  • Page 1                                     !  "    #    $%          %  &       ' &         ()   *    ! # +      $ + ,      $ + ,     - +      +(+          .+  "#             %       %  + !  "      ,!  "...
  • Page 2 To equalize the static electricity, rest the accessory bag on top of the PC while you are removing the accessory from the bag. Handle the accessory as little as possible and with care. Installing Components in the Desktop 2 of 36...

  • Page 3: Accessories You Can Install

    CD-ROM drive, DVD drive, CD-RW drive, Tape drive, or Zip drive Front-Access Device Lower Shelf CD-ROM drive, CD-RW drive, DVD drive, Tape drive, Zip drive or Power Protection Device Installing Components in the Desktop 3 of 36...

  • Page 4: Removing The Pc's Cover

    Desktop Removing the PC’s Cover 1 of 1 Installing Components in the Desktop 4 of 36...

  • Page 5: Replacing The Pc's Cover

    Desktop Replacing the PC’s Cover 1 of 1 Installing Components in the Desktop 5 of 36...

  • Page 6: Upgrading Or Replacing Main Memory

    Upgrading or Replacing Main Memory NOTE www.hp.com/go/pcaccessories Location of Main Memory Desktop 1 of 1 Installing Components in the Desktop 6 of 36...
  • Page 7 Desktop Installing More Graphics Memory (some models only) 1 of 2 Location of AGP slot Installing Components in the Desktop 7 of 36...
  • Page 8 Desktop Installing More Graphics Memory (some models only) 2 of 2 Installing Components in the Desktop 8 of 36...
  • Page 9 1. An AGP graphics card, or 2. A 4 MB Graphics memory extension card ISA 2 Optional ISA Extension Board Available only as an ISA 1 accessory PCI 3 PCI 2 PCI 1 Installing Components in the Desktop 9 of 36 Desktop 1 of 1...
  • Page 10 Desktop How to Install an Accessory Board 1 of 2 Installing Components in the Desktop 10 of 36...
  • Page 11 Connector NOTE Advanced Network Interface Disabled Suspend Wake-Up/Integrated Network Integrated Network Enabled Advanced Video Options Integrated Audio Interface Advanced Disabled Installing Components in the Desktop 11 of 36 Desktop 2 of 2 Integrated Power Multidisplay...
  • Page 12 Configuring Boards with Plug & Play Windows 95, Windows 98 and Windows 2000 Windows NT 4.0 Start Help NOTE Start Windows NT Update Installing Components in the Desktop 12 of 36 Desktop 1 of 1 Programs...
  • Page 13 Desktop Configuring non-Plug & Play ISA Boards 1 of 1 Resetting the PC’s Configuration Data Reset Configuration Data Installing Components in the Desktop 13 of 36...
  • Page 14 Desktop Installing an ISA Extension Kit 1 of 2 Studs Studs Insert screws here Installing Components in the Desktop 14 of 36...
  • Page 15 Desktop Installing an ISA Extension Kit 2 of 2 Installing Components in the Desktop 15 of 36...

  • Page 16: Which Drive Connectors To Use

    CD-RW drives, CD-ROM drives, Zip drives Floppy disk drive NOTE 2nd hard disk drive Use for Master (boot) hard disk drive Desktop 1 of 2 CD-ROM, CD-RW, DVD or Zip drive Floppy drive Installing Components in the Desktop 16 of 36...
  • Page 17 Desktop Which Drive Connectors to Use 2 of 2 Which IDE Data Connectors to Use Before Installing a Hard Drive Selecting the Bootable Hard Disk Drive NOTE Installing Components in the Desktop 17 of 36...

  • Page 18: Upgrading The Hard Disk

    Make sure that you back up your files before you install a hard disk drive. Refer to your operating system documenta- tion for information on how to do this. Installing Components in the Desktop 18 of 36...
  • Page 19 Desktop Upgrading the Hard Disk 2 of 2 NOTE www.hp.com/go/ vectrasupport  Installing Components in the Desktop 19 of 36...

  • Page 20: Installing A Second Hard Disk

    Make sure that you back up your files before you install a hard disk drive. Refer to your operating system documenta- tion for information on how to do this. Installing Components in the Desktop 20 of 36...
  • Page 21 Desktop Installing a Second Hard Disk 2 of 2 NOTE www.hp.com/ go/vectrasupport  Installing Components in the Desktop 21 of 36...
  • Page 22 Refer to the label on the CD-ROM drive for power requirements and wavelength. This product is a class 1 laser product. filler plate Installing Components in the Desktop 22 of 36...

  • Page 23: Installing Removable Media Devices

    Desktop Installing Removable Media Devices 2 of 2 Audio Connector (optional) Installing Components in the Desktop 23 of 36...

  • Page 24: Configuring An Ide Device After Installation

    Desktop Configuring an IDE Device After Installation 1 of 1 Installing Components in the Desktop 24 of 36...

  • Page 25: Replacing The Floppy Drive

    Desktop Replacing the Floppy Drive 1 of 1 Installing Components in the Desktop 25 of 36...

  • Page 26: Replacing The Processor

    Replacing the Processor Press firmly on both sides then remove it Passive heatsink Desktop 1 of 3 Heatsink with fan First remove the fan’s power connector from the system board, then remove the heatsink. Installing Components in the Desktop 26 of 36...
  • Page 27 Desktop Replacing the Processor 2 of 3 Passive heatsink Insert the processor carefully. Ensure the orientation is correct - it can go in one way only. Installing Components in the Desktop 27 of 36...
  • Page 28 CAUTION Ensure you use the correct system board connector (marked CPU FAN) - refer to page 30 the position of this connector. Desktop 3 of 3 Installing Components in the Desktop 28 of 36...

  • Page 29: Replacing The System Board

    Desktop Replacing the System Board 1 of 2 Press firmly on both sides then remove it Installing Components in the Desktop 29 of 36...
  • Page 30 Tape or Zip drive Floppy drive Status panel Hard drive Processor fan (not used if passive heatsink is fitted, as shown here) Power protection device (if installed) System fan Main power Desktop 2 of 2 Installing Components in the Desktop 30 of 36...

  • Page 31: Replacing The Power Supply

    There are no user-serviceable parts inside. Hard drive(s) Press firmly on both sides then remove it Desktop 1 of 2 DVD, CD-RW, Floppy drive CD-ROM Main power drive(s) (located on system board near memory modules) Installing Components in the Desktop 31 of 36...
  • Page 32 Desktop Replacing the Power Supply 2 of 2      Installing Components in the Desktop 32 of 36...
  • Page 33 Please return used batteries to the shop from which you bought them, or to the dealer from which you purchased your PC, or to HP, so that they can either be recycled or disposed of in an environmentally sound way. Returned used batteries will be accepted free of charge.
  • Page 34 Remove the power protection device cables before any servicing operation. Always replace the cover before switching the PC on again. Installing Components in the Desktop 34 of 36...
  • Page 35 Desktop Replacing the Power Protection Device (some models only) 2 of 2 Installing Components in the Desktop 35 of 36...
  • Page 36 Desktop Replacing the Internal Speaker (some models only) 1 of 1 Installing Components in the Desktop 36 of 36...
