USER MANUAL
Z-WAVE SMART CHIME
ZSE33
Z-Wave Plus Certified Device
FEATURES
- Audio and visual notifications triggered by other Z-Wave devices or scheduled in your routine
- Choose from 10 different sounds for chime and siren modes
- Advanced configuration available
- Powerful long-lasting batteries
- Z-Wave Plus with improved 500 chip for faster and safer wireless communication
- Small size and quick installation
SPECIFICATIONS
Model Number: ZSE33
Z-Wave Signal Frequency: 908.42 MHz
Power: 2 CR123 batteries (included)
Power Consumption: 2W
Operating Temperature: 32 – 104 F
Range: Up to 100 feet line of sight
Installation and Use: Indoor only
Dimensions: 2.7" x 1.2"
Weight: 3 oz
BEFORE YOU RETURN IT
Let us know if you are having any issues installing or operating the device.
Our fast and friendly tech support is here to help, every day of the year: ask@getzooz.com
Get more helpful tips at getzooz.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZSE33 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZooZ ZSE33

  • Page 1 - Powerful long-lasting batteries - Z-Wave Plus with improved 500 chip for faster and safer wireless communication - Small size and quick installation SPECIFICATIONS Model Number: ZSE33 Z-Wave Signal Frequency: 908.42 MHz Power: 2 CR123 batteries (included) Power Consumption: 2W Operating Temperature: 32 –...
  • Page 2: Installation

    INSTALLATION WAIT! Include the Smart Chime to your Z-Wave network and test before mounting it. Z-WAVE INCLUSION Auto Inclusion: 1. Put your Z-Wave controller in inclusion mode 2. Carefully remove the cover from the device 3. Remove the plastic pull-tab from the battery slot – the Chime will automatically enter inclusion mode for 20 seconds 4.
  • Page 3: Factory Reset

    4. The Smart Chime should disappear from your controller's device list If the first attempt is unsuccessful, please repeat the process following all steps carefully. FACTORY RESET When your network’s primary controller is missing or otherwise inoperable, you may need to reset the device to factory settings manually.
  • Page 4 Size: 1 byte dec. Siren Alarm Duration Parameter 2: Choose from 5 modes to set the duration for siren alarm: 0 – alarm is off 1 – alarm goes off for 30 seconds 2 – alarm goes off for 60 seconds 3 –...
  • Page 5 LED Notifications for Chime Parameter 9: Enable or disable visual alarm for Chime mode. The LED will blink when triggered. Values: 0 – LED disabled (default); 1 – LED enabled. Size: 1 byte dec. Indicator Command Class You may use the indicator command class to assign tones played by your Smart Chime – this will also enable you to switch between the Siren and Chime modes.
  • Page 6: Warranty

    See full list of Zooz distributors here: getzooz.com/buy During the Warranty Period, Zooz will repair or replace, at no charge, products or parts of a product that prove defective because of improper material or workmanship, under normal use and recommended maintenance.
  • Page 7 You may also get in touch with the reseller of the product directly to return or replace the product within 30 days of purchase or within applicable reseller’s returns period. IN NO EVENT SHALL ZOOZ OR ITS SUBSIDIARIES AND AFFILIATES BE LIABLE FOR ANY INDIRECT, INCIDENTAL, PUNITIVE, SPECIAL, OR CONSEQUENTIAL DAMAGES, OR DAMAGES FOR LOSS OF PROFITS, REVENUE, OR USE INCURRED BY CUSTOMER OR ANY THIRD PARTY, WHETHER IN AN ACTION IN CONTRACT, OR OTHERWISE EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
