RMLT.465311.004UM
User Manual
Document version 9
2022
ENG
26.30.23.000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIS-TOP and is the answer not in the manual?

Questions and answers

Summary of Contents for ARMTEL DIS-TOP

  • Page 1 DIS-TOP Digital desktop call station RMLT.465311.004UM User Manual Document version 9 26.30.23.000 2022...
  • Page 2 © Armtel info@armtel.com...
  • Page 3: Introduction

    INTRODUCTION This User Manual applies to «DIS-TOP Digital desktop call station» RMLT.465311.004 manufactured by Armtel LLC, and is intended to familiarize the User with the device and the procedure for its operation at the installation site. Designed for organization of two-way communication as a component of communication systems within Central exchange DCN-2.system manufactured by Armtel...
  • Page 4: Safety Provisions

    − before connecting the product to the power supply, make sure the power and communication cables are properly insulated; − protect power and communication cables from damage. The safety provisions for specific operations described in this manual are marked with: page 2/46 armtel.com © Armtel info@armtel.com...
  • Page 5: Table Of Contents

    3 MAINTENANCE ................................27 3.1 General guidelines ..............................27 3.2 Safety precautions ..............................27 3.3 Maintenance procedure ............................27 3.4 Checking operability ............................28 3.4.1 Initialization test ............................28 3.4.2 Checking acoustic path ..........................28 armtel.com page 3/46 info@armtel.com © Armtel...
  • Page 6 Wall-mounting ......................36 APPENDIX C (reference) FASTENING OF EC-TOP EXPANSION UNIT FOR DESKTOP MOUNTING 39 APPENDIX d (reference) RECOMMENDATIONS for mortise installation dis-top ......... 40 APPENDIX E (reference) DIS-TOP Indication LED types .................. 43 APPENDIX F (reference) Template for printing function keys assignment ..........44 page 4/46 armtel.com...
  • Page 7: Description And Operation

    DIS-ТОР is designed for use in distributed and centralized digital intercom and Public Address /General Alarm communication systems. The DIS-TOP supervisory control panel is a connected switch operating in a digital public address dispatching system (GGS) controlled by the DCN-2. DIS-TOP requires the broadcast of voice messages and has programmable local functions.
  • Page 8 − Establishing communication with subscribers by pre-programmed direct keys, memorizing and call repeating of the last call − Display of DIS-TOP number, date, time and type of communication for incoming and outgoing calls, as well as numbers of calling and called subscribers;...
  • Page 9: Main Specifications

    DESKTOP CALL STATION DIS-ТОР DIGITAL User Manual 1.1.2 Main specifications Main specifications of DIS-TOP are given in Table Table 1 – Main specifications (beginning) Parameters Value Rated voltage, V Supply voltage range PoE, V From 36 to 60 Reverse polarity protection...
  • Page 10: Operations Conditions

    DIS-ТОР DIGITAL User Manual 1.1.3 Operations conditions Environmental requirements for DIS-TOP in operating mode: − ambient temperature range from minus 20 °С to plus 50 °C; − relative humidity up to 80 % at 25 °C, at lower temperatures, without condensing;...
  • Page 11: Scope Of Supply

    Microphone G14-3 with the product Accessories to be Windshield provided in microphone ordered completed with the product Operational documentation RMLT.465311.004PP Product Passport RMLT.465311.004UM User Manual * For version RMLT.465311.004-01 – see 1.1.5.1 armtel.com page 9/46 info@armtel.com © Armtel...
  • Page 12: Design

    DIS-TOP has 2 versions with regard to the color of the enclosure cover: basic version is of black RAL8022, version 01 is of dark grey RAL7046. DIS-TOP is available in horizontal desktop design and upright wall-mounted design. It can be installed in a work surface, made page 10/46 armtel.com...
  • Page 13 The installation methods are provided in detail, Section “Installation, connection and dismantling”. 1.1.5.2 DIS-TOP is manufactured in plastic flat enclosure complete with detachable stand that allows the desk enclosure to be inclined for better visibility of a keypad and a display.
  • Page 14 (4 pcs.) and in the stand (2 pcs.) in accordance with Figure 5. When DIS-TOP is supplied to the customer, the grooves in the base of the enclosure are closed with special plugs (not shown in...
  • Page 15: Labeling

    DESKTOP CALL STATION DIS-ТОР DIGITAL User Manual 1.1.6 Labeling On the bottom side of DIS-TOP casing is placed bilingual nameplate. The nameplate contains the following information: − name, trademark and reference information of the manufacturer; − product name and description;...
  • Page 16: Package

