- Page 1 Fire Fighter’s Telephone TR-FFT Installation/Operation Manual Document LS10309-001TR-E 04/28/2021 Rev: P/N LS10309-001TR-E:A • ECN 151608...
- Page 2 Heat detectors are designed to Limit-F-2020 protect property, not life. PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021...
- Page 3 Triga™ is a trademark of TRIGA Life Safety Systems, LLC. eVance®, Flexput®, Honeywell®, JumpStart®, and SWIFT® are registered trademarks of Honeywell International Inc. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The Mozilla Foundation.
- Page 4 Electrical and electronic equipment contains materials, parts and substances, which can be dangerous to the environment and harmful to human health if the waste of electrical and electronic equipment (WEEE) is not disposed of correctly. PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021...
-
Page 5: Table Of Contents
5.3.5: Telephone Jack Only Audio Circuit ..............................27 Section 6: System Operation............................28 6.1: Key Switch Operations ....................................28 6.1.1: JumpStart Key Switch (on inside of TR-FFT Dead Front Panel)......................28 6.1.2: Accept Key Switch (on inside of TR-FFT Dead Front Panel)......................28 6.1.3: Answer Switch .....................................28 6.1.4: Silence Switch ......................................28... - Page 6 Table of Contents 6.2.7: Status LEDs (on inside of TR-FFT Dead Front Panel) ........................28 6.2.8: Zone Active ......................................28 6.2.9: Zone Trouble ......................................29 6.3: JumpStart Operation ......................................29 Appendix A: Compatible Powering Devices ......................... 32 A.1: Compatible Power Devices.....................................32 PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021...
-
Page 7: Section 1: Overview
1.4 About This Manual This Manual is intended to be a complete reference for all installation and operation tasks for the TR-FFT. For additional infor- mation, refer to the following FACP Installation Manuals. The documents are located on the Triga website, www.triga- global.com. -
Page 8: Section 2: Prerequisites For Installation
Do not mount the panel in areas with humidity-generating equipment (such as dryers, production machinery). When you select a location to mount the TR-FFT, the unit must be mounted where it will NOT be exposed to temperatures out- side the range of 0°C- 49°C (32°F-120°F) or humidity outside the range of 10% - 93% at 30°C (86°F) non-condensing. - Page 9 Figure 2.2 TR-FFT Front View Active (green) Trouble (amber) Zone 33 - Zone 25 - Zone 41- Zone 40 Zone 32 Zone 48 Figure 2.3 TR-24Z-EXT Expander Front View for Zone 25 - 48 PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021...
-
Page 10: Electrical Specifications
Figure 2.4 TR-24Z-EXT- Expander Front View for Zone 49 - 72 2.4 Electrical Specifications 2.4.1 Power Requirements The voltage for the TR-FFT must be a power-limited, filtered, non-resettable nominal 24 VDC source. The voltage source must be within the range of 17-29 VDC. Circuits... -
Page 11: Wiring Specifications
Non-Power-limited Relay Circuit Power-Limited Non power-limited wiring must be run separately from power-limited wiring. Figure 2.5 Wire Routing Example PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... -
Page 12: Section 3: Installation
Section 3: Installation 3.1 Mounting the Cabinet Read the Environmental Specifications in Section 2.1 before you mount the TR-FFT cabinet. This will ensure that you select a suitable location. The TR-FFT cabinet can be surface or flush-mounted. Do NOT flush-mount in a wall designed as a fire break. - Page 13 Trim Ring Cabinet Figure 3.3 Trim Ring Around cabinet Use the self-tapping sheet metal screws to secure the trim ring from the inside of the cabinet. Re-attach the cabinet door assembly. PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021...
-
Page 14: Fire Fighter's Handset Installation
Attach the strain relief clip to the phone cord. The strain relief clip should have about 2 ¾” (6.99cm) length of phone cord through it. See Figure 3.6. Push the strain into the hole in the dead front panel. PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... -
Page 15: Tr-24Z-Ext Installation
TR-24Z-EXT Installation Figure 3.6 Strain Relief Clip Installation 3.3 TR-24Z-EXT Installation The TR-24Z-EXT expander board offers the option to add additional zones to the TR-FFT. To install the TR-24Z-EXT, do the following steps. Open the cabinet door and the dead front panel. -
Page 16: Tr-Fft Installation
Refer to Section 2.3 to identify the location of the DIP switches on the TR-FFT board. Configure the TR-FFT module by adding it to the System using the JumpStart feature. See Section 6.3 for information on the JumpStart Operation. Table 3.1 lists the possible DIP switch configurations. -
Page 17: Tr-Fft Fire Fighter Telephone Module Connection
3.7 TR-FFT Fire Fighter Telephone Module Connection The TR-FFT provides the connection for a single Class B or Class A telephone audio circuit. See Section 4 and Section 5 for examples of audio zone configurations. A monitor module can be used to monitor the connection of the Fire Fighter Telephone remote handset (TR-RHS) into the TR-FPJ, which is then displayed on the TR-FFT active zone LED during the JumpStart fea- ture. -
Page 18: Tr-Stsr/Tr-Stss Installation
Install the telephone chassis assembly in the backbox. Install the trim ring on the backbox using the 6-32 wing nuts. Do not tighten. Install the door assembly. To secure, tighten the wing nuts. PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... - Page 19 Connect to the TR-FFT to SLC Terminal TB4 connectors or the other mini-monitors Contact EOL set to Connected *See Figure 3.14 for EOL example Figure 3.13 TR-STS Telephone Connection Figure 3.14 EOL Example PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021...
