- Page 1 MANUFACTURING NUMBERS: 9020440 9020442 9020444 9020450 9020452 9020455 9020456 9020458 9020460 9020462 9020464 9020465 9020466 9020468 9020470 9020472 9020480 DISPLAY CABINETS 9020481 9020482 9020485 HEATED 9020486 Model DCH ® P/N 1010677 Rev. D 12/99 Owner s Manual ’...
-
Page 2: Table Of Contents
The warranty does not extend to: for POTENTIALLY HAZARDOUS FOOD display. • Damages caused in shipment or damage as Models DCH-12, DCH-22 & DCH-32 are designed for result of improper use. NON-POTENTIALLY HAZARDOUS FOOD display. • Installation of electrical service. -
Page 3: Service/Technical Assistance
Refer to the service agency directory included with your unit. If you experience any problems with the installation or Authorized Service Agency operation of your unit, contact your local Roundup Authorized Service Agency. Name: Fill in the information below and have it handy Phone No.:... - Page 4 (BOCA) and the Food Service Sanitation • This equipment should be serviced by qualified Manual of the Food and Drug Administration personnel only. Contact the nearest Roundup (FDA). authorized service facility for adjustment or repair. • Do not immerse cord or plug in water.
-
Page 5: Specifications
• Check with a qualified electrician if you are in doubt as to whether the appliance is properly grounded. NEMA 5-20P 20 Amp, 120 VAC Model Designation DCH-10 XX DCH-12 NEMA 6-20P TYPE OF POWER CORD DCH-20 H = HARMONIZED... -
Page 6: Temperature Ranges
A.J. Antunes & Co. DISPLAY CABINET HEATED Temperature Ranges Capacities DCH-10: 150°-165°F (66°-74°C) DCH-10/DCH-12 • One 2-1/2" (63.5 mm) deep full size steam table DCH-12: 100°-165°F (38°-74°C) pan. DCH-20: 150°-165°F (66°-74°C) • One water tray at 4 quarts (3.8 liters). -
Page 7: Installation
4. Install components in unit. Water Tray Equipment Setup When placing the unit into service, pay attention to the Figure 1. Display Components (DCH-10 Shown) following guidelines. WARNING • Make sure power to the unit is off and the unit is ELECTRICAL SHOCK HAZARD. -
Page 8: Operation
Figure 2. Filling Water Tray (DCH-10 Shown) IMPORTANT: Models DCH-12, DCH-22 and DCH-32 have a temperature range of 100°-165°F (38°-74°C) which is below the safe holding temperature for some foods. -
Page 9: Maintenance
A.J. Antunes & Co. DISPLAY CABINET HEATED MAINTENANCE 3. Wash all components in soap and water. Wipe all CAUTION surfaces of the unit with a hot damp cloth. Chlorides or phosphates in cleaning agents (e.g. bleach, sanitizers, degreasers or detergents) could NOTE: Do not use a dripping wet cloth. - Page 10 4. Using a screwdriver or similar flatbladed tool, gently pry one side of the display panel assembly from the unit (Figure 6), then remove the panel. 5. DCH-10/12: Remove lamp by gently turning it DCH-20/22/30/32 counterclockwise. Install a new lamp.
- Page 11 A.J. Antunes & Co. DISPLAY CABINET HEATED MAINTENANCE (continued) FRONT GLASS PANEL REPLACEMENT Front Glass Top Cap CAUTION Panel Assy. Front glass panel replacement should be per- formed by two people to prevent damage to the glass. 1. Turn rocker switch to the OFF position. Top Glass Retainer Assy.
-
Page 12: Troubleshooting
Defective solid state relay. Replace solid state relay. Defective stepdown transformer. Replace transformer. Light bulb burned out. Replace light. Display panel does not light. DCH-20/22/30/32 only. Defective Replace ballast. ballast. Halogen heat lamp(s) will Heat lamp(s) burned out. Replace heat lamp(s). not light. -
Page 13: Replacement Parts
A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-10/12 47 18 P/N 1010677 Rev. D 12/99... - Page 14 A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-10/12 Item Part Description Qty. Item Part Description Qty. 0011103 Front Glass Panel Assy. 29 0503052 Bracket, Lamp 0021057 Inner Lamp Housing Weldment 30 4060359 Lamp, 120V, 10 Watt 0011107 Resistor Assy.
- Page 15 A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-20/22/30/32 36 51 28 27 P/N 1010677 Rev. D 12/99...
- Page 16 A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-20/22/30/32 Item Part Description Qty. (240V) (120V) DCH-20 DCH-22 DCH-30 DCH-32 DCH-32 0011002 Front Glass Panel Assy. 0011003 Front Glass Panel Assy. 0020922 Inner Lamp Housing Weldment 0020923 Inner Lamp Housing Weldment 0010706 Resistor Assy., 120V...
- Page 17 A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-20/22/30/32 (continued) 36 51 28 27 P/N 1010677 Rev. D 12/99...
- Page 18 A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-20/22/30/32 (continued) Item Part Description Qty. (240V) (120V) DCH-20 DCH-22 DCH-30 DCH-32 DCH-32 25 0700388 Power Cord w/Plug, NEMA 6-20P 0700448 Power Cord w/Plug, NEMA 5-20P 0700475 Power Cord w/Plug, CEE 7/7...
- Page 19 A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-20/22/30/32 (continued) 36 51 28 27 P/N 1010677 Rev. D 12/99...
- Page 20 A.J. Antunes & Co. DISPLAY CABINET HEATED REPLACEMENT PARTS – DCH-20/22/30/32 (continued) Item Part Description Qty. (240V) (120V) DCH-20 DCH-22 DCH-30 DCH-32 DCH-32 51 306P105* Screw, #6-32 x 1/2, SS 52 306P130* Nut, Hex, KEPS, #6-32 53 308P103* Screw, #8-32 x 1/4, One-Way...
-
Page 21: Wiring Diagram
A.J. Antunes & Co. DISPLAY CABINET HEATED WIRING DIAGRAMS DCH-10/12 (120V) DCH-20/30/32 (240V) DCH-22/32 (120V) P/N 1010677 Rev. D 12/99... -
Page 22: Warranty
2.Roundup reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations. Changes to update equip- ment do not constitute a warranty charge.
