USER MANUAL
Scavenger Transceiver Module
STM 300 / STM 300C
March 4, 2011
Patent protected:
WO98/36395, DE 100 25 561, DE 101 50 128,
WO 2004/051591, DE 103 01 678 A1, DE 10309334,
WO 04/109236, WO 05/096482, WO 02/095707,
US 6,747,573, US 7,019,241
EnOcean GmbH
Kolpingring 18a
82041 Oberhaching
Germany
Downloaded from
Elcodis.com
electronic components distributor
V1.30
Observe precautions! Electrostatic sensitive devices!
Phone +49.89.67 34 689-0
Fax
+49.89.67 34 689-50
info@enocean.com
www.enocean.com
Subject to modifications
STM 300 / STM 300C User Manual V1.30
March 4, 2011 2:06 PM
Page 1/40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STM 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for EnOcean STM 300

  • Page 1 WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 EnOcean GmbH Phone +49.89.67 34 689-0 Subject to modifications Kolpingring 18a +49.89.67 34 689-50 STM 300 / STM 300C User Manual V1.30 82041 Oberhaching info@enocean.com March 4, 2011 2:06 PM Germany www.enocean.com Page 1/40 Downloaded from Elcodis.com...
  • Page 2 This information describes the type of component and shall not be considered as assured characteris- tics. No responsibility is assumed for possible omissions or inaccuracies. Circuitry and specifications are subject to change without notice. For the latest product specifications, refer to the EnOcean web- site: http://www.enocean.com.
  • Page 3: Table Of Contents

    4.1 CE Approval ....................36 4.2 FCC (United States) certification ..............37 4.3 IC (Industry Canada) certification ..............40 © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 3/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 4: General Description

    Application notes for calculation of energy budgets and management of external energy storages Product variants STM 300/300C: SMD mountable module for use with external antenna (868/315 MHz) Features accessible via API Using the Dolphin API library it is possible to write custom firmware for the module.
  • Page 5: Technical Data

    Tolerances: PCB outline dimensions ±0.2 mm All other tolerances ±0.1 mm STM 300 / STM 300C (pads on bottom side of PCB!) @ 0.1% telegram error rate (based on 3 transmitted sub-telegrams) © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 5/40 Downloaded from Elcodis.com...
  • Page 6: Environmental Conditions

    Suited solar cells (for technical details please refer to the ECS3x0 data sheet): Type Ordering Code Size ECS 300 S3005-D305 35.0×12.8×1.1 mm ECS 310 S3005-D310 50.0×20.0×1.1 mm © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 6/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 7: Functional Description

    USER MANUAL V1.30 STM 300 / STM 300C FUNCTIONAL DESCRIPTION Simplified firmware flow chart and block diagram © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 7/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 8: Hardware Pin Out

    PROG_EN RVDD The figure above shows the pin out of the STM 300 hardware. The pins are named accord- ing to the naming of the EO3000I chip to simplify usage of the DOLPHIN API. The table in section 2.3 shows the translation of hardware pins to a naming that fits the functionality of the built-in firmware.
  • Page 9: Pin Description And Operational Characteristics

    Input read ~2 ms after wake-up. See also 2.3.2. ADIO6 DI_3 Digital input Input read ~2 ms after wake-up. See also 2.3.2. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 9/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 10: Gpio Supply Voltage

    IOVDD. Please note that the wristwatch XTAL I/Os WXIDIO and WXODIO are always supplied from UVDD. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 10/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 11 However it is important to o connect IOVDD to a supply voltage as spec cified in 2.5. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 11/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 12: Analog And Digital Inputs

    3dB input bandwidth, resulting in 111µs settling time to achieve a deviation of an input signal <1LSB (<0.098% @ 10bit resolution). © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 12/40 Downloaded from Elcodis.com...
  • Page 13: Absolute Maximum Ratings (Non Operating)

    Ripple on VDD, where VDDR Min(VDD) > VON UVDD Ultra Low Power supply RVDD RF supply DVDD Digital supply © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 13/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 14: Charge Control Output (Cco)

    Turn off threshold VDD drops below VOFF Voltage Limiter STM 300 provides a voltage limiter which limits the supply voltage VDD of STM 300 to a value VDDLIM which is slightly below the maximum VDD ratings by shunting of sufficient current.
  • Page 15: Configuration

    15.231e). The limited modular app proval of STM 300C is not valid in this c case. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 15/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 16: Configuration Via Programming Interface

    Studio (Windows application for chip configuration, programming, and testing) and the USB/SPI programmer device as part of the EDK 300 developer´s kit. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 16/40 Downloaded from Elcodis.com...
  • Page 17: Radio Telegram

    The voltages measured at the analog inputs can be calculated from these values as follows: U=(Value of AD_x)/(2 )x1.8 V n=resolution of channel in bit © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 17/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 18: Teach-In Telegram

    © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 18/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 19: Energy Consumption

    Current proportional to illumination level (not true at very low levels!) These values are calculated values, the accuracy is about +/-20%! © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 19/40 Downloaded from Elcodis.com...
  • Page 20: Applications Information

    STM 300 provides a digital output CCO (see also 2.7) which allows controlling the charging of these two storages. At the beginning, as long as the voltage is below the VON voltage only the small storage is filled.
  • Page 21 PMOS transistor Q1, driven from the STM 300 charge control output CCO over T1A. To start with, as long as the STM 300 VDD voltage is below the VON threshold, only the small storage (C1) is filled over D3. Once the threshold is reached, the CCO control signal goes High, T1B and Q2 are turned on and the long term storage (C2) will be filled over Q2.
  • Page 22: Using The Sco Pin

    WAKE pins. When STM 300 is in “Deep Sleep Mode” or “Flywheel Sleep Mode” (via API o only) and the logic levels of WAKE0 and / or WA KE1 is changed, STM 300 starts up.
  • Page 23: Using Rvdd

    Pulsed current drawn from RVDD has to be avoided. If pulsed currents are necessary, suffi- cient blocking has to be provided. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 23/40 Downloaded from Elcodis.com...
  • Page 24: Antenna Options

    TM 300C and TCM 3X0C) please note that a f full approval is needed if modules are used with antennas other than the specified whip an- tenna. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 24/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 25: Whip Antenna

    Minimum distance space: 10 mm Specification of the whip antenna; L=150 mm @ 315 MHz, L=86 mm @ 868 MHz © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 25/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 26: Chip Antenna

    Minimum distance space and layout: Distance space for components AMD1103-ST01 GND plane RF_50 Minimum distance space above and below PCB: 11 mm © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 26/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 27 Distance space for components AMD1103-ST01 GND plane RF_50 Minimum distance space above and below PCB: 11 mm © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 27/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 28: Splatch Antenna

    3.5.3. Distance space for components RF_50 Minimum distance space above and below PCB: 12 mm © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 28/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 29: Helical Antenna

    Distance space for components RF_50 ANT-315-HE GND plane Minimum distance above and below axis of antenna: 21 mm © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 29/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 30: Layout Recommendations For Foot Pattern

    The RVDD line should be kept as short as possible. Please consider rec commenda- tions in section 3.4. Top layer © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 30/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 31 USER MANUAL V1.30 STM 300 / STM 300C Solder resist top layer © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 31/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 32 Nevertheless an application and production specific test regarding the amount of soldering paste should be performed to find optimum parameters. © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 32/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 33: Soldering Information

    STM 300 has to be soldered according to IPC/JEDEC J-STD-020C standard. STM 300 shall be handled according to Moisture Sensitivity Level MSL4 which means a floor time of 72 h. STM 300 may be soldered only once, since one time is already consumed at production of the module itself.
  • Page 34: Tape & Reel Specification

    USER MANUAL V1.30 STM 300 / STM 300C Tape & Reel specification Tape running direction © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 34/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 35: Transmission Range

    False ceilings with panels of metal or carbon fiber Lead glass or glass with metal coating, steel furniture The distance between EnOcean receivers and other transmitting devices such as comput- ers, audio and video equipment that also emit high-frequency signals should be at least 0.5 A summarized application note to determine the transmission range within buildings is available as download from www.enocean.com.
  • Page 36: Agency Certifications

    CE Approval The STM 300 module bears the EC C conformity marking CE and conforms to the e R&TTE EU- directive on radio equipment. The assembly conforms to the European and nat...
  • Page 37: Fcc (United States) Certification

    United States without additional Part 15 FCC approval (ap- proval(s) for unintentional radiators may be required for the OEM’s finished product), under EnOcean’s FCC ID number. This greatly simplifies and shortens the design cycle and devel- opment costs for OEM integrators.
  • Page 38 STM 300 / STM 300C OEM Requirements In order to use EnOcean’s FCC ID number, the OEM must ensure that the following condi- tions are met. End users of products, which contain the module, must not have the ability to alter the firmware that governs the operation of the module.
  • Page 39 USER MANUAL V1.30 STM 300 / STM 300C © 2010 EnOcean | www.enocean.com STM 300 / STM 300C User Manual V1.30 | Page 39/40 Downloaded from Elcodis.com electronic components distributor...
  • Page 40: Ic (Industry Canada) Certification

    STM 300 / STM 300C IC (Industry Canada) certification In order to use EnOcean’s IC number, the OEM must ensure that the following conditions are met: Labeling requirements for Industry Canada are similar to those required by the FCC. The Original Equipment Manufacturer (OEM) must ensure that IC labeling requirements are met.
