ILLUSTRATIONS
Normatec 3 Control Unit (single-person use only)
2
3
4
5
Normatec 3 Hose
1
2
3
Normatec 3 Leg Attachment (single-person use only)
1
Normatec 3 Arm Attachment (single-person use only)
6 5
2 3
4 3
1. Power button
2. Attachment selection button
1
3. Pressure level button
4. ZoneBoost
5. Time adjustment button
6
6. Display screen
7
7. Start/Stop button
8
8. Bluetooth
9. Air outlet and power inlet
9
1. Junction box air outlets
2. Junction box
3. Blocking plug
(on the underside of the junction box)
4
4. Connector
4 5
2 1
™ button
status indicator
®
1 - 5. Zones
6. Attachment
connector
6
1 - 5. Zones
6. Attachment
connector
