GPT3G005COV User Manual
GPT3G005COV(WCDMA) Tracker User Manual
-201703
Welcome to use this portable GPS tracker. This product is with GPS module and GSM module, that has many
new and unique functions, such as extra big battery (6000mAH), water-Proof, powerful magnetic, LBS locate
without GPS signal, check current location by iOS iPhone & Android App / Web / SMS / WeChat etc. Its standby
time can reach over 2 month (about 60 days, work mode 1). User can control different working mode for different
using, it can work without platform, just send SMS to check current location, also it can upload location to sever
by user setting time interval, and more sending sms can make the tracker to go to sleep and weak up & locate
one time every day, This GPS tracker suit for personal tracking, vehicle tracking or outdoor workers tracking.
This tracker also has LBS locating function (mobile phone base station CELL ID), if no GPS signal in some
place, such as underground park, indoor room, or around high building with bad GPS signal, the tracker will
locate with LBS (normally the LBS CELL ID locating precision is about 50-500m in the city, and the GPS locating
precision is about 10m).
Using the unique user name and password (Default user name is the last 7 digits of the tracker ID, password
is same with user name), user can check the history track max to 6-12 months, the real time location, and set
the over speed alarm, the geo-fence alarm and so on. The website is www.999gps.net. It suit for personal user
or fleet user, and it can locate object by visiting website, wap visiting by phone, Android App or iOS iPhone App
on mobile phone, WeChat on mobile phone (Android,iPhone,Symbian,Windows phone,Blackberry), sending
sms to get location Google map link etc.
iPhone App Download
Android App Download
1
-
-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPT3G005COV and is the answer not in the manual?

Questions and answers

Summary of Contents for OzSpy GPT3G005COV

  • Page 1 GPT3G005COV User Manual GPT3G005COV(WCDMA) Tracker User Manual -201703 Welcome to use this portable GPS tracker. This product is with GPS module and GSM module, that has many new and unique functions, such as extra big battery (6000mAH), water-Proof, powerful magnetic, LBS locate without GPS signal, check current location by iOS iPhone &...
  • Page 2: Product Picture

    GPT3G005COV User Manual Product Picture: magnet Charging contact point Charging port ON/OFF switch and charging indicator LED Car Adapter and changing Wire power supply box Charging board(Optional accessories) Function Specification:  Portable Design,No installation,Easy use;  Big Li-battery(6000mAH) standby time up to 20 days;...
  • Page 3: Before Using

    GPT3G005COV User Manual  Green Power LED ON continuously : GSM Searching network  Green Power LED OFF continuously : Power off  Red GSM LED Flash once : Upload location to server OK  Red GSM LED Flash twice...
  • Page 4 GPT3G005COV User Manual  We recommend using OEM charger to recharge the tracker. this tracker use the 5V DC voltage to recharge, so too high voltage or AC voltage may damage the tracker or even cause accidents.  Use the car adapter or home charger or PC USB to recharge the tracker: insert the USB wire into...
  • Page 5: Basic Settings

    GPT3G005COV User Manual Basic Settings 1. First to buy a 2G GSM or 3G WCDMA mobile phone SIM card and enable data service, order a data package (Normally will use about 10M-30M GPRS data every month), install in the tracker, please refer the above Before Using1.
  • Page 6 GPT3G005COV User Manual Locate Operation & Setting 1、Add authorized phone number Send SMS“ADDPHONE*123456*A*phonenumber” to tracker is OK, “ADDPHONE” is fixed command; “123456” is password; “A” is authorized number location, every tracker have 3 authorized phone number locations, A and B, and C, so you can set 3 phone numbers, phonenumber means the mobile phone number you want to set, if the add operation is success, the tracker will send back the information ”Add Preset Phone OK”, if the...
  • Page 7 GPT3G005COV User Manual like below, click the link the map is same with the above 2. Cell ID Location http://maps.google.com/maps?q=N40.756441,W73.986378 Battery:91% Note: The LBS location precision is not very high, in the city maybe 30-50 meters, in country side maybe over 300 meters according the GSM base station density.
  • Page 8 GPT3G005COV User Manual Advanced Operation & Setting 1. Check Authorized Phone Number by SMS Send SMS “CHECKPHONE*123456” to the tracker number, “CHECKPHONE” is command; “123456” is password; the tracker will send back the information “Authorized Phone A: 13987654321; B: 13876543210;...
  • Page 9 GPT3G005COV User Manual please sending SMS “CHECK*123456” to the tracker to check. if the APN & GPRS are not right, please set by the following description. Send SMS “APN*123456*apnname” to the tracker, in which, “APN” is the fixed command, “123456” is the password and “apnname”...
  • Page 10 GPT3G005COV User Manual “22.680307N*114.146843E” is the longitude and latitude of the fence center point . “N” is north, “S” south, and “E” is east, “W” west. if no longitude and latitude in the SMS command, like “SETFENCE*123456*Geo-Name*GGG”, the tracker will turn on the GPS &...
  • Page 11 GPT3G005COV User Manual https://maps.google.com/maps?q=22.67680N,114.15188E Battery:91% If no authorized number is added, the SOS information can not be sent. If the SOS information is received, please confirm the user is safety. 13. Check tracker setting Send SMS “CHECK*123456” to the tracker number, “CHECK” is the fixed command, “123456” is password.
  • Page 12: Platform Operation

    GPT3G005COV User Manual name and password,change the tracker password to 123456, reset the IP address, reset the system working mode and the interval time, and so on. Platform Operation If user enable the uploading location to platform server www.999gps.net , the current location & history tracking can be checked on the platform with PC website &...
  • Page 13: Troubleshooting

    GPT3G005COV User Manual Trouble Shooting Please confirm that the SIM card PIN code has been disabled, it means if mobile phone use this SIM card, it is not necessary to input any password. This tracker use 2G GSM and 3G WCDMA network, any other SIM card and network is invalid.
  • Page 14: Packing List

    GPT3G005COV User Manual Specification: Working Voltage 5V DC GSM Frequency 850/900/1800/1900Mhz (global band) GSM/WCDMA Chip set Fibocom WCDMA Frequency 850(800)/900/1900/2100 (global band ) GPS Chip Set Antenna Built in Locate Precision 5-10 Meters Recharging Current 5V/700-800mA Standby Current < 2 mA 5V DC Locating Current <...
  • Page 15 GPT3G005COV User Manual Customer User Mobile Phone Tracker SIM card Date Year month Model ID Number GPT3G005COV Distributor...
