IN CORRESPONDENCE. FoamPro • 26 Southern Blvd. • Nesconset, NY 11767 USA • 800-533-9511 • FAX 816-892-3178...
  • Page 2: Table Of Contents

    WARRANTY ..................... Back Cover NOTE TO SYSTEM INSTALLERS IMPORTANT: Please provide a copy of the FoamPro manual to the end user of the equipment. For additional FoamPro manuals, contact by FAX 816-892-3178, web site www.foampro.com, or call 800-533-9511. Request Form No. 925.
  • Page 3: Safety

    Drain all concentrate and water from the discharge 19. CAUTION: The components shipped with each system before servicing any of its component parts. FoamPro unit are tested at the factory. Improper handling and forcing connections can damage the Periodically inspect all hoses for wear or worn components which could result in other conditions.
  • Page 4: Introduction

    Use extreme care during assembly and service to keep contaminants out of the system. Introduction The FoamPro High Pressure System is a hydraulic or The foam concentrate is directly injected into the gas engine-driven, flow-based proportioning system that system at the head of the pump.
  • Page 5: System Component Description

    Turbo Stream Installation and Operation Manual System Component Description The following components are packaged with the FoamPro High Pressure System: Foam Concentrate Strainer Control Panel Pump/Gas Engine Assembly Foam Spray Gun/Wand Water Inlet Check Valve Thermal Relief Valve Inlet Water Strainer...
  • Page 6: Installer Supplied Parts

    DISCHARGE LINES CAUTION: Always disconnect ground before electrical arc welding on any FoamPro equipment. Failure to do so will Fittings and hoses from the foam solution discharge of result in a power surge through the system that could case the pump to the foam spray nozzle must be supplied by irreparable damage to the electronic components.
  • Page 7: Installation Planning

    FoamPro unit can gravity feed to the pump. The foam system will draft up best be installed onto a particular apparatus. Most of to three feet.
  • Page 8: Electrical Equipment Installation

    LINE STRAINERS THERMAL RELIEF VALVE There are two line strainers provided with the FoamPro A thermal relief valve is included with the system to prevent unit. The pump inlet line strainer has 3/4-inch NPT pump overheating during unloading.
  • Page 9: Calibration And Setup

    The output of the FoamPro High Pressure System must be set at a constant 8 GPM + 0.20 GPM/-0.5 GPM. Injection rate is easily changed by turning the foam % control knob on the display panel.
  • Page 10: Engine Operating Instructions

    2) Engine Oil: Before checking or refilling with engine temperature is achieved. oil, make sure the engine is stopped and placed on 2) CAUTION: Do not run the FoamPro High Pressure a stable, level surface. Use oil recommended for System for long periods during unloading. Long...
  • Page 11: Maintenance

    Troubleshooting The FoamPro Turbo Stream system is designed to be easy to diagnose and service. There are several major components (see Figure 2). Servicing the system involves isolation of the failed component and replacing it.
  • Page 12: Parts Identification

    Installation and Operation Manual Parts Identification 2541-0049 PowerPro Engine 2541-0057 Honda Engine 3350-0085 Foam Inlet Strainer 2414B-G1P Pump/Gearbox Assy. 2640-0004 Pressure Gauge 2900-0049 3312-0005 Bypass Hose Thermal Relief Valve 3320-0063 Inlet Check Valve 3381-0045 Gun/Wand Assembly with Low Pressure 3385-4500 Nozzle (approx. 400 PSI) Nozzles High Pressure 3385-2300 (1450 PSI) Medium Pressure 3385-3000 (750 PSI)
  • Page 13: Installation Drawings

    Turbo Stream Installation and Operation Manual Installation Drawings 18.25 3.75 7.68 .44 Dia (6 Holes) 2.63 5.62 2.25 6.69 5.31 Pulse Hose Connection Foam Concentrate Inlet Solution Outlet 3/8-18 NPT 1/2-14 NPT Water Inlet Port .22 Dia (4) 3/4-14 NPT 17.94 21.44 31.31...
  • Page 14 Installation and Operation Manual NOTES...
  • Page 15 Turbo Stream Installation and Operation Manual NOTES...
  • Page 16: Warranty

    Limited Warranty Fire Research Corp. (FRC), as supplier of FoamPro, warrants to the original purchaser, each new pump, system or other product of its own manufacture, for a period of two years from the date of shipment from the factory, to be free from defects in material and workmanship under normal use and service.
