Panasonic SA-PM17E Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Order No. MD0205132C2
CD Stereo System
SA-PM17E / SA-PM17EB / SA-PM17EG
Colour
(S) ... Silver Type
SPECIFICATIONS
Specification
1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SA-PM17E

Summary of Contents for Panasonic SA-PM17E

  • Page 1 Order No. MD0205132C2 CD Stereo System SA-PM17E / SA-PM17EB / SA-PM17EG Colour (S) ... Silver Type SPECIFICATIONS Specification...
  • Page 2 Amplifier Section RMS Power output 10% Total harmonic distortion 1 kHz, both channels driven (Low 25 W per channel (6 channel) 8 kHz, both channels driven (High 25 W per channel (6 channel) Total Bi-Amp power 50 W per channel Input sensitivity 250 mV Input impedance...

  • Page 3: Before Repair And Adjustment

    General Power supply AC 230 V, 50 Hz Power consumption 100 W Dimensions (W x H x D) 179 x 241 x 375 mm Mass 5.6 kg Power consumption in standby Approx. 0.7 W mode Music Center: SA-PM17(E) System: SC-PM17(E) Speaker: SB-PM17(P) Music Center: SA-PM17(EB) System: SC-PM17(EB)
  • Page 4 2. Determine the cause of the problem and correct it. 3. Turn on the power once again after one minute. Note: When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again. 3.

  • Page 5: Caution For Ac Mains Lead

    Remote Control Transmitter..1 pc 4. Caution for AC Mains Lead...

  • Page 6: Self-Diagnostic Display Function

    5. Self-Diagnostic Display Function This unit is equipped with a self-diagnostic display function, which will be useful during servicing and maintenance. - Refer to the next page for display symbols, symptoms, etc. 5.1. Preparations 1. A Cr02-positioned blank cassette tape with an erase prevention niche on either Side A or B.
  • Page 7 both Sides A and B. Both tapes are halfway forwarded in advance. 3. The remote controller that comes with this unit. 5.2. Setting of the Self-Diagnostic Mode 5.3. Restoring Normal Display - From the F76 display, the normal display does not appear till an error is recovered.
  • Page 8 respective indication is displayed when " /-DEMO" button is pressing repeatedly. (e.g. H01 CD F15 F01) / If no error is found, only "TEST" indication is displayed and remains unchange even if " /-DEMO" button is pressed. 5.5. Displaying Self-Diagnostic Results <Cassette Deck Section>...

  • Page 9: Handling Precautions For Traverse Deck

    silent sections (such as classical music). - and/or Music recorded with fade in/out effect. 6. Handling Precautions For Traverse Deck The laser diode in the traverse deck (optical pickup) may break down due to potential difference caused by static electricity of clothes or human body. So, be careful of electrostatic breakdown during repair of the traverse deck (optical pickup).
  • Page 10 in as short time as possible. 4. Do not turn the variable resistor (laser power adjustment). It has already been adjusted. - Grounding for electrostatic breakdown prevention 1. Human body grounding Use the anti-static wrist strap to discharge the static electricity from your body.

  • Page 11: Precaution Of Laser Diode

    7. Precaution of Laser Diode CAUTION: This product utilizes a laser diode with the unit truned “ON”, invisible laser radiation is emitted from the pick up lens. / Wavelength : 780 nm / Maximum output radiation power from pick up : 100 W/VDE / Laser radiation from pick up unit is safety level, but be sure the followings: 1.
  • Page 12 3. Nicht mit optischen Instrumenten in die Fokussierlinse blicken. 4. Nicht über längere Zeit in die Fokussierlinse blicken. ADVARSEL: I dette a apparat anvendes laser. CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

