6
Operating unit with timer
ON timer and OFF timer
TEMP
SLEEP
Setting TIMER
Set the timer during operation. The timer cannot be set if
the air conditioner is not running.
1
ON/OFF TIMER button (
Push the ON or OFF TIMER buttons as required.
•
The previous timer setting is displayed and
flashes along with ON/OFF timer display.
Set the timer to the desired time.
Each push of the TIMER button changes the time in
ten minute steps.
Pushing the TIMER button continually changes the
time in one hour step.
2
SET
button
SET
Push the SET
button to set the timer.
SET
The timer time is indicated and the timer starts.
Cancelling TIMER
3
CLR
button
CLR
Push the CLR
button to cancel the timer setting.
CLR
1
3
CLR
2
SET
or
)
OFF
ON
– 10 –
CAUTION
•
When you select the timer operation, the remote
controller automatically transmits the timer signal to
the indoor unit at the specified time. Therefore, keep
the remote controller in a location where it can
transmit the signal to the indoor unit properly.
Otherwise, the time lag of up to 15minutes will occur.
•
If you do not push the SET
seconds after setting the time, the setting will be
cancelled.
Once you select the timer operation mode, the settings
are saved in the remote controller.
Thereafter, the air conditioner will start operating under
the same conditions when you simply push the ON/OFF
button of the remote controller.
If the clock display is flashing, you cannot set the timer.
Follow the instructions in the section "Setting the clock"
and then set the timer.
Combined timer (Setting both ON and
OFF timers simultaneously)
OFF timer —> ON timer
(Operation —> Stop —> Operation)
This feature is useful when you want to stop the air
conditioner after you go to sleep, and start it again in the
morning when you wake up or you return home.
Example:
To stop the air conditioner and start it again next morning.
Operation
▼ Setting combined TIMER
1. Push the OFF TIMER
OFF timer.
2. Push the ON TIMER
ON timer.
3. Push the SET
button.
SET
button within 30
SET
Operation again
Stop
button to adjust the
OFF
button to adjust the
ON
EN
10-EN
