Professional Sound System
Operation Manual
CX4.40, CX4.50, CX4.100
CX4.150, CX4.180, CX4.240
Professional Class-D Four Channel Amplifier
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
Advertisement
Table of Contents
Related Manuals for CMX CX4.40
Summary of Contents for CMX CX4.40
-
Page 1: Operation Manual
Professional Sound System Operation Manual CX4.40, CX4.50, CX4.100 CX4.150, CX4.180, CX4.240 Professional Class-D Four Channel Amplifier Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference. -
Page 2: Table Of Contents
1. SAFETY PRECAUTIONS ................1 2. PRODUCT INTRODUCTION ................. 3 3. FEATURES....................3 4. EFFICIENCY....................4 5. POWER SUPPLY..................4 6. SUITABLE APPLICATION................4 7. NOMENCLATURE AND FUNCTIONS 7.1 Front Panel ..................5 7 .2 Rear Panel...................5 8. OPERATION INSTRUCTIONS...............6 9. -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS Be sure to read the instructions in this section carefully before use. Make sure to observe the instructions in this manual as the conventions of safety symbols and messages regarded as very important precautions are included. We also recommend you keep this instruction manual handy for future reference. Safety Symbol and Message Conventions Safety symbols and messages described below are used in this manual to prevent bodil y injury and property damage which could result from mishandling. - Page 4 SAFETY PRECAUTIONS When Installing the Unit When Installing the Unit Never plug in nor remove the power supply plug Do not place heavy objects on the unit as this may with wet hands, as doing so may cause electric cause it to fall or break which may result in personal shock.
-
Page 5: Product Introduction
2. PRODUCT INTRODUCTION The Class-D range four channel power amplifiers are our latest digital professional power amplifier, which is the new milestone in switch power technology amplifiers. It is of light and 1RU height but can provide you with unprecedented strong power. The high sound quality will be a new marker of professional audio market. -
Page 6: Efficiency
. E F F I C I E N C Y Compared with the traditional audio power amplifier, D series power amplifier show more excellent performance, while significantly reduce heat, offer more strong power to the speakers. High conversion efficiency which can make the size of the power amplifier, weight and power consumption greatly reduced. Output efficiency reaches up to 95%. -
Page 7: Nomenclature And Functions
7 . N O M E N C L AT U R E A N D F U N C T I O N S Front Panel CH-D output level meter 1. CH-A volume control 8. CH-D volume control 2. CH-A output level meter 9. -
Page 8: Operation Instructions
8 . O P E R A T I O N I N S T R U C T I O N S 1. Power on 1.1 According to introduction, make the setting and wiring correctly. 1.2 Check short circuit between input cable and output cable. 1.3 Check whether the local power grid are in conformity with this manual. -
Page 9: Applications
10. CONNECTION DIAGRAM 7 / 12... -
Page 10: Block Diagram
11. BLOCK DIAGRAM 8 / 12... -
Page 11: Specifications
12. SPECIFICATION Model CX4.40 CX4.50 CX4.100 CX4.150 CX4.180 CX4.240 Description Professional Class-D Four Channel Power Amplifier Amplifier Class D-Class Rated Output 8Ω Four 250W 350W 600W 800W 1000W 1300W Rated Output 4Ω Four 400W 500W 1000W 1500W 1800W 2400W Rated Output 2Ω Four... -
Page 12: Service & Warranty
Terms and conditions of warranty for a given product may be determined first by locating the appropriate country which the product was purchased in, then by locating the product type. Guangzhou CMX Audio Co., Limited 302RM 3#, Honghui Industrial Zone, Zhongyuan RD, Shibi Area, Panyu, Guangzhou, China 511497 Web: www.cmxaudio.com...