  • Page 13: Front Panel Controls

    8. Front Panel Controls...

  • Page 15: Disassembly And Main Component Replacement Procedures

    9. Disassembly and Main Component Replacement Procedures. “ATTENTION SERVICER” Some chassis components maybe have sharp edges. Be careful when diassembling and servicing. 1. This section describes procedures for checking the operation of the major printed circuit boards and replacing the main components.
  • Page 16 - Disassembly of Traverse Mechanism - Main Component Replacement Procedures 1. Procedure of replacing Cassette Holder 2. Procedure of replacing Pinch Roller and Head Block (Cassette Mechanism Unit) 3. Procedure of replacing Motor, Capstan Belt A, Capstan Belt B and Winding Belt (Cassette Mechanism Unit) 4.
  • Page 17 Step 3 Remove all the screws and pull up the cassette lid as the arrow shown. Step 4 Release the connectors CN307, CN308 and CN1303. Remove the cassette lid. Step 5 Release the connector CN310 and pull out the back cover as the arrow shown.
  • Page 18 Step 6 Release the connectors CN504, CN305 and CN301. Step 7 Release the connectors CN606, CN602, CN505, CN500 and remove all the screws.
  • Page 19 Step 8 Remove all the screws. Step 9 Release the catches and pull out the front panel as the arrow shown. Step 10 Remove all the screws and release the connector CN607A.
  • Page 20 Steps 11 & 12 Remove all the screws. Step 13 Remove all the screws and pull up the cover as the arrow shown.
  • Page 21 Step 14 Remove all the screws. Step 15 Reconnect all the connectors back to do the testing. 9.2. Procedure for Replacing Cassette Holder - Follow Steps 1 to 4 described in Item 9.1. Step 2 Press the lever to open the cassette cover.
  • Page 22 9.3. Procedure for Replacing Pinch Roller and Head Block (Cassette Mechanism Unit) - Follow Steps 1 to 4 described in Item 9.1. - Follow Steps 1 to 3 described in Item 9.2.
  • Page 24 9.4. Procedure for Replacing Motor, Capstan Belt A, Capstan Belt B, and Winding Belt (Cassette Mechanism Unit) - Follow Steps 1 to 4 described in Item 9.1. - Follow Steps 1 to 3 described in Item 9.2. - Follow Steps 2 to 4 described in Item 9.3.
  • Page 26 9.5. Procedure for Replacing Parts on Mechanism PCB - Follow Steps 1 to 4 described in Item 9.1.
  • Page 27 - Follow Steps 1 to 3 described in Item9.2. - Follow Steps 2 to 4 described in Item 9.3. 9.6. Replacement of CD traverse deck - Follow Steps 1 to 14 described in Item 9.1.
  • Page 28 9.7. Replacement of optical pickup unit (CD mechanism) - Follow Steps 1 to 14 described in Item 9.1. - Follow Steps 1 to 2 described in Item 9.6.
  • Page 32 9.8. Replacement of a traverse gear A and a traverse gear B - Follow Steps 1 to 14 described in Item 9.1. - Follow Steps 1 to 2 described in Item 9.6. - Follow Steps 1 to 12 described in Item 9.7.
  • Page 33 9.9. Disassembly of CD loading unit 9.9.1. Regarding a jig "gear" - The gear is equipped to the unit to check the opening and closing of the disk tray and the hoisting of traverse unit manually at the maintenance service. (The usage of the gear is described in this disassembly procedure).
  • Page 34 used. 1. Remove the gear attached to the top cover of CD loading mechanism. 2. Insert a hexagonal wrench of 2.5mm (opposite side diameter) into the gear. 9.10. Replacement of disk tray - Follow Steps 1 to 14 described in Item 9.1.
  • Page 37 9.11. Replacement of the traverse mechanism - Follow Steps 1 to 7 described in Item 9.10.
  • Page 38 9.12. Disassembly of CD loading section - Follow Steps 1 to 7 described in Item 9.10. - Follow Step 1 described in Item 9.11.
  • Page 42 9.13. Assembly of CD loading unit - For assembly of CD loading unit, follow the reverse way of the disassembly procedure. And see following procedure as there are some points to be noticed in the assembly. 9.13.1. Notes on fixing of CD loading section 9.13.1.1.
  • Page 43 9.13.1.2. Notes on fixture of a vertical drive gear and GENEVA gear 1. Fix a vertical drive gear, GENEVA gear, a vertical reduction gear, gears (2 pieces) and a relay gear. 2. The marking should be at the position as shown below figure to fix a vertical drive gear.
  • Page 44 3. Set a hole as shown below to fix GENEVA gear. 9.13.1.3. Notes on fixing a vertical rack (L) 1. Fix vertical rack (L) and (R). 2. Position the concave portion of a vertical rack (L) to trapezoidal...
  • Page 45 cog of a vertical rack (L) and fix. 3. Fix a timing gear plate and a timing gear, then fasten them with screws. 9.13.1.4. Notes on fixing of a change gear and a main gear 1. Fix a change lever and a change gear following 2. Then fix a level drive gear and a main gear spring, and fix a main gear following 3 and 4.
  • Page 46 2. Position a convex portion of a change gear to a marking of a mechanism base and fix. 3. Position a hole of a main gear against a boss (a) of a mechanism base and fix. 4. Rotate a main gear to the arrow direction to position a hole of a main gear to a boss (b).
  • Page 47 5. Draw up a select rack to the far front part. 9.13.1.5. Notes on fixing a pitch plate 1. Fix a reduction gear (2), a relay gear, a pulley gear, a tray relaying gear and a large belt (2).
  • Page 48 2. Fix a level reduction gear (1), a horizontal reduction gear (2), a relay gear, a reverse gear, a speedup gear and a small belt (1). 3. Position the edge of a dividing lever (1) to the position shown in figure 1.
  • Page 49 9.13.1.6. Notes on fixing a traverse mechanism 1. Fix a vertical lever. (Fit a rib into both side grooves) 2. Fit a traverse mechanism into the groove. 3. The projecting portion of a dividing lever (2) should be inserted...
  • Page 50 into a concave portion of a dividing lever (1). 4. Set a loading gear at the position shown by figure 2. 5. Draw a vertical rack (R) to the arrow direction. 9.13.1.7. Notes on fixing a disk tray 1. Fix a tray drive gear and a tray drive gear shaft. / (Position the lowest rib of a tray drive gear to be level) 2.
  • Page 51 3. Check the phase. A. The projecting portion of a dividing lever (2) should be inserted into a concave portion of a dividing lever (a). B. Seta loading gear at the position shown by figure 2. C. The hole A of pitch plate should be positioned at a hole of a main gear.
  • Page 52 5. Fix a speedup lock. 6. Fix an open switch lever. / (Insert a boss of an open switch lever into the hole of mechanism base)
  • Page 53 7. Fix a top cover. / (Fix to the arrow direction after putting into the catch) 9.14. Disassembly of traverse mechanism - Follow Steps 1 to 14 described in Item 9.1. - Follow Steps 1 to 7 described in Item 9.10. - Follow Step 1 descrbed in Item 9.11.
  • Page 55 9.15. Handling of cassette tape jam - Follow Steps 1 to 3 described in Item 9.1.

  • Page 56: Procedure For Checking Operation Of Individual Parts Of Cassette Mechanism Unit

    10. Procedure for Checking Operation of Individual Parts of Cassette Mechanism Unit 10.1. Operation Check with Cassette Tape 1. Pull up the EJECT lever using a rubber band. (Cf. Fig. 6) 2. Supply DC5V to MOTOR. ( MOTOR rotates.) (Cf. Fig. 5) 3.
  • Page 57 : approx. 5msec) D. REV PLAY: Supply the plunger power in a normal timing at STOP mode. (ON: approx. 200msec) E. REV REW: Supply the plunger power in a flash at REV PLAY mode. (ON: approx. 50msec) F. STOP: Supply the plunger power in a flash at FF mode. (ON: approx.

