QUICK REFERENCE GUIDE
Operation & Assembly
Set depth gauge to .003"
(closed position) prior to
the blade installation.
Attach power cord to back
of power supply and plug
into electrical outlet.
Contact Us:
For additional information:
support@exsurco.com | 800-243-6049
Quick Reference Guide
Part #X100574
®
Turn the Amalgatome MD
lever side down. Place
blade (A) into housing/
frame (B) and slightly turn
blade in any direction for
smooth rotation.
Remove protective cap from
end of handpiece power
cord and plug into power
supply by aligning red dots.
amalgatome
A
B
Place blade locking ring (C)
onto housing/frame (B) and
ensure the three (3) screws
align with screw holes.
Tighten with screwdriver
included with device.
Cap
Turn power switch to ON.
The device is ready to
operate.
MD
MD
|
C
B
