GE109MST1
imagine
the possibilities
Microwave Oven
Thank you for purchasing this Samsung product.
Owner's instructions & Cooking guide
Please be advised that the Samsung warranty does NOT cover service
calls to explain product operation, correct improper installation, or
perform normal cleaning or maintenance.
This manual is made with 100 % recycled paper.
GE109MST1_XEF_DE68-04288A-01_EN.indd 1
20/12/2014 10:30:42
Advertisement
Table of Contents
Related Manuals for Samsung GE109MST1
Summary of Contents for Samsung GE109MST1
- Page 1 Microwave Oven Thank you for purchasing this Samsung product. Owner’s instructions & Cooking guide Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance. This manual is made with 100 % recycled paper.
-
Page 2: Table Of Contents
Safety information ..................2 USING THIS INSTRUCTION BOOKLET Quick look-up guide ..................11 You have just purchased a SAMSUNG microwave oven. Your Owner’s Oven features ....................12 Instructions contain valuable information on cooking with your microwave Oven ......................12 oven: Control panel .................... - Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING: Only allow children to use READ CAREFULLY AND KEEP FOR the oven without supervision when FUTURE REFERENCE. adequate instructions have been given Make sure that these safety precautions are so that the child is able to use the oven obeyed at all times.
- Page 4 The microwave oven is intended for Failure to maintain the oven in a clean heating food and beverages. Drying of conditioin could lead to deterioration of food or clothing and heating of warming the surface that could adversely affect pads, slippers, sponges, damp cloth and the life of the appliance and possibly similar may lead to risk of injury, ignition result in a hazardous situation.
- Page 5 The appliance should not be cleaned During use the appliance becomes hot. with a water jet. Care should be taken to avoid touching heating elements inside the oven. This oven should be positioned proper direction and height permitting easy WARNING: Accessible parts may access to cavity and control area. become hot during use.
- Page 6 EDM and arc welding equipment. This appliance can be used by For Class B equipment is equipment children aged from 8 years and above suitable for use in domestic establishments and persons with reduced physical, and in establishments directly connected sensory or mental capabilities or lack of experience and knowledge if they have to a low voltage power supply network been given supervision or instruction...
- Page 7 If the supply cord is damaged, it must be Failure to maintain the oven in a clean replaced by the manufacturer, its service condition could lead to deterioration of the agent or similarly qualified persons in surface that could adversely affect the life order to avoid a hazard. of the appliance and possibly result in a For your personal safety, plug the cable hazardous situation.
- Page 8 A few simple precautions should be taken Please contact nearest authorised when storing or having your microwave oven Samsung customer care, to arrange for a serviced. qualified engineer to replace the bulb. The oven must not be used if the door or...
- Page 9 Remove all foreign substances such as dust or Do not use a damaged power plug, damaged power water from the power plug terminals and contact cord or loose wall socket. When the power plug points using a dry cloth on a regular basis. or power cord is damaged, contact your nearest service centre.
- Page 10 Do not operate the microwave oven for deep Stand at arms length from the oven when opening fat frying because the oil temperature cannot be the door to avoid getting scalded by escaping hot air controlled. This could result in a sudden boil over of or steam.