-
Page 20: Section 4: Slc Device Installation
Table 4.1 SLC Devices 4.2 Maximum Number of Devices The TR-FFT supports up to 72 TR-MINIMON devices on one TR-FFT System. 4.3 Wiring Requirements for SLC Device The information in Section 4.3 and Section 4.4 pertains to the TR-MINIMON - Mini Monitor Module. -
Page 21: 2: Wiring Slc Devices In (Class A) Configuration
TR-FFT. Figure 4.3 Class A SLC Configuration NOTE: Class A does not require the use of the isolator modules.There are no T-taps allowed on the Class A SLC loops. PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... -
Page 22: Addressing The Tr-Minimon Slc Devices
Example 2: To select the device address 42, turn the ONES rotary dial to 2 and turn the TENS rotary dial to 4 as show in Figure 4.4. Example 1: Device set to 10 Example 2: Device Set to 42 Figure 4.4 TR-MINIMON SLC Device Addressing using the Rotary Dials PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... -
Page 23: Section 5: Audio Phone Circuit Installation
Table 5.1 Devices 5.2 Maximum Number of Devices The TR-FFT supports up to 72 zones. Each zone consists of one addressable monitor module (TR-MINIMON) and a mini- mum of one Fire Fighter Telephone Jack (TR-FPJ). 5.3 Wiring Requirements for the Audio Telephone Circuit In Section 5.3, the information pertains to the TR-FPJ Fire Fighter Phone Jack. -
Page 24: 2: Single Phone Jack Audio Circuit Wired In Class A Configuration
For information on the wiring specifications, see Section 5.3.1. Figure 5.3 illustrates the Phone Jack Audio Circuit (Class A) and SLC for the (Class A) configuration. Contact EOL Connected TR-FFT TR-FPJ TR-FPJ TR-FPJ Figure 5.3 Single Phone Jack Audio Circuit in Class A PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... -
Page 25: 3: Multi-Phone Jack Audio Circuit Wired In Class B Configuration
TR-FPJ TR-FPJ 4.7K W, 1/2 watt ELR (Install on the last device for Class B telephone circuit only). TR-FPJ TR-FPJ TR-FPJ Figure 5.4 Multi-Phone Jack Audio Circuit Wired in Class B PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... -
Page 26: 4: Multi-Phone Jack Audio Circuit In Class A Configuration
TR-FPJ must be less that 100 ohms. TR-FFT TR-FPJ TR-FPJ TR-FPJ TR-FPJ TR-FPJ TR-FPJ Figure 5.5 Multi-Phone jack Audio Circuit Wired in Class A PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021... -
Page 27: 5: Telephone Jack Only Audio Circuit
The TR-FFT can be configured using only the Fire Fighter’s Phone Jack (TR-FPJ). In this configuration, the TR-MINIMON module is not required for the System operation. To configure the TR-FFT for only the Telephone Jack, the DIP Switch posi- tion One must be set to OFF (SLC Devices not Installed). See Table 3.1. -
Page 28: Section 6: System Operation
6.2.1 Power Status LED The Power Status LED is located on the left side of the TR-FFT board. On Power-Up, the Power Status LED will blink at a 50% on/off rate until the TR-FFT initialization is complete (which takes approximately 20 seconds). Once initialization is complete, the Power Status LED will blink at a 10% on and 90% off rate. -
Page 29: 9: Zone Trouble
Press and hold the JumpStart button for two seconds. The TR-FFT will search for the installed SLC devices and activate the Active LED’s of all zone/point addresses found. When the JumpStart is complete, the first four status LEDs will blink. -
Page 30: Appendix A: Compatible Powering Devices
Appendix A: Compatible Powering Devices A.1 Compatible Power Devices Table A.1 lists the available Triga Series compatible power device used with the TR-FFT. Model Manual PN TR-2100/ECS Control Panel Manual LS10143-003TR-E TR-RPS1 Power Supply LS10259-002TR-E Table A.1 Compatible Powering Devices... - Page 31 TRIGA Life Safety Systems, LLC 7600 Olde Eight Rd. Hudson, OH 44236-1057 Telephone: +1-330-577-5199 www.trigaglobal.com...
- Page 32 Model TR-FFT Basic Operating Instructions These Instructions must be framed and displayed next to the TR-FFT panel in accordance with NFPA 72 fire code for Local Protected Fire Alarm Systems. Test the system in accordance to NFPA 72. Refer to Installation Manual P/N LS10309-001TR-E for more information regarding this control panel.