    DIS-ТОР DIGITAL User Manual 1.1.7 PACKAGE The DIS-TOP with the assembly kit and documents, which come with the supply package, is packed in consumer package (cardboard box). Before packing in consumer package (cardboard box), DIS-TOP with the assembly kit and operational documentations are placed in plastic film covers that have the corresponding marking.
  • Page 17: Description And Operation Of The Product Components

    − microphone; − speaker; − Display. 1.2.2 Main board DIS-TOP main board is a printed board with installed electronic elements required for functioning of the DIS-TOP. External appearance of main board is given on Figure 6. DIS-TOP Figure 6 –...
  • Page 18 The call station has 42 keys with LED backlight indication, 7 keys in a line slot, the number of slots is 6. To provide specified protection degree for DIS-TOP, the keys are furnished with silicon membrane. Each key is assigned for establishing connection with subscribers or performing local functions as follows: “Headset”, changing modes for “Public...
  • Page 19: Microphone

    User Manual The keys are high-strength and wear-resistant. The direct keys have no key labels, the transparent film incorporating into DIS-TOP scope of supply can be applied for function identification of DCN. The functional labels are printed out with allowance for film/paper thickness up to 100 microns and placed underneath transparent caps of DCN.
  • Page 20: Speaker

    Figure 9 – External appearance and overall dimensions of microphone G14-3 1.2.4 Speaker DIS-TOP uses a wideband 2,5 Inch broadband speaker with plastic membrane, main specifications are as follows: rated resistance 8 Ohm, frequency range from 200 to 15kHz is used in DIS-TOP.
  • Page 21: Intended Use

    2.1.2 DIS-TOP power is supplied from PoE injector under IEEE802.3at standard, it is allowed to connect to it no more than two DIS-TOP Expansion units. The use of more than two Expansion units is permitted only if the unit is powered by from an external 12 V power supply with a power of at least 25 W.
  • Page 22: Safety Precautions

    In order to ensure fire safety, follow the following rules: − before connecting the product to the power supply, make sure the power and communication cables are properly insulated; − protect power and communication cables from damage. page 20/46 armtel.com © Armtel info@armtel.com...
  • Page 23: Installation, Connection And Dismantling

    The pin numbering and pinout of the connectors are given in Appendix A. The cables connected to the DIS-TOP are laid in the grooves of the base of the case and the stand in accordance with 1.1.5.4 and Figure 5.
  • Page 24 − disconnect stand (if used); − disconnect all connection cables; − disconnect the appropriate power and communication cable from the RJ-45 DIS-TOP connector; − disconnect the headset from the RJ-11 connector (if used); − disconnect the cable of the EC-TOR expansion unit (if used) −...
  • Page 25: Operation

    After connecting to DCN-2 exchange, the DIS-TOP is automatically initialized. The initialization process takes from 30 seconds to three minutes. Before DIS-TOP start-up, data with initial settings are transmitted to it. Data transfer is fulfilled under control of DCN-2 software within the initialization cycle via the interface.
  • Page 26: Communication Types And Scenarios

    The relevant indication is displayed at the desktop with regard to the provided communication type of DIS-TOP programmed by DCN-2 central exchange. For instance, the following messages can be displayed in simplex ingoing and outgoing calls: Messages displayed in simplex communication: Figure 12 –...
  • Page 27 Direct keys to DIS-TOP can be configured from DCN-2 to fulfil different communication scenarios such as “Call”, “Group call”, “Conference”, “Disconnection”, “Selector”, “Circular” etc. as referred in the User manual DCN communication system.
  • Page 28: Troubleshooting

    The caller subscriber is Adjust volume of the integrated speaker is set on minimum speaker using programmed keys. not heard from the level integrated speaker The speaker is faulty Contact and apply for Armtel service page 26/46 armtel.com © Armtel info@armtel.com...
  • Page 29: Maintenance

    − check for safety connection to the cable sockets - the cables should not have any tension; − cleaning of DIS-TOP surface from dirt, using for this purpose the wet sponge with mild soap solution or wet wipes for cleaning office appliances; the use of chemically active solvents is not admitted;...
  • Page 30: Checking Operability

    − pause for about 10 seconds to completely discharge the filtering power supply tanks in DIS-TOP; − apply power to DIS-TOP again, make sure that the remote control is successfully initialized as described in 2.5.1. 3.4.2 Checking acoustic path...
  • Page 31: Eng 4 Pepair

    No scheduled repair work is provided for the product. Unscheduled repair shall be performed by the manufacturer at the request of the User. The place, time, procedure and cost of the work shall be agreed with the manufacturer in advance. armtel.com page 29/46 info@armtel.com © Armtel...
  • Page 32: Storage

