- Page 5 Align threaded bolts of the back (#1) through the holes of the seat (#3) and legs (#2). Secure by using washers (#B,C) and tighten with hex nut (#C).
- Page 6 1) Align arms (#4) to the holes of the back (#1). Insert bolts (#E) through the arms (#4) and back (#1), then secure by using washers (#G), hex nut (#H), and nut cap (#1). 2) Attach threaded bolts (#F) to the bottom hole attaching to seat (#3). Align arms (#4) to the holes of the seat (#3), then secure by using washer (#G), hex nut (#H) and nut cap (#I).
- Page 7 Attach threaded bolts (#J) to the holes of the table top (#5), then align and insert legs (#6) to the threaded bolts (#J) of the table top (#5). Secure by using washers (#A,B), hex nut (#C) and nut caps (#D). Align center plate (#7) to the holes of the legs (#6), then secure by using washers (#A,B) and hex nut (#C).
- Page 8 ASSEMBLY COMPLETED...
