- Page 1 User Manual-P5133 PS5 Wall Mount with Dual Charging Station User Manual Installation Video...
-
Page 2: Contact Information
14 days of the delivery date to extend your warranty coverage to TWO Years! From all of us here at NexiGo, we want to welcome you again to the family. We thank you deeply for your trust and for your business. -
Page 3: Product Introduction
PRODUCT INTRODUCTION This PS5 Wall Mount with Dual Charging Station is designed to organize your PS5 console and can support both Digital and Disc versions. The wall mount is equipped with a 2A power adapter to provide faster charging. The LED... -
Page 4: Product Instructions
1. Charging Slot 1 5. Charging Dock 2. LED Indicator 6. Charging Slot 2 3. Type-C Power Interface 7. Wall Mount 4. Power Button PRODUCT INSTRUCTIONS Step 1: Align one of the U-shaped spacers with the holes on the base of the wall mount. Insert a screw through one of the holes in the U-shaped spacer and fasten it with a washer on the other side. - Page 5 Step 2: Position the stand where you want it and then locate the screw holes in the wall mount. Mark each hole with a pencil/pen to ensure that the tapping process will be accurate. 15/64" drill bit Step 3: Drill a hole with 15/64" drill bit at each mark. (Drill and drill bits NOTincluded.)
- Page 6 Step 4: Insert a plastic wall plug into each hole and hammer in the plastic wall plugs so they are nearly flush with the wall surface. (Hammer NOT included.) Step 5: Insert a screw through the hole in the wall mount and into the plastic wall plug, then do the same with the rest holes in the wall mount.
- Page 7 Digital Edition Disc Edition Bottom Step 6: Place your PS5 console on the wall mount and align its safety lock screw hole with the opening on the bottom of the mount. There are two openings for the screw placement, one for each version of the console. Once you have aligned the PS5 screw hole with the opening on the bottom of the mount, insert the safety screw and tighten it.
- Page 8 Step 8: Tap the power button to toggle on/off the charging dock (Note: Please ensure that the power button is turned on and lit up before charging. The controllers will not charge if it is off.) FEATURES An intelligent microchip within the charger protects the controllers from damage and displays an easy-to-read charging status.
-
Page 9: Charging Instructions
CHARGING INSTRUCTIONS Power the charging dock with either the provided USB cable or the provided power adapter. A white power indicator light will display in the lower left hand corner of the dock next to the power button when the dock is on. -
Page 10: Fcc Requirement
NOTES SAFETY WARNING: HAZARD-Small Parts-Not intended for children under 5 years of age. Power the charging dock with either the provided USB cable or the provided power adapter. Other Type-C power supplies may cause charging failure or extended charging duration. To ensure longevity and lifespan of the wall mount do not place any objects other than the console or accessories on the wall mount.
