Summary of Contents for Adaptive Recognition Osmond L

  • Page 2: Table Of Contents

    OSMOND L, R User’s Manual OSMOND L, R USER’S MANUAL Document version: 2022-04-27 Table of Contents INTRODUCTION............................ 4 DEVICE OVERVIEW ..........................5 Package Contents ........................5 Parts and Components......................6 Maintenance ..........................8 ACCESSING THE DEVICE ........................9 Installation ..........................10 1.1.
  • Page 3 OSMOND L, R User’s Manual Equipment modifications: This equipment must be installed and used in accordance with the instructions given in its documentation. This equipment contains no serviceable components. Unauthorized equipment changes or modifications cause warranty to void. Page 3/21 SENDINFO@ADAPTIVERECOGNITION.COM...

  • Page 4: Introduction

    OSMOND L, R User’s Manual Introduction The Osmond is a full-page, multi-purpose passport and ID reader that provides automatic, accurate data extraction and verification with the ability to read multiple types of identity documents: passports, e-passports, ID cards, visas and driver licenses. The printed data is extracted from the entire page (MRZ, VIZ and 1D &...

  • Page 5: Device Overview

    OSMOND L, R User’s Manual Device Overview PACKAGE CONTENTS Pas sport 5V output 1 pc of glass Power U SB cable Ethernet Reader power cleaning Blind plug cord (EU) (U SB3.0) cable device s upply wipe Osmond L ✓ ✓...

  • Page 6: Parts And Components

    OSMOND L, R User’s Manual PARTS AND COMPONENTS The device is produced in a plastic (ABS) housing (1) and an aluminum base plate (2). The object-plate (3) is protected from the external light-striking by the plastic (ABS) shield/cover (4). The shield has a document holder (5) in order to facilitate the placing of the document.
  • Page 7 OSMOND L, R User’s Manual The scanner is designed with an aluminum heatsink (9). The USB socket (10), the power supply socket (11) and the K ensington ® security slot (12) are located on the back of the device. The Osmond device is designed with a removable document holder built in the shield. This feature can be vital in special cases e.g., scanning extremely thick documents which cannot...

  • Page 8: Maintenance

    OSMOND L, R User’s Manual MAINTENANCE The device has no moving parts – except for the motorized, auto-focus module – which ensures maximum reliability and low maintenance. However, in order to ensure that the device remains in a satisfactory operating condition, the following actions should be performed regularly.

  • Page 9: Accessing The Device

    OSMOND L, R User’s Manual Accessing the Device Osmond R and L models are USB devices that operate as any other ADAPTIVE RECOGNITION passport reader. They can be used with the Full Page Reader or Authentication Checker applications as well as our SDK.

  • Page 10: Installation

    OSMOND L, R User’s Manual INSTALLATION 1.1. HARDWARE INSTALLATION Please follow the next steps for connecting the device to the PC: • Connect the device to one of the USB 2.0 or 3.0 ports of the PC with the supplied USB cable.

  • Page 11: Software Installation

    OSMOND L, R User’s Manual 1.2. SOFTWARE INSTALLATION Due to the fact that USB Osmond devices operate similar to any other ADAPTIVE RECOGNITION passport reader in order to use it the ADAPTIVE RECOGNITION driver package is necessary. For Osmond devices, the Passport Reader software package 2.1.9.5 or higher version is required.

  • Page 12: Oled Display Status Icons Of Osmond Usb Devices

    OSMOND L, R User’s Manual OLED Display Status Icons of Osmond USB Devices Unlike previous document scanner models, the Osmond device is equipped with OLED display. This screen is able to display the following status icons. DISPLAY ICON STATUS NAME...
  • Page 13 OSMOND L, R User’s Manual If you see the "Update error" icon during the update process, this indicates that the update has failed for some reason. In this case, the device automatically rollbacks to the original firmware version. Page 13/21 SENDINFO@ADAPTIVERECOGNITION.COM...

  • Page 14: Oled Standby Mode

    OSMOND L, R User’s Manual OLED Standby Mode In order to protect the lifetime of the OLED display, the OLED screen enters idle mode. By using the ctrl/screen_standby property a time interval can be specified, after which the OLED screen of the device enters idle mode (sleep mode).
  • Page 15 OSMOND L, R User’s Manual 2. In the Full Page Reader application: This method is currently available only in USB mode. In the Full Page Reader application navigate to the OPTIONS / MANUAL SETTINGS tab, and type "ctrl/screen_standby" (without apostrophes) into the "PROPERTY NAME" field and specify any decimal value as "PROPERTY VALUE".
  • Page 16 OSMOND L, R User’s Manual 3. In the gxsd.dat file: This method is currently available only in USB mode. In the gxsd.dat file, add the following: <ctrl> <screen_standby value="X"/> </ctrl> This is to be pasted anywhere into the <pr> section. The value "X" has to be a decimal value in seconds.

  • Page 17: Shutdown Process

    OSMOND L, R User’s Manual Shutdown Process To turn off the device, perform the following steps: 1. Press and hold the power touch button until the shutdown process starts. Hold the power touch button for another 5 seconds. The progress bar on the OLED screen shows the remaining time.

  • Page 18: Removing The Osmond Document Holder

    OSMOND L, R User’s Manual Removing the Osmond Document Holder The Osmond device is designed with a removable document holder built in the shield. Document holder under the shield This feature can be vital in special cases e.g., scanning extremely thick documents which cannot fit to the device due to their size being incompatible with the document holder.
  • Page 19 OSMOND L, R User’s Manual The process is simple and easy to perform in which the following steps will guide the user: 1. Hold firmly the document holder and carefully pull it towards the front side of the device (OLED display, ON/OFF touch button) to remove it.
  • Page 20 OSMOND L, R User’s Manual 3. Gently push the blind plug into the slot of the document holder. 4. If the document holder is to be put back to the device later on, then the blind plug can be removed by using a long and flat screwdriver.

  • Page 21: Contact Information

    OSMOND L, R User’s Manual Contact Information Headquarters: Service Address: Adaptive Recognition, Hungary Inc. Adaptive Recognition, Hungary Inc. Alkotás utca 41 HU- Ipari Park HRSZ1113/ 1 HU 1123 Budapest Hungary 2074 Perbál Hungary Phone: +36 1 201 9650 Phone: +36 1 2019650...

This manual is also suitable for:

Osmond r
