- Page 1 INSTALLATION & MAINTENANCE MANUAL OP9R...
-
Page 2: General Instructions
These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following product: OP9R SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations. -
Page 3: Installation
Do not overload this accessory or subject it to conditions outside its rating This product is Class I and must be earthed This product is IP66 rated LLATION INSTALLATION he unit should be fixed to a rigid flat surface as unevenness could cause damage to the product Note: the unit should be fixed to a rigid flat surface as unevenness could cause damage to the product or affect operation •... - Page 4 • The backbox has drain hole drilling guides marked (see Fig. 2). Drilling a drain hole is advised if the unit is installed in a location subject to temperature fluctuations where a build-up of condensation may occur. It is not advised if the unit will be subject to high pressure jets as drilling a drain hole will reduce the IP rating.
- Page 5 • Remove one or more of the pre-fitted blank plugs as required by pushing out from the inside and install a suitable IP rated gland or adaptor (not supplied). For rear entry, cut or drill a 20/25mm hole where marked and install a suitable IP rated grommet (not supplied). Remove one or more of the pre-fitted blank plugs as required by pushing out from the inside and install •...
-
Page 6: Remote Control
• An earth connection must be made to the earth terminal of the socket. Use green/yellow sleeving on earth conductors that are not insulated. The earth terminal in the backbox is provided for convenience and does not need to be connected •... - Page 7 Changing the battery: Using a small flat screwdriver, remove the cover from the remote and take out the PCB • Remove the old batteries and insert two new CR2016 batteries (see Fig. 4) • Fig. 4 Fig. 4 WARNING WARNING To ensure continued safe and proper weatherproof operation, the unit must not be left with To ensure continued safe and proper weatherproof operation, the unit must not be left with the cover raised open or the catch left unlocked.
-
Page 8: Warranty
GENERAL This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities for where facilities exist. The batteries in the remote are Lithium Ion and must be disposed of correctly. Please contact the local authorities for the disposal of this toxic waste. - Page 9 Manufacturers Declaration of Conformity For ML Accessories (Knightsbridge) Electrical products in accordance with CE marking ML Accessories Ltd. Declare that all products have been designed, manufactured, and tested in accordance with the requirements of the relevant legislation CE marking legislation...
- Page 10 Manufacturers Declaration of Conformity For ML Accessories (Knightsbridge) Electrical products in accordance with UKCA marking ML Accessories Ltd. declare that all products have been designed, manufactured, and tested in accordance with the requirements of the relevant legislation UKCA marking legislation UK SI 2016 No.
- Page 11 Supplied By: (UK) Manufacturer ML Accessories Ltd, Unit E Chiltern Park, Boscombe Road, Dunstable LU5 4LT, www.mlaccessories.co.uk (EU) Authorised Representative nnuks Holding GmbH, Niederkasseler Lohweg 18, 40547 Düsseldorf, Germany, Email: eprel@nnuks.com AVJUN22_V2...
