SPECIFICATIONS
Data Standards & Speeds:
Standards -
ITU V.92, V.90/ k56Flex, V.34+. V.34, V.32bis,
V.32, V.23, V.22bis and V.21
Bell 212A and 103
Data Speeds:
56K, 33,600; 31,200; 28,200; 26,400; 21,600;
19,200; 16,800; 14,400; 12,000; 9,600;
7,200; 4,800; 2,400; 1,200 and 300pbs
Fax Standards & Speeds:
Standards –
ITU-T; V.17; V.29; V.27ter and V.21 ch2
Fax Class 1
Fax Speeds:
14,400; 12,000; 9,600; 7,200; 4,800; 2,400;
1,200 and 300bps
Error Correction & Data Compression:
MNP® 2-4; V.42; LAPM; MNP 4; V.42bis, MNP 5
DTE Speeds:
115,200bps
Software Compatibility:
Windows 9x, XP, ME, NT 4.0
Command Sets:
Industry Standard AT Command Set; Extended AT
Commands; EIA Class 1 (EIA 578)
Note: Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. MNP is a registered trademark of Microcom.
PART NUMBERS
PC OEM -
Domestic: 90109-2 (40-pack modems only)
International: TBD (40-pack modems only)
© 1999. All rights reserved. The stylized "S" and "SMART" as well as "SMART Modular Technologies" are trademarks of SMART Modular Technologies, Inc. All other trademarks and registered trademarks are the property of their respective companies. 0601- V.92 PCI DFM-PSM376
Dial Type:
Tone and Pulse
Operating Modes:
Auto dial/answer; auto feature negotiation
External Connectors:
2 - RJ-11 Phone jacks
Diagnostics:
CCITT V.54 Loopback tests:
- Local analog
- Local analog with self-test
- Local digital
- Remote digital Loopback
- Remote digital with self-test
Flow Control:
XON/XOFF; CTS/RTS (Hardware & Software)
Certifications:
FCC Part 15, Class B
FCC Part 68 PSTN
Industry Canada (CS 03)
WHQL (Windows Hardware Qualification Labs)
PC '99 Compliant
CE Conformity – EN50082/Part1, EN55022,
EN60950
UL1950 3rd Edition
EN61000-4-2
Channel -
Domestic Single Pack: ST5614DFNAPABL (individually packed modem, RJ-11 cable and diskette with manual and drivers)
Domestic Bulk Pack: ST5614DFNAPABL40 (40 pack, modem only)
Optional Software Cable Kit - 40 count: QDSK/CBLLTMDM40 (40 driver diskettes and cables only)
Corporate Headquarters: Tel: (+1) 510.623.1231 • Fax: (+1) 510.623.1434 • e-mail: info@smartm.com
Europe: Tel: (+44) 870-870-8747 • Fax: (+44) 870-870-8757 • e-mail: euro.sales@smartm.com
Asia/Pacific: Tel: (+65) 604.399.2909 • Fax: (+65) 604.399.2903 • e-mail: infoasia@smartm.com
Web: http://www.smartmodulartech.com
Environmental:
Temperature:
- Operating: 0C to +45C
- Storage: -25C to +60C
Altitude:
- 0 to 20,000 feet
Humidity:
- 10% to 90% (non-condensing)
Minimum System Requirements:
Single PCI slot in a desktop PC using at least a
Pentium 100MHz processor and either Windows
9x, XP, ME, or NT 4.0
International PTT Certifications
(for international part numbers only):
PTT approvals may be obtained for the following
countries (other countries available per request and
may require custom modification)
CTR-21
Austria, Belgium, Denmark, Finland,
France, Germany, Greece, Ireland, Italy,
Luxembourg, Netherlands, Portugal, Spain,
Sweden, United Kingdom, Iceland, Norway and
Switzerland