  • Page 58: Measurement And Adjustments

    3. Lift up the mechanism unit’s plunger/rib with the tip of a negative screwdriver, and operate the unit in the same timing as / supplying the power. (Cf. Fig. 7) / (Note) Follow Step 4 in Item 1.1. for procedure on operating each function. 11.
  • Page 59 Block (Cassette Mechanism Unit)] under [9. Disassembly and Main Component Replacement Procedures before Operation Checks]. 3. Connect the headphone jack output jig (cf. Fig. 8) to headphone jack. 11.2.4. Head Azimuth Adjustment 1. Connect an oscilloscope. (Cf. Fig. 10) 2. Playback the azimuth adjustment portion (8kHz, -20dB) of the test tape (QZZCFM).
  • Page 60 is played in forward and reverse directions does not exceed 1.5dB. 5. After the adjustment, fasten screwlock to the azimuth adjusting screw. (Note) Before adjusting the head azimuth, be sure to remove the screwlock adhesive attached around the head for fine adjustments.
  • Page 61 11.2.6. Bias Voltage Check 1. Connect an electrical voltmeter. (Cf. Fig. 9) (Cf. Fig. 14) 2. Set the function to “TAPE” position. 3. Insert a normal blank cassette tape (QZZCRA). 4. While pressing and holding down [REC ( )] button, press [TAPE ( )] button to pause the recording mode.
  • Page 62 Switch Switch Switch Trigger Switch S600 Rec Switch S601 Preset EQ Switch S602 Tape Eject Switch S603 Rew Switch S604 Stop/Demo Switch S605 FF Switch S606 CD Play/Pause Switch S607 Tape Play Switch S608 Tuner/Band Switch S609 AUX Switch S610 CD Current Switch S611 Exchange Switch...

  • Page 63: Printed Circuit Board

    (capacitors), low-noise (resistors), etc. are used. When replacing any of components, be sure to use only manufacturer’s specified parts shown in the parts list. Caution! IC, LSI and VLSI are sensitive to static electricity. Secondary trouble can be prevented by taking care during repair. - Cover the parts boxes made of plastics with aluminium foil.

  • Page 64: Troubleshooting Flowchart (Cd Section Circuit)

    16. Troubleshooting Flowchart (CD Section Circuit)
  • Page 66 17. Type Illustrations of ICs, Transistors & Diodes 18. Terminal Function of IC’s 18.1. IC701 (AN8885SBE1) Servo Amplifier...
  • Page 67 Pin No. Mark Function Tracking signal input 1 Tracking signal input 2 Power supply Focus signal input terminal 1 Focus signal input terminal 2 APC amp input APC amp output RFsumming output RFIN Detector’s input CSBRT I Capacitor for OFTR connection Capacitor for HPF amp connection...
  • Page 68 Mark Function BCLK N.C. LRCK N.C. SRDATA O N.C. DVDD1 Power supply input (for digital circuit) DVSS1 GND (for digital circuit) Digital audio interface signal output (Latches data at first transition) MCLK Microprocessor command clock signal input MDATA Microprocessor command data signal input Microprocessor command load signal...
  • Page 69 Mark Function /RST Reset signal input SMCK 1/2-diveded clock signal of crystal osscillating at MSEL = “H” (fSMCK = 8.4672 MHz) 1/4-divided clock signal of crystal oscillating at MSEL = “L” (fSMCK = 4.2336 MHz) CSEL Frequency Selection Terminal H = 33.8688 MHz ;...
  • Page 70 Mark Function TRCRS Track cross signal input /RFDET RF detection signal input ("L" : detection) Dropout signal input ("H" : Dropout) LDON Laser on signal output ("H" : ON) PLLF2 N.C. DSLF2 Tracking Offset alignment output/DSL Balance Output (DA Output) WVEL N.C.
  • Page 71 Mark Function X1 IN Crystal oscillating circuit input (f = 16.9344MHz) X2 OUT Crystal oscillating circuit input (f = 16.9344 MHz) Power supply input (for oscillating circuit) BYTCK Byte clock output /CLDCK Sub-code frame clock signal output (fCLDCK = 7.35 kHz during normal playback) FCLK...
  • Page 72 Mark Function RSEL RF signal polarity assignment input (at "H" level, RSEL="H", at "L" level, RESL= "L") IOVOD 5V supply input PSEL Test terminal (connected to Gnd) MSEL SMCK oscillating frequency designation input (“L” :4.2336 MHz, “H”: 8.4672 MHz) SSEL SUBQ output mode select (“H”:Q-code buffer mode)

  • Page 73: Parts Location And Replacement Parts List

    Mark Function Motor driver (4) reverse- action output Motor driver (4) forward- action output N.C. PGND2 - Ground connection (2) for driver PVCC2 I Power supply (2) for driver N.C. Power supply terminal VREF Reference voltage input Motor driver (4) input Motor driver (3) input RSTIN Reset terminal...
  • Page 74 1,000(ohms). - The marking (RTL) indicates that the Retention Time is limited for this item. After the discontinuation of this assembly in production, the item will continue to be available for a specific period of time. The retention period of availability is dependant on the type of assembly, and in accordance with the lows govening part and product retention.
  • Page 75 19.1.2. Deck Mechanism Parts List...