-
Page 11: Quick Look-Up Guide
Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect if the damage to the unit and/or damage to or loss of the accessory was caused by the customer. Items this stipulation covers include: If you want to cook some food. (a) A Dented, Scratched, or Broken Door, Handle, Out-Panel, or Control Panel. (b) A Broken or missing Tray, Guide Roller, Coupler, or Wire Rack. 1. Place the food in the oven. Press the START/+30s button. -
Page 12: Oven Features
oven features OVEN CONTROL PANEL 1. DOOR HANDLE 7. DOOR LATCHES 2. DOOR 8. TURNTABLE 3. VENTILATION HOLES 9. COUPLER 4. HEATING ELEMENT 10. ROLLER RING 5. LIGHT 11. S AFETY INTERLOCK HOLES 6. WATER BOWL HOLDER 12. C ONTROL PANEL 1. CLOCK BUTTON 8. TURNTABLE ON/OFF BUTTON 2. HEALTHY COOKING BUTTON 9. STEAM CLEAN BUTTON 3. MY PLATE BUTTON 10. -
Page 13: Accessories
oven use ACCESSORIES HOW A MICROWAVE OVEN WORKS Depending on the model that you have purchased, you are supplied with several Microwaves are high-frequency electromagnetic waves; the energy released enables accessories that can be used in a variety of ways. food to be cooked or reheated without changing either the form or the colour. -
Page 14: Checking That Your Oven Is Operating Correctly
CHECKING THAT YOUR OVEN IS OPERATING CORRECTLY The following simple procedure enables you to check that your oven is working correctly 3. Set the cooking time by press the Up(+)/Down(-) button. at all times. If you are in doubt, refer to the section entitled “Troubleshooting” on the Result: The cooking time is displayed. -
Page 15: Power Levels And Time Variations
ADJUSTING THE COOKING TIME You can increase the cooking time by pressing the START/+30s button once for each 4. Press the Up(+)/Down(-) button to set the minute. 30 seconds to be added. • Check how cooking is progressing at any time simply by opening the door • Increase the remaining cooking time 5. When the right time is displayed, press the Clock button to start the clock. -
Page 16: Setting The Energy Save Mode
SETTING THE ENERGY SAVE MODE The oven has an energy save mode. The following table presents quantities and appropriate instructions about 12 pre- programmed cooking options. • Press the STOP/ECO button. Use oven gloves when taking out food. Result: Display off. Serving • To remove energy save mode, open the door or press the Code/Food... -
Page 17: Using The My Plate Features
USING THE MY PLATE FEATURES The My Plate features has 2 pre-programmed cooking times. You do not need to set Serving Code/Food Instructions either the cooking times or the power level. Size First, place the food in the centre of the turntable and close the door. 300g Rinse pieces and put on a ceramic plate. -
Page 18: Using The Power Defrost Features
USING THE POWER DEFROST FEATURES The Power Defrost features enable you to defrost meat, poultry, fish, bread and cake. The following table presents the various Power Defrost programmes, quantities and The defrost time and power level are set automatically. You simply select the programme appropriate instructions. -
Page 19: Grilling
GRILLING COMBINING MICROWAVES AND GRILL The grill enables you to heat and brown food quickly, without using microwaves. You can also combine microwave cooking with the grill, to cook quickly and brown at the • Always use oven gloves when touching the recipients in the oven, as they will be same time. -
Page 20: Using The Crusty Plate
USING THE CRUSTY PLATE This crusty plate allows you to brown food not only on the top with the grill, but also the Clean the crusty plate with warm water and detergent and rinse off with clean water. bottom of the food turns crispy and brown due to the high temperature of the crusty Do not use a scrubbing brush or a hard sponge otherwise the top layer will be plate. -
Page 21: Using The Steam Cleaning
Cooking time Cooking time Food Serving Size Power Food Serving Size Power (min.) (min.) Pizza (Frozen) 300-350 g 450 W+Grill 11-12 Baked Potatoes 250 g 600 W + Grill 500 g Instructions Preheat the crust plate for 3 minutes. Put the frozen pizza Instructions on the crust plate. -
Page 22: Using The Child Lock Features
USING THE TURNTABLE ON/OFF FEATURES The Turntable on/off button enables you to use large dishes which fill the whole oven by 4. Press the Steam Clean button. stopping the turntable from rotating (only manual cooking mode). It can be seen MISTY during steam cleaning. but it is not a The results will be less satisfactory in this case as the cooking is less even. -
