Specification
Size：7"
Resolution：1920(H) × 1200(V)
2
Brightness：500cd/m
Viewing angle： 89/89/89/89
Sampling ratio：10bit
Voltage input：DC 12V
Power consumption：≤15W
Dimension：L192.0×H132.0×D27.5mm
Weight：around 450g
Format
3G- SDI
1080/50p/60p
HD- SDI
1080/24p/24psf/25p/30p/50i/60i
720/50p/60p
SD- SDI
480i/576i
HDMI
2160/24p/30p/50p/60p
1080/24p/24psf/25p/30p/50i/60i
50p/60p 720/50p/60p 480i/576i
Special material declaration
Hazardous material name and content
Hazardous materia
Parts
Name Pb Hg Cd
Cr6+
PBBs
×
○
○
○
○
Monitor
×
○
○
○
○
Adapter
×
○
○
○
○
Parts
The table is made based on SJ/T 11364
Comply to the EU RoHS environmental protection
standard.
l
PBDEs
○
○
○
Quick Guidance
Advertisement
Related Manuals for Ruige Action HL-701HM
Summary of Contents for Ruige Action HL-701HM
- Page 1 Specification Size：7" Resolution：1920(H) × 1200(V) Brightness：500cd/m Viewing angle： 89/89/89/89 Sampling ratio：10bit Voltage input：DC 12V Power consumption：≤15W Dimension：L192.0×H132.0×D27.5mm Weight：around 450g Format 3G- SDI 1080/50p/60p HD- SDI 1080/24p/24psf/25p/30p/50i/60i 720/50p/60p SD- SDI 480i/576i HDMI 2160/24p/30p/50p/60p 1080/24p/24psf/25p/30p/50i/60i 50p/60p 720/50p/60p 480i/576i Special material declaration Hazardous material name and content Hazardous materia Parts Name Pb Hg Cd...
- Page 2 Introduction of key functions Interface function introduction Intelligent brightness control When pressing the metering light function key , the screen prompts "Underexposure", "Normal exposure", and "Overexposure". Under Exposure Normal Exposure Over Exposure In the image, the display below the lower limit set value is "purple", which means the image is under- -exposed .