  • Page 76: Cassette Deck

    Ref. No. Part No. Part Name & Description Remarks CASSETTE DECK RED0067 R/P HEAD BLOCK UNIT RDG0300 REEL BASE GEAR RDG0301 WINDING RELAY GEAR RDK0026 MAIN GEAR RDV0033-4 WINDING BELT RDV0064 CAPSTAN BELT RMB0312 TRIGGER LEVER SPRING RMB0400 REEL SPRING RMB0403 HEAB PANEL SPRING RMB0404...
  • Page 80 19.2.2. CD Loading Mechanism Parts List...
  • Page 81 Ref. No. Part No. Part Name & Description Remarks TRAVERSE DECK RAE0155A-V TRV UNIT WITHOUT SER RDG0455 TRAVERSE GEAR (A) RDG0456 TRAVERSE GEAR (B) RDG0519 MAIN GEAR RDG0520 SPEED UP GEAR RDG0521 TRAVERSE GEAR RDG0522 GENEVA GEAR RDG0523 HOR RELAY GEAR RDG0525 CROWN GEAR RDG0526...
  • Page 82 Ref. No. Part No. Part Name & Description Remarks RMM0242 TRV.SLIDE PLATE [R] RMM0243 SELECT RACK RMM0244 SELECT GUIDE RMQ1051 PITCH PLATE RMQ1052 UD BASE RMQ1056 TRAY GUIDE [L] RMQ1057 TRAY GUIDE [R] RMQ1058 GEAR HOLDER RMQ1059 TOP COVER RMQ1060 CLAMP GUIDE RMQ1061 TG.PLATE...
  • Page 84 19.3.2. Cabinet & CD Loading Machanism Parts List...
  • Page 85 Ref. No. Part No. Part Name & Description Remarks CABINET AND CHASSIS REE1172 3P BLUE LED REEX0165 14P FFC REEX0166 14P FFC WIRE REEX0167 19P CD FFC REEX0168 30P FFC REM0094 COLLING FAN RGK1512-S VOLUMW RING RGK1513-S REC BUTTON RING RGKX0117-S FRONT ORNAMENT RGKX0126...
  • Page 86 Ref. No. Part No. Part Name & Description Remarks XTW3+15T SCREW RGCX0005-W L/PIECE REFLECTOR RDG0357 DAMPER GEAR XTWS3+8T SCREW 19.4. Components Parts List Ref. No. Part No. Part Name & Description Remarks P.C.B. REP2807D CD SERVO P.C.B. REPX0289A DECK P.C.B. REPX0108G DECK MECHANISM P.C.B.
  • Page 87 Ref. No. Part No. Part Name & Description Remarks Q510 KRA110MTA TRANSISTOR Q514 2SD0592ARA TRANSISTOR Q515 KTC3199GRTA TRANSISTOR Q516 KTC3199GRTA TRANSISTOR Q517 KTC32030YTA TRANSISTOR Q519 B1AAGC000006 TRANSISTOR Q575 B1AAGC000006 TRANSISTOR Q577 2SC3940ARA TRANSISTOR Q578 KRC102MTA TRANSISTOR Q579 2SB621ARSTA TRANSISTOR Q607 KRC103STA TRANSISTOR Q608...
  • Page 89 Ref. No. Part No. Part Name & Description Remarks DIODES D101 UDZSTE175R1B DIODE D301 RL1N4003S-P DIODE D302 RL1N4003S-P DIODE D500 KBL402G DIODE D505 B0AACK000004 DIODE D508 MAZ4150NLF DIODE D515 B0BA9R600002 DIODE D517 B0BA5R600016 DIODE D518 B0AACK000004 DIODE D520 B0BA9R600002 DIODE D524 MAZ4150NMF DIODE...
  • Page 90 Ref. No. Part No. Part Name & Description Remarks D702 B0AACK000004 DIODE D703 B0AACK000004 DIODE D704 B0AACK000004 DIODE D705 B0AACK000004 DIODE D706 B0AACK000004 DIODE D707 B0AACK000004 DIODE D708 MA2C16500E DIODE D709 MA2C16500E DIODE D743 1D3E DIODE D750 MAZ80560ML DIODE D951 MA2C16500E DIODE D1301...
  • Page 91 Ref. No. Part No. Part Name & Description Remarks CN305 RJS2A8030 P1 FFC CONNECTOR ST CN306 K1MN14C00004 14P FFC CONNECTOR CN307 K1MP09A00002 TO MAIN MOLEX CN308 K1KA02B00115 LASER CONNECTOR CN310 K1KA02A00008 FAN CONNECTOR CN500 K1MN14A00049 FF CONNECTOR CN504 RJT119W08V CONNECTOR CN505 K1KB07A00016 7P CONNECTOR...
  • Page 93 Ref. No. Part No. Part Name & Description Remarks Z602 B3RAB0000016 INFRARED RAYS SP600 RMB0712 EARTH SPRING CERAMIC FILTERS CF201 J0B1075A0086 CERAMIC CAPACITOR CF202 J0B1075A0077 CERAMIC FILTER RELAY RL501 RSY0040M-0 POWER RELAY OSCILLATORS X102 RLFDFT22DD CRYSTAL OSCILLATOR X103 H0H720400005 CRYSTAL OSCILLATOR X391 H0H433400001 CRYSTAL OSCILLATOR...
  • Page 94 JACKS...
  • Page 95 Ref. No. Part No. Part Name & Description Remarks JK101 RJH8304N JK ANTENNA JK301 K4BC04B00036 JK RED/BLACK SPEAKER JK302 K4BC04B00037 JK BLUE/GRAY SPEAKER JK303 RJH2213N-1 JK 2P RCA PIN JK501 K2AA2B000004 JK AC INLET JK600 RJJ37TK07-X JK HEADPHONE EARTH TERMINAL E501 SNE1004-2 EARTH TERMINAL...
  • Page 96 R125 ERJ3GEYJ471V 470 1/16W Ref. No. Part No. Part Name & Description Remarks R126 ERJ3GEYJ102V 1K 1/16W R127 ERJ3GEYJ471V 470 1/16W R128 ERJ3GEYJ820V 82 1/16W R129 ERJ3GEYJ273V 27K 1/16W R130 ERJ3GEYJ103V 10K 1/16W R131 ERJ3GEYJ680V 68 1/16W R132 ERJ3GEYJ103V 10K 1/16W R133 ERJ3GEYJ102V 1K 1/16W...
  • Page 97 Ref. No. Part No. Part Name & Description Remarks R402 ERJ3GEYJ182V 1.8K 1/16W R403 ERJ3GEYJ822V 8.2K 1/16W R404 ERJ3GEYJ223V 22K 1/16W R405 ERJ3GEYJ223V 22K 1/16W R406 ERJ3GEYJ682V 6.8K 1/16W R407 ERJ3GEYJ183V 18K 1/16W R408 ERJ3GEYJ182V 1.8K 1/16W R411 ERJ3GEYJ392V 3.9K 1/16W R412 ERJ3GEYJ102V 1K 1/16W...
