Better Homes and Gardens BH15-101-099-03 Instruction Manual

Better Homes and Gardens BH15-101-099-03 Instruction Manual

Natural gas conversion

Advertisement

Quick Links

WARNING
For Outdoor Use Only (outside any enclosure)
WARNING
1. Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
2. Read this instruction manual thoroughly
before installing or servicing this equipment.
3. Failure to follow these instructions could
result in fire or explosion, which could cause
property damage, personal injury or death.
4. This instruction manual contains important
information necessary for proper assembly and
safe use this appliance.
WARNING
1. Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
2. An LP tank not connected for use should not
be stored in the vicinity of this or any other
appliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open the lid.
4. If the odor continues, keep away from the
appliance
and
immediately
supplier or fire department.
DANGER
Never operate this appliance unattended.
Save these instructions for future reference.
If you are assembling this unit for someone else,
give this manual to him or her to read save for
future reference.
DO NOT RETURN YOUR GRILL TO THE STORE
Question, problems, missing parts? Don't return the grill to stores, please call our customer service
department at 1-855-CHANT-US (1-855-242-6887) from 8:00am to 5:00pm Eastern time, Monday
through Friday for assistance.
Natural Gas Conversion
VENDOR STOCK NO.: BH15-101-099-03
call
your
gas
1-855-242-6887
Instruction for
MODEL NO.:BG2503B-DG
Call Customer Service Hotline
1
BH15-101-099-08
BH15-101-099-09
BH15-101-099-10

Advertisement

loading
Need help?

Need help?

Do you have a question about the BH15-101-099-03 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Better Homes and Gardens BH15-101-099-03

  • Page 1 Natural Gas Conversion Instruction for MODEL NO.:BG2503B-DG WARNING For Outdoor Use Only (outside any enclosure) VENDOR STOCK NO.: BH15-101-099-03 BH15-101-099-08 WARNING 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or BH15-101-099-09 property damage. 2. Read this instruction manual thoroughly BH15-101-099-10 before installing or servicing this equipment.
  • Page 2: Safety Information

    SAFETY INFORMATION DANGER: Failure to follow the dangers, warning and cautions in this manual may in result in serious bodily injury or death, or in a fire or an explosion causing damage to property. The installation and repairs of this appliance must cause a fire or explosion.
  • Page 3: California Proposition

    SAFETY INFORMATION Never operate grill without heat plates installed. Use protective gloves when assembling this Do not leave a lit grill unattended, especially keep product. children and pets away from grill at all times. Do not force parts together as this can result in Always use a meat thermometer to ensure food is personal injury or damage to the product.
  • Page 4 NATURAL GAS CONVERSION Before beginning conversion, make sure all parts are present. Compare parts with package contents. If any part is missing or damaged, do not attempt to convert. Please have your owner’s manual and part number available for reference, and contact customer service 1-855-242-6887 for replacement parts.
  • Page 5 NATURAL GAS CONVERSION IMPORTANT: After your grill is converted to natural gas, the working pressure for natural gas is 7 in. water column (WC). Gas pressure is affected by gas line size and the length of gas line run from house. Follow the recommendations in the chart below.
  • Page 6 NATURAL GAS CONVERSION WARNING: Place the grill on a flat, level surface. Before the conversion, make sure all control knobs are in the OFF position, LP tank valve is closed, and tank is disconnected from regulator and removed from grill 1, Open the lid and remove cooking grates and heat tent.
  • Page 7 NATURAL GAS CONVERSION 3, Loosen the screw from LPG setting, rotate the shutter opening counterclockwise, adjusting it from LP setting to NG setting. Re-tighten the screw into NG setting for securing the air shutter opening. 4, Unscrew the old LP orifice from each gas valve with the orifice removal tool. Put a new NG orifice into the valves and tighten with tool.
  • Page 8 NATURAL GAS CONVERSION 5. Reinstall the main burners and R pin. Make sure to engage the burner valves. Then Put the heat tents, cooking grates back to grill. 6, Remove the Grease Tray out of the grill. Then use a wrench to detach the LP regulator and hose from fitting as shown.
  • Page 9 NATURAL GAS CONVERSION 7, Remove the 3 main burner control knobs by grasping and pulling out. Insert slotted screwdriver (Not included) into the hole of each control valve shaft as shown. Rotate the shaft counterclockwise (to the left) as far as it will go (about 2 complete turns) until it stops. The shaft will now be set in the NG position.
  • Page 10: Troubleshooting

    TROUBLESHOOTING Many solutions given here can make your grilling experience safer and more enjoyable. You can also call customer service department at 1-855-CHANT-US(1-855-242-6887) from 8:00am to 5:00pm Eastern time, Monday through Friday for assistance. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. The ignition wire came off the 1.