    20 °С to plus 40 °С, and in relative humidity conditions under plus 25 °С. Air in the storage premises must be free of corrosive foreign matter (acid fumes, alkalis). page 30/46 armtel.com © Armtel info@armtel.com...
  • Page 33: Transportation

    − temperature from minus 20 to plus 40 °С and humidity up to 80 % at 25 °С; − absence of direct ingress of atmospheric precipitation, water splashes, solar UV radiation, dust, sand, aerosols; − the shipping container on the shipping vehicle is fastened to avoid falling and collision. armtel.com page 31/46 info@armtel.com © Armtel...
  • Page 34: Disposal

    The product shall not be disposed of together with household waste and must be delivered to a special center for the disposal of electronic products. The operating organization shall be responsible for the disposal of the product. page 32/46 armtel.com © Armtel info@armtel.com...
  • Page 35: Appendix A (Reference) Connection

    Figure А.1 –RJ-45 socket Supply voltage range 0 V Supply voltage range 0 V The pin assignment of RJ-22 sockets for analog path connection of Handset unit is illustrated at Table А.2. Figure А.2 –RJ-45 socket armtel.com page 33/46 info@armtel.com © Armtel...
  • Page 36 The appearance of the plug RJ-11 connector with the numbering of temptations figure A.4. Figure A.4 – RJ-11 plug contacts An example of DIS-ТОР connection complete with DIS-ТОР Handset unit and communication DCN-2 DIS-ТОР unit is illustrated at Figure A.5. page 34/46 armtel.com © Armtel info@armtel.com...
  • Page 37 DESKTOP CALL STATION DIS-ТОР DIGITAL User Manual DIS-ТОР Figure A.5 – The example of connection armtel.com page 35/46 info@armtel.com © Armtel...
  • Page 38: Appendix B (Reference)

    User Manual APPENDIX B (REFERENCE) WALL-MOUNTING B.1 For mounting the DIS-TOP on the wall mount of the housing, a hole is located below the console housing. The appearance of the plate is shown in Figure B.1. Figure B.1 – Additional Expansion unit adjustment page 36/46 armtel.com...
  • Page 39 DESKTOP CALL STATION DIS-ТОР DIGITAL User Manual B.2 At the installation site, marking is made in accordance with the given template (see Figure B.2). Figure B.2 – The variants of adjustment of TOP-EC-IP2 Expansion unit armtel.com page 37/46 info@armtel.com © Armtel...
  • Page 40 B.3 – Brackets for wall mounting DIS-TOP B.4 B.4 In holes 1, 4, 5, 8 on the lower surface of the DIS-TOP base (see Figure B.1), screws for plastic 3 × 8 mm from the location kit are screwed in so that the head of the screw does not reach the base of the base on 2-3 mm, after which the heads of the self-tapping screws are sunk into the holes (5) - see Figure B.3, and moving down the remote control is...
  • Page 41: Fastening Of Ec-Top Expansion Unit For Desktop Mounting

    C.3 If it is necessary to connect another EC-TOP expansion unit, its fastening is carried out in the same way either to the DIS - TOP console or to the EC-TOR expansion unit. armtel.com page 39/46 info@armtel.com © Armtel...
  • Page 42: Appendix D (Reference) Recommendations For Mortise Installation Dis-Top

    DESKTOP CALL STATION DIS-ТОР DIGITAL User Manual APPENDIX D (REFERENCE) RECOMMENDATIONS FOR MORTISE INSTALLATION DIS-TOP In the case of using the mortise version of the DIS- TOP installation , markings are made on the tabletop in accordance with Figure C.1: Figure D.1 –...
  • Page 43 ART 9091. The permissible length of self-tapping screws should not exceed the value determined by the formula (see Figure D.2): Calculation of the maximum length of a screw Figure D.2 – armtel.com page 41/46 info@armtel.com © Armtel...
  • Page 44 DESKTOP CALL STATION DIS-ТОР DIGITAL User Manual D.3 If EC-TOP Expansion unit should be attached to, the layout for its installation is and in accordance with Figure D.3: page 42/46 armtel.com © Armtel info@armtel.com...
  • Page 45: Appendix E (Reference)

    User Manual APPENDIX E (REFERENCE) DIS-TOP INDICATION LED TYPES The indication types LED are used in DIS-TOP are given in Table E.1. All periods of indication are synchronized in the frames of one end-User device Table E.1 – DIS-TOP LED indication types Целевая...
  • Page 46: Appendix F (Reference)

    DESKTOP CALL STATION DIS-ТОР DIGITAL User Manual APPENDIX F (REFERENCE) TEMPLATE FOR PRINTING FUNCTION KEYS ASSIGNMENT Template size when printing (2,8 х 0,95) mm page 44/46 armtel.com © Armtel info@armtel.com...