  • Page 98 Ref. No. Part No. Part Name & Description Remarks R549 ERDS1FVJ2R2T 2.2 1/2W R550 ERDS1FVJ331T 330 1/2W R551 ERDS2TJ104T 100K 1/4W R554 ERDS1FVJ331T 330 1/2W R556 ERD2FCVG270T 27 1/4W R557 ERDS1FVJ270T 27 1/2W R561 ERDS2TJ104T 100K 1/4W R562 ERDS2TJ394T 390K 1/4W R565 ERDS2TJ123T 12K 1/4W...
  • Page 99 Ref. No. Part No. Part Name & Description Remarks R623 ERJ3GEYJ223V 22K 1/16W R624 ERJ3GEYJ101V 100 1/16W R625 ERJ3GEYJ472V 4.7K 1/16W R626 ERJ3GEYJ472V 4.7K 1/16W R627 ERJ3GEYJ473V 47K 1/16W R628 ERJ3GEYJ473V 47K 1/16W R629 ERJ3GEYJ472V 4.7K 1/16W R630 ERJ3GEYJ101V 100 1/16W R631 ERJ3GEYJ101V 100 1/16W...
  • Page 100 Ref. No. Part No. Part Name & Description Remarks R681 ERJ3GEYJ103V 10K 1/16W R682 ERJ3GEYJ471V 470 1/16W R683 ERJ3GEYJ473V 47K 1/16W R684 ERJ3GEYJ223V 22K 1/16W R685 ERJ3GEYJ474V 470K 1/16W R686 ERJ3GEYJ472V 4.7K 1/16W R687 ERJ3GEYJ680V 68 1/16W R688 ERJ3GEYJ680V 68 1/16W R689 ERJ3GEYJ392V 3.9K 1/16W...
  • Page 101 Ref. No. Part No. Part Name & Description Remarks R724 ERDS2TJ104T 100K 1/4W R724 ERJ3GEYJ153V 15K 1/16W R725 ERDS2TJ102T 1K 1/4W R725 ERJ3GEYJ681V 680 1/16W R726 ERDS2TJ273T 27K 1/4W R727 ERDS2TJ104T 100K 1/4W R727 ERJ3GEYJ272V 2.7K 1/16W R728 ERDS2TJ102T 1K 1/4W R728 ERJ3GEYJ222V 2.2K 1/16W...
  • Page 102 Ref. No. Part No. Part Name & Description Remarks R762 ERDS2TJ103T 10K 1/4W R763 ERDS2TJ103T 10K 1/4W R764 ERDS2TJ683T 68K 1/4W R765 ERDS2TJ683T 68K 1/4W R766 ERDS2TJ153T 15K 1/4W R767 ERDS2TJ153T 15K 1/4W R768 ERDS2TJ472T 4.7K 1/4W R769 ERDS2TJ472T 4.7K 1/4W R770 ERDS2TJ332T 3.3K 1/4W...
  • Page 103 Ref. No. Part No. Part Name & Description Remarks R1107 ERJ3GEYJ102V 1K 1/16W R1109 ERJ3GEYJ102V 1K 1/16W R1110 ERJ3GEYJ333V 33K 1/16W R1201 ERJ3GEYJ270V 27 1/16W R1202 ERJ3GEYJ152V 1.5K 1/16W R1203 ERJ3GEYJ183V 18K 1/16W R1204 ERJ3GEYJ103V 10K 1/16W R1205 ERJ3GEYJ222V 2.2K 1/16W R1206 ERJ3GEYJ104V 100K 1/16W...
  • Page 104 ECA1CAK101XB 100 16V...
  • Page 105 Ref. No. Part No. Part Name & Description Remarks C101 ECUV1E103KBV 0.01 25V C102 ECA1CAK101XB 100 16V C103 ECUV1E103KBV 0.01 25V C104 ECJ1VB1H102K 1000P 50V C105 ECJ1VB1H102K 1000P 50V C106 ECUV1H103KBV 0.01 50V C107 ECUV1C473KBV 0.047 16V C108 ECUV1H080DCV 8P 50V C109 ECJ1VB1H102K 1000P 50V...
  • Page 106 Ref. No. Part No. Part Name & Description Remarks C212 ECQV1H394JZ3 0.39 50V C213 ECA1CAK100XB 10 16V C215 ECA1HAK2R2XB 2.2 50V C217 ECJ1VB1H102K 1000P 50V C218 ECUV1E473KBV 0.047 25V C219 ECUV1E473KBV 0.047 25V C220 ECUV1E473KBV 0.047 25V C221 ECUV1E473KBV 0.047 25V C222 ECUV1E473KBV 0.047 25V...
  • Page 107 Ref. No. Part No. Part Name & Description Remarks C508 ECA1EAM332XE 3300 25V C509 F1D1H330A006 33P 50V C510 F1D1H330A006 33P 50V C511 ECKR1H103ZF5 0.01 50V C512 ECA1CAK101XB 100 16V C513 ECKR1H103ZF5 0.01 50V C514 ECA1AAK330XB 33 10V C515 ECBT1H103KB5 0.01 50V C516 ECA1HAK100XB 10 50V...
  • Page 108 Ref. No. Part No. Part Name & Description Remarks C636 ECUV1H180JCV 18P 50V C637 ECUV1H560JCV 56P 50V C638 ECUV1H560JCV 56P 50V C639 ECJ1VB1H102K 1000P 50V C640 ECJ1VB1H102K 1000P 50V C641 ECUV1H103KBV 0.01 50V C642 ECUV1H101JCV 100P 50V C643 ECUV1H101JCV 100P 50V C644 ECA1HAK010XB 1 50V...
  • Page 109 Ref. No. Part No. Part Name & Description Remarks C716 ECA1HAK2R2XB 2.2 50V C716 ECJ1VB1H821K 820 50V C717 ECFR1C273KR 0.027 16V C717 ECUV1E104ZFV 0.1 25V C717 F1D1C472A010 4700P 16V [M]EB C718 ECUV1A224KBV 0.22 10V C720 ECA1HAK010XB 1 50V C721 ECUV1H100JCV 10P 50V C721 F1D1C682A010...
  • Page 110 Ref. No. Part No. Part Name & Description Remarks C747 ECUV1H181JCV 180P 50V C748 ECBT1H470JC5 47P 50V C749 ECBT1H822KB5 8200P 50V C749 ECUV1H222KBV 2200P 50V C750 ECBT1H822KB5 8200P 50V C750 ECUV1C104KBV 0.1 16V C751 ECA1CAK100XB 10 16V C751 ECUV1C104KBV 0.1 16V C752 ECA1CAK100XB 10 16V...
  • Page 111 Ref. No. Part No. Part Name & Description Remarks C1315 ECUV1H222KBV 2200P 50V C1316 ECJ1VB1H102K 1000P 50V C1317 ECJ1VB1H102K 1000P 50V C1318 ECQV1H473JZ3 0.047 50V C1319 ECA1CAK101XB 100 16V C1320 ECA1HAK010XB 1 50V C1321 ECQP1472JZT 4700P 100V C1322 F0A2A102A010 1000P 100V C1323 ECEA1HKN010B 1 50V...

