BODY VIBE
WHOLE BODY VIBRATION THERAPY
AssEmBLY INsTRucTIONs
Please check the parts list here to ensure
you have all the necessary pieces.
8
Handlebar wire cover
9
Self-tapping screw (x4)
11
M8*15 bolt (x4)
13
M6*45 bolt (x4)
13
10
M4*15 bolt (x2)
12
M8*40 bolt (x2)
14
Control wire
™
7
8
12
6
9
10
4
11
2
1
14
5
3
23
Advertisement
Table of Contents
Related Manuals for Let's Talk Health Body Vibe
Summary of Contents for Let's Talk Health Body Vibe
- Page 1 BODY VIBE ™ WHOLE BODY VIBRATION THERAPY AssEmBLY INsTRucTIONs Please check the parts list here to ensure you have all the necessary pieces. Handlebar wire cover Self-tapping screw (x4) M4*15 bolt (x2) M8*15 bolt (x4) M8*40 bolt (x2) M6*45 bolt (x4)
- Page 2 sTEP BY sTEP AssEmBLY: Figure 1 Thread the control wire through (14) the stand post . Lay the stand post down in order to connect the control wire to the connector on the base (14) unit . Attach the stand post to the main unit using M8*15 bolts...
- Page 3 Figure 5 the wires. With your Body Vibe in its final location for use, adjust the four feet to ensure a stable foundation. Check and make sure each part is in the correct position and then connect the...
Need help?
Do you have a question about the Body Vibe and is the answer not in the manual?
Questions and answers
What is the max weight of user for this model?
The maximum user weight for the Let's Talk Health Body Vibe model is 330 lbs (149.7 kg).
