- Page 1 IP-600NA IP Network Pre-Amplifier INSTALLATION & OPERATION MANUAL Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 IP-600NA IP Network Pre-Amplifier SAFTY WARNINGS! Read and keep these instructions. Heed all warnings and follow all instructions. Do not use this apparatus near water. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
- Page 3 IP-600NA IP Network Pre-Amplifier INTRODUCTIONS: Description: The IP public address system network audio Pre-Amplifier with decoder is the main equipment of the IP network PA system. It is built-in decoder which can decode the network audio signal into analog to feed in analog amplifier.
-
Page 4: Front Panel And Rear Panel
Network status indicator, light on means LAN communication is good. Power indicator, light on means AC power supply on. Terminal Configuration Port, RS232 protocol, which is used to configure the terminal through CMX supplied cable with PC directly. LAN Port, after connection with LAN network, green LED light and yellow flash means communication well, otherwise means communication failure. -
Page 5: Operation And Setting
192.168.0.1 1.2 Online Status Monitoring Connect the IP-600NA and IP-600RM IP remote paging microphone to the LAN network with PC server, the software will auto detect the IP terminal, go to the “Session status” to monitor and check all equipments whether are online or not, “red cross” means failure connection, please correct the IP configuration. - Page 6 IP-600NA IP Network Pre-Amplifier 2. How to make paging over IP? 2.1 User Log In Press “Enter” button to enter the user log in window with password “001” and “enter”. Press “enter” to log in the menu: 1-Paging, 2-Intercom, 3-Program Broadcast, 4-Program Control and 5-Exit 2.2 Terminal Status Monitoring...
-
Page 7: Specifications
IP-600NA IP Network Pre-Amplifier SPECIFICATIONS: Model IP-600NA Description IP Network Audio Pre-Amplifier Power Supply AC230V or 110V Power Consumption Network Protocol TCP, UDP, ARP, ICMP, IGMP Network Speed 10/100Mbps Audio Format Mp2, Mp3, PCM, ADPCM Audio Sampling 8KHz-44.1KHz, 16 bits, 8K-320Kbps S/N Ratio ≥90dB... - Page 8 IP-600NA IP Network Pre-Amplifier Simple Trouble Shoot Guidance Can not connect the network audio Check whether the software is incomplete installation for Anti-virus, firewall, adapter to the PC server Windows 7 or office 2007 Check the PC server whether have the fixed IP...
- Page 9 IP-600NA IP Network Pre-Amplifier messages or music songs to different speaker zones at the same time What kinds of music broadcasting There are six ways of music broadcasting: 1) External source player input to this system can do? the PC, the software will transfer the analog data into digital data 2) Live...