  • Page 112: Packing Materials

    Ref. No. Part No. Part Name & Description Remarks PACKING MATERIALS RPGX0931 PACKING CASE RPNX0145 POLYFOAM RPHV0001 MIRAMAT SHEET ACCESSORIES EUR648264 REMOTE CONTROL A1-1 UR64EC2337A R/C BATTERY COVER RJA0019-2K AC CORD (SF) [M]EG E VJA0733 AC CORD (SF) [M]EB RQT6398-B O/I BOOK (En) [M]EB E RQT6399-E...
  • Page 113 / Printed in Singapore / M020500001FLE/K/E/J/A/S/N...
  • Page 114 CD SERVO P.C.B (REP2807D) (RF) TJ701 X701 C727 TJ701 TP19 C725 C717 R714 C726 TP16 C721 C744 C728 C716 R709 C702 TP17 TP26 C722 TP24 TP25 C724 R712 TP18 TP35 TP27 C723 TP13 R721 IC701 TP14 J723 C730 C732 TP11 C711 J726 J702...
  • Page 115 IC701 CD OPTICAL PICKUP AN8885SBE1 SERVO AMP SEMICONDUCTOR LASER RFEQ1 Q701 OFTR LASER POWER DRIVE TENV RFEQ2 /RFDET /RFDET DET. VREF FEOUT SUBTRACTER PHOTO DETECTOR VREF TEOUT SUBTRACTER VREF BAND [CH3] LEVEL FOCUS COIL SHIFT RSTIN [CH4] TRACKING COIL LEVEL SHIFT TRV+ M701...
  • Page 116 TO MAIN BLOCK IC702 MN662790RSC SERVO PROCESSOR /DIGITAL SIGNAL PROCESSOR DIGITAL FILTER /D/A CONVERTER CLVS OUTR BLKCK /CLDCK SBCK SUBC OUTL CD SIGNAL DEMPH SQCK ST/DO FLAG SUBQ SUBQ IPFLAG DIGITAL AUDIO INTERFACE PLLF DIGITAL AUDIO INTERFACE PLLF2 LRCK DSLF2 DSLF SRDATA INTERPOLATION/...
  • Page 117 AM ANT FM ANT CF202 Z120 CF201 Q101, Q102 Z101 SWITCHING, MIXER FM IF AMP (FM) RF AMP BUFFER COIL COIL (FM) Q110 DETECT SWITCH DECODER RM AMP PHASE PILOT BUFFER CANCEL LEVEL S-CURVE STEREO SWITCH AM/FM BUFFER COMP TUNING DRIVE PILOT X102...
  • Page 118 FILTER CD SIGNAL TEST LVREF CONTROL CIRCUIT JK303 CONTROL CIRCUIT INTERFACE CONTROL CIRCUIT RVREF VREF IC301 C1BB00000617 ELECTRONIC VOLUME CONTROL & TONE CONTROL MPXIN IC302 Q902 FLOUT C1BB00000527 X391 STAT STATUS SWITCH XOUT Q901 SUBQ SUBQ SWITCH Q903 BLKCK BLKCLK IC11 IC21 SWITCH...
  • Page 119 Q1101 (Q1201 ) MUTING SWITCH FILTER R/P HEAD (Lch) FILTER IC1001 AN7326K P/B REC AMP 22(1) 21(2) 20(3) 19(4) 15(8) 16(7) RIPPLE REJECTION LOGIC SWITCH REC AMP (L) MUTE IC1000 C1AA00000612 ANALOG SWITCH Q1302 DECK MUTING CONT. Q1304 SWITCH (REC:H) Q1317 Q1303 BEAT PROOF...
  • Page 120 IC501 Q1315 C0AABB000117 DUAL_OP_AMP SWITCH D951 Q721(Q720) Q1314, Q1316 SWITCH (MOTOR SUPPLY) HP_L(R) JK600 HEADPHONE Q503 Q507 D541 D518 MUTING MUTING SWITCH SWITCH MUTE_A Q905 Q904 D528 SYNC PLUNGER MOTOR SWITCH SWITCH Q510 MUTING SWITCH HP_L(R) Q704 MUTE_A MUTING CONTROL MUTEH KEY SW Q700~Q703...
  • Page 121 SIGNAL LINES : MAIN SIGNAL LINE : CD SIGNAL LINE : AM SIGNAL LINE : PLAYBACK SIGNAL LINE : FM OSC SIGNAL LINE : AM OSC SIGNAL LINE : FM & AM SIGNALS LINE : RECORD SIGNAL LINE : FM SIGNAL LINE : CD-DA (AUDIO/VIDEO) SIGNAL LINE : AUX SIGNAL LINE ( ) Indicates the Pin No.

