- Page 1 K130 USER MANUAL 1800 790 915 pumpsaustralia.com.au...
-
Page 2: Important Safety Information
PTY LTD COMPACT 10/120 USER MANUAL Thank you for purchasing a quality Pumps Australia Unit. We reserve the right to make changes at any time without incurring any obligation. Owner/User Responsibility: The owner and/or user must have an understanding of the manufacturer’s operating instructions and warnings before using this Stand Alone Boiler. - Page 3 17. Manufacturer will not be liable for any changes made to our standard machines or any components not purchased from Pumps Australia Pty Ltd. 18. The best insurance against an accident is precaution and knowledge of the machine.
- Page 4 Valve pressure regulating Water inlet Pressure switch Transformer Safety valve Fuel pump Motor fan High-Pressure Water Outlet Fuel tank Tank cap Burner Chimney unloaded smokes Fig.1 PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 5 PTY LTD COMPACT 10/120 USER MANUAL 3.1 DIMENSIONS Fig.2 3.2 TECHNICAL FEATURES Pressure max Flow max L/min Temperature C° 70° Motor Volt Weight Fuel tank PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 6 Water feeding Electrocution! Wiring box Exit gas of combustion at high Identification plate temperature Diesel Fuel Pumps Australia Pty Ltd (brand) Don’t apply the high-pressure water jet towards people, animals, wiring installations, etc… PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 7 Before connecting the plug of high-pressure cleaner to the tension, please be sure that the current corresponds to the tension reported on the identification plate. (picture.3 page.5) PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106...
- Page 8 Unload the residual pressure of the high-pressure hose through the gun every time the cleaner is switched off. Never put your hands in front of the lance whilst working. Do not use different fuel from that foreseen by the manufacturer. PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 9 The high-pressure cleaner is supplied with idle wheels, so avoid placing it on ramps or tilted floors. The use of extension cables is discouraged. In case the user is necessary, please adopt the conforming laws in force. PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106...
-
Page 10: Installation
Connect the high-pressure hose (pos.3 fig.6) to the gun (pos.4) and with the other end of the high-pressure hose to the outlet nipple (pos.5) locking it in firmly. Fig.6 PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106... - Page 11 HOT WATER WORKING To have hot water, after having switched on the electric motor, push the switch pos. 2 that turns on the burner. (See Fig.8). PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106...
- Page 12 Grip the lance and push on the lever A as shown in fig.9 so, start to work. Verify that the water jet is uniform; in not, disassemble the nozzle, clean it, then reassemble it... PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 13 Please place the cleaner in a place protected from ice and frost and the possibility of use by other people. PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
-
Page 14: Maintenance
Re-assemble the nozzle U on the lance and start to work with the cleaner. Fig.13 PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106... - Page 15 WATER DIAGRAM DENOMINATION DENOMINATION Water faucet Chimney Motor pump High-pressure hose Pressure valve Pressure switch Water opening lever Outer case boiler Lance Coil Nozzle Fig.14 PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 16 TRAS Transforme Pressure- switch 1 Pressure- switch 2 S.E.P Main electric board S.E.S Secondary electronic board Thermostat Main switch Earth cable Tension Fig.15. PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
-
Page 17: Troubleshooting
With the lance opened, the pressure goes up and down. CAUSE Warped or obstructed nozzle, obstructed lance, or coil. REMEDY Clean or replace the nozzle, scale the coil, and lance. PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au... - Page 18 DIESEL FUEL PUMP FUEL PUMP ADAPTOR 240VAC BURNER MOTOR 12VDC BURNER MOTOR FAN BLADE (LEFT ROTATION) FAN BLADE (RIGHT ROTATION) 240VAC IGNITION TRASFORMER 12VDC IGNITION TRANSFORMER PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 19 Fan System Solenoid & Fuel Pump System Transfomer Inner Coil Assembly Boiler Pad Fuel System Electrical System Please Note: 240VAC Option Shown, 12VDC will vary. PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 20 PTY LTD COMPACT 10/120 USER MANUAL 1450 MARKING: YYWW PUMP NUMBER 60 69 OIL DRAIN STOPPER CHEM UN004349-LM KIT RICAMBI / PART KITS UN004350-LM sp_00682_HJR PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 21 @ Posizionamento targa di identificazione / Identification plate positioning β Codice premontaggio / Code number Olio - Oil Tipo / Type Quantità / Quantity SAE 15W40 0,154Kg MI 95646 DI_4148509 PUMPS AUSTRALIA PTY LTD PHONE: 1800 790 915 212 Welshpool Road, Welshpool WA 6106 EMAIL: Sales@Pumpsaustralia.com.au...
- Page 22 AUSTRALIAN OWNED & OPERATED Established in 1997 as a backyard business, Pumps Australia has had steady growth over 20 years by supplying quality products with quality service using quality people. Being a firm believer of always having what you need in stock, our large warehouse locat- ed in Welshpool carries a HUGE inventory of stock for our customers.