Page 23: Cookware Guide
cookware guide To cook food in the microwave oven, the microwaves must be able to penetrate the food, Microwave- Cookware Comments without being reflected or absorbed by the dish used. safe Care must therefore be taken when choosing the cookware. If the cookware is marked Glassware microwave-safe, you do not need to worry. The following table lists various types of cookware and indicates whether and how they • Oven-to- Can be used, unless decorated with a metal... -
Page 24: Cooking Guide
cooking guide Cooking Guide for frozen vegetables Use a suitable glass pyrex bowl with lid. Cook covered for the minimum time – see table. Continue cooking to get the result you prefer. MICROWAVES Stir twice during cooking and once after cooking. Add salt, herbs or butter after cooking. Microwave energy actually penetrates food, attracted and absorbed by its water, fat and Cover during standing time. sugar content. The microwaves cause the molecules in the food to move rapidly. - Page 25 Cooking Guide for fresh vegetables Use a suitable glass pyrex bowl with lid. Add 30-45 ml cold water (2-3 tbsp) for every Food Serving Size Power Time (min.) 250 g unless another water quantity is recommended – see table. Cook covered for the Leeks 250 g 900 W 4-4½ minimum time – see table. Continue cooking to get the result you prefer. Stir once during Instructions and once after cooking. Add salt, herbs or butter after cooking. Cover during a standing time of 3 minutes. Cut leeks into thick slices. Stand for 3 minutes.
- Page 26 Cooking Guide for rice and pasta REHEATING Rice: Use a large glass pyrex bowl with lid – rice doubles in volume during Your microwave oven will reheat food in a fraction of the time that conventional ovens cooking. Cook covered. hobs normally take. After the cooking time is over, stir before standing time and salt or add Use the power levels and reheating times in the following chart as a guide.
- Page 27 REHEATING BABY FOOD BABY FOOD: Food Serving Size Power Time (min.) Empty into a deep ceramic plate. Cover with plastic lid. Stir well after reheating! Let stand Stew (Chilled) 350 g 600 W 4½-5½ for 2-3 minutes before serving. Stir again and check the temperature. Recommended serving temperature: between 30-40 °C. Instructions BABY MILK: Put stew in a deep ceramic plate. Cover with plastic lid. Pour milk into a sterilised glass bottle. Reheat uncovered. Never heat a baby’s bottle with Stir occasionally during reheating and again before standing and teat on, as the bottle may explode if overheated. Shake well before standing time and serving.
- Page 28 Reheating Baby Food and Milk DEFROSTING Use the power levels and times in this table as guide lines for reheating. Microwaves are an excellent way of defrosting frozen food. Microwaves gently defrost frozen food in a short period of time. This can be of great advantage, if unexpected Food Serving Size Power...
- Page 29 GRILL The grill-heating element is located underneath the ceiling of the cavity. It operates while Food Serving Size Power Time (min.) the door is closed and the turntable is rotating. The turntable’s rotation makes the food Poultry brown more evenly. Preheating the grill for 3-5 minutes will make the food brown more Chicken Pieces 500 g (2 pcs) 180 W...
- Page 30 Grill Guide for fresh and frozen foods Preheat the grill with the grill-function for 3 minutes. Serving Use the power levels and times in this table as guide lines for grilling. Fresh Food Power 1 step (min.) 2 step (min.) Size Use oven gloves when taking out.
-
Page 31: Troubleshooting And Error Code
6½ to 7½ minutes using 900 W. • The Light bulb should not be replaced in person for safety reasons. Please contact Stir several times well during cooking. nearest authorised Samsung customer care, to arrange for a qualified engineer to replace the bulb. BROWNING ALMOND SLICES Spread 30 g sliced almonds evenly on a medium sized ceramic plate. -
Page 32: Error Code
Sparking and cracking occur inside the oven (arcing). SAMSUNG strives to improve its products at all times. Both the design specifications and • Have you used a dish with metal trimmings? these user instructions are thus subject to change without notice. - Page 33 MEMO MEMO GE109MST1_XEF_DE68-04288A-01_EN.indd 33 20/12/2014 10:30:59...
