Summary of Contents for AME 15925
- Page 1 15925 Instruction Manual & Part List 5Qt. Air Pump w/ Plastic Reservoir MODEL 15925 PLASTIC RESERVIOR AIR HYDRAULIC PUMP AME International 2347 Circuit Way Brooksville, Fl 34604 (877)775-4263 www.ameintl.net...
-
Page 2: Specification
SPECIFICATION Input Air Input Port Output Port Oil Delivery (cu.in./min) Internal Usable Oil Weight Pressure Threads Threads Relief Setting Capacity (lbs. L+W+H (psi) (Psi) (cu.in.) w/fluid) 0 psi 10,000 psi 12.3”x6.7”x7.5” 90-140 ¼-18 3/8-18 NPT 24.4 10,000 DESCRIPTION This Air/Hydraulic Pump supplies hydraulic fluid pressure to selected tools. It consists of an in-line air and hydraulic cylinder. -
Page 3: Maintenance
MAINTENANCE 1. Inspect hosed and connections daily. 2. Tighten connections as needed. Use non-hardening pipe thread compound when servicing connections. 3. Use only good quality hydraulic fluid. We recommend Mobil DTE13M or equivalent. When not in use or during storage: a. - Page 4 15925-031 Rear Cover 15925-061 Screw 15925-002 Oil Filter 15925-032 O-Ring 15925-062 O-Ring 15925-003 Oil Filter 15925-033 O-Ring 15925-063 Oil Filter Plug 15925-004 Valve Block 15925-034 Bolt 15925-064 Oil Filter Plug 15925-005 Screw 15925-035 Fixing Base 1 15925-065 Screw 15925-006 Spring...
-
Page 5: Troubleshooting
Air trapped in System Ensure proper fluid level Ensure vented oil filler plug let Poor Performance pressurized reservoir air escape (see before use) AME International 2347 Circuit Way Brooksville, Fl 34604 (877)775-4263 www.ameintl.net...