  • Page 122: Schematic Diagram

    SCHEMATIC DIAGRAM -1 CD SERVO CIRCUIT : +B SIGNAL LINE : CD SIGNAL LINE R701 OPTICAL PICKUP CIRCUIT C701 Q701 6.3V33 3.2V 2SA1037AKSTX C703 LASER DIODE Q701 6.3V100 LASER POWER DRIVE CN701 2.7V ((2.3V)) 0.9V ((2V)) C704 R754 LD GND NBOUT C707 C714...
  • Page 123 SCHEMATIC DIAGRAM - 2 CD SERVO CIRCUIT : +B SIGNAL LINE : CD SIGNAL LINE D750 MAZ80560ML R717 C727 50V1 C725 1000P R721 C726 1000P R718 C728 50V1 R761 C731 4.7K 6.3V220 CN702 Lch OUT C754 C730 C733 C732 470P A.GND 6.3V220 Rch OUT...
  • Page 124 SCHEMATIC DIAGRAM-9 : PLAYBACK SIGNAL LINE DECK CIRCUIT : +B SIGNAL LINE : REC SIGNAL LINE C1105 470P R1103 C1122 C1102 0.01 470P R1101 R1104 C1104 C1303 C1307 0.027 0.033 10V220 C1101 50V1 C1121 C1107 1000P 1500P PBLIN Nor/Cro L NF GAIN Lout L EQ...
  • Page 125 SCHEMATIC DIAGRAM-10 : PLAYBACK SIGNAL LINE DECK CIRCUIT : +B SIGNAL LINE : REC SIGNAL LINE R1307 Q1101, 1201 B1ABG000005 MUTING SWITCH R1109 R1105 2.2K R1107 Q1101 C1110 R1106 6800P 100K C1123 270P R1308 R1205 R1209 2.2K R1207 Q1201 R1206 C1210 6800P 100K...

  • Page 126: Cd Loading Circuit

    SCHEMATIC DIAGRAM-14 CD LOADING CIRCUIT : +B SIGNAL LINE IC11 C0GAG0000007 UP/DOWN MOTOR DRIVE 0.01 16V100 RM11 UP/DOWN MOTOR BOTTOM OPEN B3NAA0000068 SENSOR STOCK PLAY MAIN CIRCUIT (CN306) ON SCHMEATIC DIAGRAM-3 IC21 C0GAG0000007 LOADING MOTOR DRIVE 0.01 16V100 RM21 LOADING MOTOR...
  • Page 127 SCHEMATIC DIAGRAM-3 : AUX SIGNAL LINE : PLAYBACK SIGNAL LINE MAIN CIRCUIT : +B SIGNAL LINE : AM/FM SIGNAL LINE : RECORD SIGNAL LINE LINE OUT R201 C201 R202 C225 470P 1.8K 1000P C401 R402 L392 470P 1.8K 100µH R401 C425 JK303 1000P...
  • Page 128 SCHEMATIC DIAGRAM-4 : AUX SIGNAL LINE : PLAYBACK SIGNAL LINE : MAIN SIGNAL LINE MAIN CIRCUIT : +B SIGNAL LINE : AM/FM SIGNAL LINE : RECORD SIGNAL LINE : CD SIGNAL LINE S602 TAPE EJECT DECK EJECT CIRCUIT W308 CN308/WH308 C416 C400 100P...

  • Page 129: Power-On Circuit

    SCHEMATIC DIAGRAM-7 PANEL CIRCUIT : +B SIGNAL LINE : MAIN SIGNAL LINE FL600 A2BD00000052 FL DISPLAY 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 C601 C602 35V22...
  • Page 130 SCHEMATIC DIAGRAM-8 DECK CIRCUIT (CN1303) ON : MAIN SIGNAL LINE SCHEMATIC DIAGRAM-10 PANEL CIRCUIT : +B SIGNAL LINE : CD SIGNAL LINE H600/W600 Q613,615 R687 R688 D632 L605 KRA119STA UDZSTE174R78 100µH LED DRIVE MOTOR Q904 Q905 C646 KRC101STA 50V3.3 KRC101STA MOTOR SWITCH PLUNGER SWITCH REC_LED...
  • Page 131 SCHEMATIC DIAGRAM-11 power pcb (EB) power pcb (E/EG) POWER CIRCUIT : +B SIGNAL LINE : MAIN SIGNAL LINE Q700 Q702 B1AACF000063 B1AACF000063 SWITCH R704 SWITCH Q701 KTA12710YTA R778 SWITCH Q701 C700 R702 R707 D708 6.3V100 R776 5.6K MA2C16500E Q720 KTC3199GRTA Q700 R774 C738...
  • Page 132 SCHEMATIC DIAGRAM-12 : -B SIGNAL LINE POWER CIRCUIT : +B SIGNAL LINE : MAIN SIGNAL LINE (E_EG) Q703 B1AACF000063 IC500 SWITCH IC500 RSN314H41A-P Q703 POWER AMP D707 C515 B0AACK000004 0.01 R709 C702 C503 820K 50V2.2 R514 820P HI_R C501 R506 C509 820P LO_L...
  • Page 133 SCHEMATIC DIAGRAM-13 ac transformer pcb (E/EG) ac transformer pcb (EB) AC TRANSFORMER CIRCUIT : +B SIGNAL LINE D581 D578 RL1N4003S-P R580 R581 R585 RL1N4003S-P C585 D585 D579 25V100 RL1N4003S-P RL1N4003S-P CN507A R583 Q577 Q577 C578 2SC3940ARA C584 C580 0.01 R584 16V1000 REGULATOR SYS 6V 0.01...

  • Page 134: Main (Tuner) Circuit

    SCHEMATIC DIAGRAM-5 : +B SIGNAL LINE : AM SIGNAL LINE MAIN (TUNER) CIRCUIT : FM OSC SIGNAL LINE : AM OSC SIGNAL LINE : FM SIGNAL LINE Z120 ENV17290G1Y C103 0.01 R107 2SK238 2SC2620 CF201 R106 J0B1075A0086 HVM27 HVM27 470K FM EXT ANT C104 1000P...
  • Page 135 SCHEMATIC DIAGRAM-6 : AM SIGNAL LINE : AM OSC SIGNAL LINE MAIN (TUNER) CIRCUIT : +B SIGNAL LINE : FM SIGNAL LINE : FM/AM SIGNAL LINE R104 Q110 R109 2SC3311ARTA CF202 C105 R108 J0B1075A0077 SWITCH +7.5V 1000P 470K R139 Q110 DET_OUT Q102 R121...
  • Page 136 POWER P.C.B. ( REPX0279D...EB Q720 C740 D526 J771 R778 C742 R764 C736 D527 C741 R758 D517 CN500 C709 R767 R728 R771 R753 IC501 D701 C743 C730 R759 R773 Q514 R729 C747 C749 C731 Q721 R727 C745 R756 R721 R755 J750 R775 Q718 C728...
  • Page 137 AC TRANSFORMER P.C.B. ( REPX0279D...EB L503 JK501 CN507B RL501 J517 CN507A Z501 J518 J519 J512 J513 J514 J520 FP502 D585 C588 C584 R576 D592 D593 D582 D581 C587 D586 R581 R580 C580 Q577 D505 C581 C585 C586 J521 J510 CN505 J516...
  • Page 138 POWER P.C.B. ( REPX0279C...E/EG Q720 C740 D526 J771 R778 C742 R764 C736 D527 C741 R758 D517 CN500 C709 R767 R728 R771 R753 IC501 D701 C743 C730 R759 R773 Q514 R729 C747 C749 C731 Q721 R727 C745 R756 R721 R755 J750 R775 Q718 C728...
  • Page 139 AC TRANSFORMER P.C.B. ( REPX0279C...E/EG L503 JK501 CN507B RL501 J517 CN507A Z501 J518 J519 J512 J513 J514 J520 FP502 D585 C588 C584 R576 D592 D593 D582 D581 C587 D586 R581 R580 C580 Q577 D505 C581 C585 C586 J521 J510 CN505 J516...
  • Page 140 MN662790RSC (80p) BA5948FPE2 (28P) AN8885SBE1 (28p) C0AABB000117 CNB13030R2AU C2BBGF000357 (100p) AN7326K (26p) LA1833NMNTLM (24p) LC72131MDTRM (20p) C1BB00000617 (30p) C1BB00000527 (16p) KRA102MTA RSN314H41A-P C0GAG0000007 C1AA00000612 B1AAGC000006 KTC3199GRTA KRC102MTA KRA110MTA DTA114EKA146 KTC3875GRTA KTA1046 KRC119STA 2SD0592ARA DTA143XKA146 KRC101STA KTC2026 2SD09650RA DTC114EKA146 KRC102STA KTA12710YTA DTC143XKA146 KRC103STA KTA1504GRTA...
  • Page 141 DECK P.C.B (REPX0289B) IC1001 C1101 J1021 C1323 C1321 C1201 J1061 R1101 C1103 J1019 C1322 C1203 C1121 C1104 C1204 C1325 J1017 R1302 C1318 C1303 R1102 C1223 C1122 C1108 R1333 C1106 C1302 J1306 IC1000 R1330 C1123 C1109 R1303 C1301 R1334 C1319 R1336 C1316 C1308 C1305...

  • Page 142: Tact Switch P.c.b

    TACT SWITCH P.C.B. ( REPX0278E Z602 S605 S603 S604 S600 S601 R604 R602 STOP/DEMO PRESET_EQ C647 R603 C648 R693 VR600 S606 S609 S607 S608 S619 D633 3 2 1 C627 PLAY/PAUSE TUNER/BAND TAPE PLAY S610 SSEQ S618 R606 R607 R608 R609 C628 POWER...
  • Page 143 CD LOADING P.C.B (REP3340A)

  • Page 144: Main/Tuner P.c.b

    main circuit tuner circuit MAIN/TUNER P.C.B. ( REPX0278E R301 R302 C130 C134 L392 J208 X103 J107 C395 J206 R137 R136 R393 R135 R134 R133 R151 R129 R117 C124 R391 R138 R127 J105 R132 C394 C122 R152 X391 R122 C397 C113 C121 C141 J212...
  • Page 145 POWER-ON P.C.B. REPX0278E R637 C130 R111 C134 R113 X103 R114 CN609B J107 R136 C110 R135 R134 R133 R151 J122 R129 R117 J102 C124 R138 D634 R127 J105 R105 R132 R152 C113 C141 R110 C103 C129 J134 C142 C108 J118 R123 C139 R106 R107...
  • Page 146 PANEL P.C.B. ( REPX0278E J646 J644 H605A CN608 R708 R903 J638 J639 J691 J674 C651 J693 J690 R919 J673 C653 J676 J672 D641 C652 R918 J681 R697 J662 J685 R699 R927 Q903 C656 D644 J633 CN606 R644 J660 R639 D645 J659 Q607 D630...
